Designed to be Compact
The small box design makes it flexible for mounting anywhere. Though it is compact, it doesn't compromise on quality. The 1/2.3” 4K CMOS sensor captures high-quality images and incredible details of the subject.

Interchangeable CS Mount Lenses
User can install a CS Mount camera lens to the BC-15C/BC-15CN, or use a C Mount camera lens with the bundled 5mm CS-C camera lens adapter ring.  User can have a wide range of visual expression by using different lenses for the BC-15C/ BC-15CN.
* The lens is NOT included with the BC-15C/BC-15CN package.

1/2.3” CMOS Sensor with 4K 50/60p Output
The BC-15 series is one of the best cameras for capturing eSports. When changing back to the standard lens, it will fulfill a wide range of other applications.

Elevate Your Content with Seamless 4K Streaming
During video production, you can stream your program to different platforms such as YouTube and Facebook. If using Datavideo dvCloud, you can even stream your program to 25 different platforms at the same time while backing up your program on the cloud server.

Low-Latency SRT Streaming Engine Allowing Online Switching to dvCloud with Nearly Zero Latency
Many viewers may have encountered streaming issues, such as video stuttering or frame loss, often attributable to fluctuating bandwidth and network instability. dvCloud incorporates the SRT protocol, effectively reducing frame loss even when your network is unstable. If you are still encountering problems with RTMP streaming, dvCloud stands out as the optimal solution for a smoother and more enjoyable viewing experience.

Built-in Tally Light
Built-in tally lights make it easier for the talent to know which camera is live during a multi-camera live production.

Physical Buttons Make Camera Setup Very Easy
When the camera is set up, there is no need to use an additional remote controller. The physical buttons on the rear panel of the BC-15C make it very easy to adjust settings.

Power over Ethernet
The BC-15C supports PoE for easy installation. No need to find local power outlets or hire an electrician to install outlets wherever you want to mount your camera. Simply run a single CAT 6 cable to power your BC-15C.

Built-in DC-IRIS Function
Most off-the-shelf C/CS lenses are manual aperture lenses but some adopt DC-IRIS technique which is thus also included in the BC-15C, making lens selection hassle-free.

1/4” Screw Hole for Mounting
Changing the camera angle is easy with the three 1/4” screw holes on the BC-15C. It gives you the flexibility of mounting it anywhere.

Datavideo BC View Assist App
BC View Assist App is the ultimate companion for BC-15 devices, simplifying control and enhancing streaming. Automatically detecting connected devices, it enables effortless DVIP management.

With support for major video coding standards and innovative streaming protocols, it delivers precision. Accessible directly from mobile, it redefines convenience in configuring remote settings, ensuring a seamless streaming experience.

Configuring Live Video on the Mobile Phone
You can adjust the video settings on the mobile phone and preview the video as you make changes to the settings. You can also monitor major camera settings such as HDMI output resolution,camera name, and stream status.

Model Number: BC-15C
Video format/Resolution: 2160p 60/59.94/50/30/29.97/25 , 1080p 60/59.94/50/30/29.97/25
Image Sensor: 1/2.3" CMOS
Effective Pixels (approx.): 12.3Mega Pixels
S/N Ratio: 50 dB
Min. Illumination: 0.5Lux (F1.0, AGC ON) * depend on Lens
Electronic Shutter: 1/25(1/30), 1/50(1/60), 1/75(1/90), 1/100(1/120), 1/125(1/150), 1/150(1/180), 1/200(1/210), 1/500(1/600), 1/1000(1/1200), 1/2000(1/2400), 1/4000(1/4800), 1/8000(1/9000) sec
Zoom Ratio: 2x Digital Zoom , Optical Zoom depend on lens
Gamma Control: Standard / Mode1 / Mode2 / Mode3
Iris Control: DC IRIS supported * depend on Lens
Digital Noise Reductions: 2D/3D
On-Screen Display (OSD): English/Simplified Chinese/Traditional Chinese
White Balance: Auto, Indoor, Outdoor, OnePush, Color Temp., R/B Gain, Lock
AGC / Gain Control: Auto(AGC) / Manual / Lock (Follow Exposure Mode)
HDR/WDR: WDR
Mirror / Flip Image: Yes
Focus Mode: Full Manual
Panning / Tilting Range: ----
Panning / Tilting Speed: ----
Preset: ----
Focal Length: * depend on Lens
Field of View (Horizontal, Wide): * depend on Lens
Image Compensation: Auto
Video Output: HDMI 2.0 x1
Audio Input: 3.5mm Line in/Mic in (Stereo)
Tally LED: Dual color (Red, Green)
Lens Filter: IR cut built-in
Control Protocol: DVIP
Remote Control Interface: RJ-45: for IP control (DVIP)
Video Compression Format: H.265, H.264
Audio Compression Format: AAC
Audio Bitrate: 128Kbps
HD IP Interface: 10/100/1000M
Streaming Protocols: RTMP(S), SRT
First Stream Supported Resolution: 1920x1080 , 1280x720 , 1024x576 , 960x540 , 640x480 , 640x360
Second Stream Supported Resolution: ----
Video Bitrate: 1Mbps ~ 7Mbps
Video Bitrate Mode: VBR, CBR
Encoding Frame rate: 50Hz: 1-50fps , 60Hz: 1-60fps
POE: IEEE 802.3af
F/W Update: Ethernet
IR Control: ----
Camera Control Unit: RMC-300 series/BC View Assist APP
Tripod Mount: 1/4-20 UNC
Optional Accessories: ----
Color: Black
Dimension (LxWxH): 77mm (W) x 82mm (D) x 78mm (H)
Weight: 204 g
Operating Temp. Range: 0~40 °C
Power: DC 12V 9W

What's in the Box
1 x BC-15C Main Unit
1 x CS-C Lens adaptor ring
1 x DC 12V power adaptor
