Downscale Conversion with Stand-Alone Audio Output
Converts 3G/HD/SD-SDI input to analogue video and 2 unbalance analogue audio channels.

Two Available Output Combinations with Independent SDI Loop-Through
Can choose output options between 1 x YUV output & 1 x CV output or 1 x S-Video (Y/C) output & 2 x CV outputs. SDI loop through is unaffected by the adjustments of resolution setting to the analogue signal, users can connect the original video signal to other terminal device.

Aluminum Alloy and Heavy Duty Design
Super sturdy and durable. DAC series has a rugged metal housing for use in even the roughest conditions. Low heat dissipation, ideal for long hour operation in normal ventilated environment.

Model Number: DAC-50S
Conversion: 3G/HD/SD-SDI to Analog Down Converter
Video Inputs: 1x 3G/HD/SD-SDI
Loop Through: Yes
Video Outputs: YUV + Composite or Y/C + 2x Composite
Audio Inputs: 1x SDI Audio embedded
Audio Outputs: 2x RCA (Stereo Pair)
Supported Video Input Formats: 1080p (50/59.94Hz) , 1080i (50/59.94Hz), 720p (50/59.94Hz), 576i, 480i
Output Resolutions: 576i, 480i
Equalizer: Yes
Reclock: Yes
Updates and Configuration: Mini USB x 1
Dimension (LxWxH): 112 x 85 x 45 mm
Weight: 0.5 kg
Operating Temp. Range: 0~40 °C
Power: DC 12V, 6W
What's in the Box: 1 x DAC-50S , 1 x AD Switch DC 12V
