Compact Design Suited for Medium-sized Productions
The HS-1300 offers a small footprint and supports up to 6 video inputs in HDMI and SDI, and 5 Video Outputs ( SDI x 2 + HDMI x 3).

All-in-One
Switch, stream, and record from a single unit. XLR audio connections allow you to connect master audio from a mixer.

Made for Mobility, Made for the Web
The HS-1300 brings a new level of simplicity to production workflows. You'll set up faster and easier thanks to its portable "briefcase" design. And thanks to its built-in H.264 web streaming encoder, you can stream your show to virtually any CDN like YouTube and Facebook in no time.

Built-in H.264 Recorder for SD Cards
The HS-1300 comes with a built-in web-ready recorder. Simply insert your SD card, and you'll have video files that can be immediately uploaded to the video network of your choice or to your website.

Streaming to Facebook Live, YouTube, Twitch, and More
The built-in H.264 encoder allows you to stream your show to virtually any CDN like Facebook, YouTube or Twitch in no time. It also supports different bitrate for recording to SD card and streaming function

Built-in Virtual Set Backgrounds and 9 Animations
Choose between a variety of pre-saved virtual set backgrounds. Choose between a variety of pre-saved animated stinger transitions for your show.

User Memories
You can save a complex process into a user memory, turning multiple tasks into a one-finger job.

17.3'' LED Backlit Monitor
Built-in Monitor Display. 17.3" HD TFT LED backlit monior with resolution 1600x900 pix.

Support SRT Streaming Protocol, no Need to Worry About Unreliable Network Environment
Many broadcasters have experienced pixelated video during live streaming, often due to unstable network environments caused by bandwidth volatility. Streaming RTMP over unreliable, low-bandwidth networks can cause issues. With dvCloud, you can now replace the RTMP protocol with SRT, which will fix most streaming issues you may have. SRT is better than RTMP because it handles problematic networks more efficiently. It requires less bandwidth, and it solves data errors faster. As a result, your viewers will experience a better stream, with less buffering and pixelization.

Model Number: HS-1300
Video Standard: HD
Video Format: 1080i 50/59.94/60Hz , 720p 50/59.94/60Hz
Input Routable / Crosspoint: All 6, repeatable
Video Input: 4x HD-SDI , 2x HDMI
Computer Graphic Interface: 2 via HDMI
Video Output: 3x HDMI + 2x SDI assignable: AUX 1-6, PGM, PVW, PGM Clean or Multiview
Analogue Audio Input: 2x Balanced XLR
Analogue Audio Output: 1x Stereo headphone
Digital Embedded Audio Support: Input 2 channels, Output 2 channels
A+V Switching: Yes
USK: 2x USK support Chromakey
DSK; 2, support Lumakey & Linear key (Key / Fill)
Picture in Picture: 1
Built-in Monitor Display: 17.3” HD TFT LED backlit, 1600x900 pix
Streaming: H.264 / AVC, Main/ High Profile , Configurable Bit-rate up to 10Mbps
Streaming Audio Encode: AAC-LC , Configurable bit rate range from 32Kbps to 384Kbps , Sample rate: 48KHz, 16bit
Streaming Protocol: TS over TCP/UDP (unicast & multicast) , RTSP over HTTP/TCP/UDP (RTSP Elementary Streaming) , RTMP/RTMPS (Publish) , HLS , SRT
Streaming Control: Web browser UI for configuration and control Socket commands
Recording File System: FAT, exFAT, NTFS
Recording File Format: MP4
Streaming & Recording Setting Control: Web UI for system configuration and control
Special Features: Streaming encoder and recorder , 2 chromakey virtual studio , 9 stinger transition and 30 virtual sets included
Dimension (LxWxH): 455 x 355 x 134 mm
Weight: 16.3 Lbs (7.4 kg), Reinforce Plastic Case
Power: DC 12V, 5A
Operating Temp. Range: 0~40 °C
What's in the Box: 1 x HS-1300 Product , 1 x AD Switch DC 12V with AC Cord
