A Multi-Functional Multi-Camera Controller
The Datavideo RMC-300A stands out as a multi-functional multi-camera controller with advanced control protocols. It supports various control protocols such as Sony VISCA, VISCA over IP-S, VISCA over IP-C, and Datavideo DVIP.

With the capability to control up to 24 Datavideo PTZ and block cameras via DVIP or up to 8 Datavideo cameras through serial RS-422 transmission, the RMC-300A provides unparalleled flexibility.

Its user-friendly interface on a 5” touch panel, combined with hardware buttons, empowers users to efficiently manage complex EFP workflows without compromise.

The Datavideo RMC-300A camera controller features dual USB 2.0 ports for expanded device connectivity, a 10/100Mbps Ethernet port with an RJ-45 connector for reliable network integration, and eight RS-422 ports (RJ-45 connectors) that enhance compatibility with various devices.

User Friendly Interface on 5-inch LCD Touch Panel
5-inch LCD touch panel design allows users to easily control settings of each cameras.

Control Up to 24 Cameras
Designed to control up to 24 cameras, with 7 preset memories for each camera for easy camera operation.

LCD Displays GUI for Operability and Visibility
Easily access to all the cameras setting, and call back your favorite settings such as Shutter, Focus, IRIS, Gain, Zoom, and movement speeds.

Professional Use
Single person control of Pan, Tilt, and Zoom is possible with the 2-axis Joystick and the zoom knob. Easily access all the cameras settings in the OSD, and call back your favorite settings such as Shutter, Focus, IRIS, Gain, Zoom, and movement speeds.

Remote Control via Ethernet or Serial Port RS-422
The RMC-300A can control PTZ and block cameras, as well as robotic camera heads such as the Datavideo PTR-10 series by using the DVIP or RS-422 interfaces.

Can control up to 8 cameras via RS-422 or 24 cameras via DVIP.

Zoom Knob and Lock Button
Easy to use knob for the camera to zoom in/out, and the Lock button to help you secure the position of the joystick and the zoom knob.

Model Number: RMC-300A
Maximum Camera Control: 24 Datavideo cameras over DVIP, up to 8 Datavideo cameras over serial RS-422
Preset (Position): 14 for each Datavideo camera
Control Protocol: Sony VISCA, VISCA over IP-S, VISCA over IP-C, Datavideo DVIP
Connection to Cameras: RS-422, Ethernet
Input/Output: USB 2.0 x2 , 10/100Mbps Ethernet (RJ-45 connector) x1 , RS-422 (RJ-45 connector) x8
Build-in Control Panel: Size: 5" , Resolution: 1280 x 720
Firmware Upgrade: USB 2.0
Dimension: 420 x 294 x 134 mm
Weight: 1.5 kg
Operating Temp. Range: 0°C ~ 40°C (32°F~104°F)
Storage Temperature: - 10°C ~ 60°C (14°F~140°F)
Operating Humidity: 10 % to 80 % (non-condensing)
Power: DC 12V, 19W
What's in the Box: 1 x RMC-300A Main Unit , 1 x DC 12V power adaptor
