HuddleCamHD HuddleView 12x HC12X-HUDDLEVIEW | Caméra PTZ, Auto-Framing, 12x Zoom, DVI, SDI, USB, IP

    HC12X-HUDDLEVIEW-C
    2 835,00 €
    Aucune taxe
    Hors stock (délai de livraison à confirmer)

    Auto-Framing Camera Model
    The HuddleView automatically frames all the meeting participants in view during a meeting. It intelligently combines facial tracking and motion with a 12X optical zoom to make the HuddleView an ideal video conferencing camera solution for mid-to-large-sized conferencing spaces.

    Automatically Frame Meeting Participants
    Our camera system allows for the automatic framing of all the participants at a meeting. Using a 12X optical zoom, HuddleView frames the first meeting participant and then continually adjusts as more participants enter the space. It’s that easy. Eliminate complicated setups and have your camera zoom in to automatically capture everyone in full detail without a remote control.

    Lecture Tracking Camera System
    See just how easy it is to set up your auto-framing camera on your network with our included Quick Start Guide and Video. Once you define the tracking stage and frame you would like to maintain around your subject, you can set the camera to automatically track.

    Unrivaled Warranties
    With robust warranties included standard on every product, you can trust HuddleCamHD solutions to deliver high performance from day one, and for many years to follow.

    The HuddleView comes with a 3-year limited parts and labor warranty. HuddleCamHD stands by our promise to protect your investment by providing repairs or replacement products for the duration of your warranty.

    KEY FEATURES
    • 12X Optical Zoom
    • Motion & Facial Framing
    • RSTP / RTMP Streaming
    • Multiple Video Outputs
    • 1080p@60 FPS SDI Feed
    • 1080p@60 FPS IP Feed
    • 72.5° Field of View
    • Software Interface
    • Supposed VISCA Protocol & VISCA over IP
    • Photobooth Functionality
    • Control Zones
    • Control Zone Triggers

    WHAT’S IN THE BOX
    • 12X HuddleView Camera
    • Power Supply
    • IR Remote
    • RS-232 Control Cable
    • USB 2.0 Cable 3m / 9.8 feet
    • Setup Documents

    Tracking Camera Image Sensor & Lens
    Video Sensor
    1/2.8” EXMOR, 2.14 Mega Pixel
    Frame Rate
    60fps @ 1920x1080p
    Lens Zoom
    12X Optical, f=3.9-46.8mm
    Field of View
    6.3° (tele) to 72.5° (wide) Horizontal
    Min Lux
    0.5 lux
    Reference Camera Image Sensor & Lens
    Video Sensor
    1/2.8” EXMOR, 2.14 Mega Pixel
    Field of View
    86° (Horizontal) x 52° (Vertical)
    Lens
    2.4mm
    Pan / Tilt Movement
    Pan Movement
    ±170°
    Pan Speed
    0.1° to 120° /s
    Tilt Movement
    +90° to -30°
    Tilt Speed
    0.1° to 90° /s
    Presets
    256 Presets
    Electrical Index
    Power Supply
    12V D 2.5A
    Input Power
    20W (Max)
    PoE
    No supported
    Physical Specifications
    Material
    Aluminum, Plastic
    Color
    Gray
    Dimensions (W x D x H)
    9.6” x 5.7” x 6.4” | 243mm x 145mm x 163mm
    Weight
    2.64 lbs (1.2 kg)
    Working Environment
    Indoor
    Operating Temperature
    32°F to 104°F (0°C to 40°C)
    Storage Temperature
    -4°F to 140°F (-20°C to 60°C)
    Humidity Range
    10% - 80%
    Rear Board Connectors
    HD Video Interfaces
    3G-SDI, USB 2.0, DVI-D
    Controller Signal Interface
    8pin mini-din
    Audio Input Interface
    3.5mm
    Network
    10/100
    Power Supply Interface
    D12V 2.5A
    Warranty
    Mfg. Warranty
    3 Years Parts & Labor

    HC12X-HUDDLEVIEW-C

    Fiche technique

    Sortie vidéo
    DVI
    RJ-45 (IP)
    SDI
    USB
    Entrée audio
    Mini Jack 3.5mm
    Sortie audio
    RJ-45
    Résolution maximale de sortie
    1080p 50/60 fps
    Protocole d'inspection pour les caméras PTZ
    RS-232
    VISCA
    VISCA IP
    Connexion Newtork
    Ethernet
    Taille du capteur
    1/2.8"
    Zoom optique
    12x
    Prise en charge PoE
    Pas
    Auto-Tracking
    Pas
    Tally Light
    Pas

    Références spécifiques

    ean13
    0737993161967
    mpn
    HC12X-HUDDLEVIEW-C
