HuddleCamHD HuddleView 12x HC12X-HUDDLEVIEW | Caméra PTZ, Auto-Framing, 12x Zoom, DVI, SDI, USB, IP

HC12X-HUDDLEVIEW-C
2 835,00 €
Aucune taxe
Hors stock (délai de livraison à confirmer)

Auto-Framing Camera Model
The HuddleView automatically frames all the meeting participants in view during a meeting. It intelligently combines facial tracking and motion with a 12X optical zoom to make the HuddleView an ideal video conferencing camera solution for mid-to-large-sized conferencing spaces.

Automatically Frame Meeting Participants
Our camera system allows for the automatic framing of all the participants at a meeting. Using a 12X optical zoom, HuddleView frames the first meeting participant and then continually adjusts as more participants enter the space. It’s that easy. Eliminate complicated setups and have your camera zoom in to automatically capture everyone in full detail without a remote control.

Lecture Tracking Camera System
See just how easy it is to set up your auto-framing camera on your network with our included Quick Start Guide and Video. Once you define the tracking stage and frame you would like to maintain around your subject, you can set the camera to automatically track.

Unrivaled Warranties
With robust warranties included standard on every product, you can trust HuddleCamHD solutions to deliver high performance from day one, and for many years to follow.

The HuddleView comes with a 3-year limited parts and labor warranty. HuddleCamHD stands by our promise to protect your investment by providing repairs or replacement products for the duration of your warranty.

KEY FEATURES
• 12X Optical Zoom
• Motion & Facial Framing
• RSTP / RTMP Streaming
• Multiple Video Outputs
• 1080p@60 FPS SDI Feed
• 1080p@60 FPS IP Feed
• 72.5° Field of View
• Software Interface
• Supposed VISCA Protocol & VISCA over IP
• Photobooth Functionality
• Control Zones
• Control Zone Triggers

WHAT’S IN THE BOX
• 12X HuddleView Camera
• Power Supply
• IR Remote
• RS-232 Control Cable
• USB 2.0 Cable 3m / 9.8 feet
• Setup Documents

Tracking Camera Image Sensor & Lens
Video Sensor
1/2.8” EXMOR, 2.14 Mega Pixel
Frame Rate
60fps @ 1920x1080p
Lens Zoom
12X Optical, f=3.9-46.8mm
Field of View
6.3° (tele) to 72.5° (wide) Horizontal
Min Lux
0.5 lux
Reference Camera Image Sensor & Lens
Video Sensor
1/2.8” EXMOR, 2.14 Mega Pixel
Field of View
86° (Horizontal) x 52° (Vertical)
Lens
2.4mm
Pan / Tilt Movement
Pan Movement
±170°
Pan Speed
0.1° to 120° /s
Tilt Movement
+90° to -30°
Tilt Speed
0.1° to 90° /s
Presets
256 Presets
Electrical Index
Power Supply
12V D 2.5A
Input Power
20W (Max)
PoE
No supported
Physical Specifications
Material
Aluminum, Plastic
Color
Gray
Dimensions (W x D x H)
9.6” x 5.7” x 6.4” | 243mm x 145mm x 163mm
Weight
2.64 lbs (1.2 kg)
Working Environment
Indoor
Operating Temperature
32°F to 104°F (0°C to 40°C)
Storage Temperature
-4°F to 140°F (-20°C to 60°C)
Humidity Range
10% - 80%
Rear Board Connectors
HD Video Interfaces
3G-SDI, USB 2.0, DVI-D
Controller Signal Interface
8pin mini-din
Audio Input Interface
3.5mm
Network
10/100
Power Supply Interface
D12V 2.5A
Warranty
Mfg. Warranty
3 Years Parts & Labor

HC12X-HUDDLEVIEW-C

Fiche technique

Sortie vidéo
DVI
RJ-45 (IP)
SDI
USB
Entrée audio
Mini Jack 3.5mm
Sortie audio
RJ-45
Résolution maximale de sortie
1080p 50/60 fps
Protocole d'inspection pour les caméras PTZ
RS-232
VISCA
VISCA IP
Connexion Newtork
Ethernet
Taille du capteur
1/2.8"
Zoom optique
12x
Prise en charge PoE
Pas
Auto-Tracking
Pas
Tally Light
Pas

Références spécifiques

ean13
0737993161967
mpn
HC12X-HUDDLEVIEW-C
