Advanced UltraHD pan tilt zoom camera with 12G-SDI, IP, and HDMI outputs.

Key Features:
• 4K UHD 60fps and 1080P 60fps output
• 30x optical zoom, 63° maximum horizontal field of view
• 12G-SDI, HDMI, Ethernet, and USB 3.0 video output
• Triple stream HEVC/H.264 IP video output
• Supports RTSP / RTMP / RTMPS / MPEG-TS / SRT streaming protocols
• Maximum horizontal/vertical speed of rotation: 300° /sec
• Supports Power Over Ethernet (PoE++)
• Smart AF: AI-enabled autofocus system
• FreeD protocol for live VR/AR production
• 5 Year Warranty

Broadcast Quality UltraHD Video
Paired with a low distortion professional zoom lens, the camera's large (1/1.8") CMOS sensor produces great 4K and HD results. Operating in lighting conditions down to 0.05 lux, the smooth video output makes it an ideal camera for producing sports, theatre, and live events. Its excellent color reproduction and 12G-SDI output mean it's a great choice for productions where image quality is of the highest importance.

AV and Broadcast Integration
The VC-A71P integrates with a variety of professional AV, IT, and broadcast workflows. The camera is ready for SDI and HDMI video workflows, IP networks, direct video streaming, and video conferencing via USB 3.0. Each interface will output video simultaneously, creating a flexible installation, monitoring, switching, and distribution options.

Live VR/AR Video Production
VC-A71P supports the popular FreeD protocol which outputs the camera’s positional data over IP in real-time. This enables users to work with state-of-the-art Virtual Reality and Augmented Reality sets without the need for additional sensors.

Control and Power
Lumens’ PTZ cameras offer users a high degree of versatility. The VC-A71P can be powered by a dedicated 12v DC adapter, or via POE++, giving network managers the option to install devices in any position. Multiple control protocols (Visca, Pelco, Onvif and UVC) and interfaces (RS-232, RS-422, Ethernet and USB 3.0) enable cameras to join new or existing networks.

Face Recognition Autofocus System
Equipped with Lumens' Smart AF algorithm, VC-A71P can intelligently identify human faces and automatically detect the eyes and mouth. This enables the camera to keep the subject in sharp focus all the time.

Semi-Autonomous Production
Each camera supports up-to 256 presets, allowing users to switch angles and zoom positions, and engage tracking movements at the touch of a button. The advanced Auto Focus, Auto Exposure and Auto White Balance algorithms automatically deliver consistent images while zooming and panning, or under changing lighting conditions. Together, these advanced functions allow a single operator to manage multiple cameras and to produce multi-camera productions without the need for a large crew.

Applications
•    Broadcast and Video Studios: built-in 12G-SDI, IP control and tally lights make VC-A71P and ideal 4K studio camera.
•    Live Events and Sports: Shooting UltraHD at 60p delivers smooth, high-quality images, with the zoom lens able to shoot wide and deliver extreme close-ups.
•    Next Generation AV Installation: featuring major control protocols and with support for multiple power and video output options, VC-A71P can integrate into the corporate, house of worship and education installations to deliver higher quality results.

Specification:
Sensor: 1/1.8" 9.17MP CMOS
Video Format: 2160p: 59.94 / 50 / 29.97 / 25 , 1080p: 59.94 / 50 / 29.97 / 25 , 1080i: 59.94 / 50 , 720p: 59.94 / 50 / 29.97 / 25
Video Output Interface: 12G-SDI / HDMI 2.0 / Ethernet / USB 3.0
Optical Zoom: 30x
Digital Zoom: 12x
Viewing Angle: 63° (H) 35.4° (V) 72.3° (D)
Aperture: F1.6 ~ F4.8
Focal Length: 6.5mm ~ 202mm
Shutter Speed: 1/1 ~ 1/10,000 sec
Minimum Object Distance: 1.5m (Wide/Tele)
Video S/N Ratio: > 50dB
Minimum Illumination: 0.05 lux (F1.6, 50IRE, 30fps)
Focus System: Auto / Manual / Smart AF
Gain Control: Auto / Manual
White Balance: Auto / Manual
Exposure Control: Auto / Manual / Smart AE
IQ Sync: Yes
WDR: Yes
3D NR: Yes
Image Flip: Yes
Color Space: Standard / BT.2020 / REC.709
AR/VR Systems: FreeD
Tally Light: Yes
Panning Angle: +170° ~ -170°
Panning Speed: 300°/sec
Tilting Angle: +90° ~ -30°
Tilting Speed: 300°/sec
Preset Positions: 256
HDMI / 12G-SDI: 2160p59.94
IP Stream: HEVC 4K 59.94fps , H.264 1080p 59.94fps , H.264 640x360 29.97fps
IP Compression: HEVC(H.265) / H.264
USB Output: H.264 4K30fps , MJPEG 1080p30
USB Compression: H.264 / MJPEG
IP Protocol: RTSP / RTMP / RTMPS / MPEG-TS / SRT
PoE: PoE++ (IEEE802.3bt)
Audio Input: Line In / MIC In, Phone Jack 3.5mm x1
Audio Output: Ethernet / 12G-SDI / HDMI 2.0 / USB
Audio Compression Format: IP: G.711 / USB: PCM
Control Interface: RS-232 / RS-422 / Ethernet / USB 3.0/ Remote
Control Protocol: VISCA / VISCAIP / PELCO D / ONVIF
UVC: 1.1
UAC: Yes
DC In: 12V +/- 20%
Power Consumption: PoE: 27.5 W , DC In: 27 W
Weight: 6.6lbs (3 kg)
Dimensions: 9.2" x 7.4" x 7.4" (232 x 188 x 189 mm)
