The new Blackmagic URSA Broadcast G2 is an incredibly powerful camera designed for both traditional and online broadcasters. The 3 cameras in 1 design allows it to work as a 4K production camera, a 4K studio camera or a 6K digital film camera! It's a perfect solution for broadcasters because it uses the lenses and batteries you already own! You can record to common SD cards, UHS-II cards, CFast 2.0 cards or external USB disks, using common file formats such as H.265, ProRes and Blackmagic RAW. This means it's compatible with all video software and broadcast media management systems. You can even change the lens mount! No other broadcast camera is so flexible!

Broadcast Production Camera
The perfect solution for broadcasters, URSA Broadcast G2 includes ENG camera controls positioned around the camera so you can locate them by feel. It also features a low light sensor so you get amazing images using natural light. That's the perfect combination for broadcast news and programming.

Live Studio Camera
URSA Broadcast includes an advanced YRGB color corrector built in and full remote camera control. You can use B4 ENG lenses, large studio box lenses, or even change the lens mount and use any lens! Plus the optional Blackmagic focus and zoom demands let you control the lens from the tripod handles.

Digital Cinema Camera
URSA Broadcast G2 includes an advanced 6K digital film sensor, and you can change the lens mount! Use a PL mount for digital film lenses or EF for photo lenses. Plus the high dynamic range, great low light performance and Blackmagic RAW means you get a true "Hollywood" quality digital film camera.

Compatible with B4 Broadcast Lenses
The URSA Broadcast G2 features a B4 broadcast lens mount that includes optics specifically designed to match the camera’s sensor. The B4 lens mount lets you use modern Ultra HD lenses or lower cost HD lenses. Older HD lenses often feature resolutions well beyond HD, so you get great quality at low cost! B4 lenses are fantastic because they are par-focal, so the image stays in focus as you zoom in and out, so you don't need to constantly chase focus as you shoot. That lets you work much faster! You also get full electronic lens control to adjust focus, iris and zoom using the camera’s controls, or remotely! Plus if you want to use alternative lenses, you can change the mount to PL, EF and more!

Built In Optical ND Filters
URSA Broadcast G2 features high quality neutral density (ND) filters that let you quickly reduce the amount of light entering the camera. The ¼, 1/16th and 1/64th stop filters have been specifically designed to match the image sensor and color science of URSA Broadcast G2, providing you with additional latitude and better colorimetry. This lets you use different combinations of aperture and shutter angle, in a wider range of situations. The IR filters have been designed to evenly filter both optical and IR wavelengths, eliminating IR contamination. Plus the filter status on the LCD can be displayed as a fraction, number, or stop reduction!

Use Common Media and File Formats!
URSA Broadcast is designed to work with standard file formats that are used by all broadcast systems and editing software. You can record in ProRes 422 HQ and ProRes 422 into QuickTime files. The new Blackmagic URSA Broadcast G2 model can even record into H.265 for incredibly small files at 60:1 to 285:1 compression ratios, in 10-bit broadcast quality. Plus you can record to Blackmagic RAW files, a revolutionary new format designed to capture and preserve the quality of the sensor data from the camera. That means you get the perfect range of file formats designed for all types of workflows.

Dual Media Slots for Non‑Stop Recording
With dual CFast 2.0 recorders and dual SD/UHS-II card recorders, you can choose the media that's best for you! Both types of media are standard, inexpensive and readily available at computer and camera stores. Plus with dual media slots, URSA Broadcast gives you non stop recording! When a card is full, recording automatically continues onto the next card so you can swap a full card while recording continues. You get enough speed to record high quality ProRes and H.265 video file formats, even when working in Ultra HD at high frame rates. That means URSA Broadcast G2 is easy to integrate into your existing broadcast systems. You can even record 12-bit Blackmagic RAW cinema files!

Built In SRT and RTMP Live Streaming
Now you can live stream to the world! Blackmagic URSA Broadcast G2 features a built hardware streaming engine that supports both RTMP and SRT streaming protocols so you can go live to YouTube, Facebook, X and more! For internet access, you have two options, one to connect a USB-C to Ethernet adapter or you can connect a 4G or 5G phone for mobile data! Plus if you want to create a wireless link back to the studio, then you can stream to a Blackmagic ATEM Streaming Bridge, which is an H.264 decoder that converts the video stream back to SDI video. Plus the ATEM Streaming Bridge can send full camera control, on air tally and even talkback audio back to the remote camera!

Connect 5G or 4G Phones for Mobile Data
When live streaming, you can connect and use an Apple or Android phone to get a connection to the internet via mobile data. Simply connect the phone to the rear mounted USB-C and Blackmagic URSA Broadcast G2 will configure for mobile data. Plus it works with the latest high speed 5G phones, as well as 4G phones! You can also connect via wired Ethernet by using a USB-C to Ethernet adapter. If you add the Blackmagic URSA Broadcast ENG Kit, then you also get a convenient holder for mounting the mobile phone to the side of the camera. With live streaming built into the camera, you get a truly global live ENG solution that uses common and easy to use mobile phone networks!

Standard Television Industry Connections
Blackmagic URSA Broadcast G2 features the latest technology and connections such as 12G-SDI. This includes 12G-SDI connections for both video output and return program feed input. The 12G-SDI connections are multi rate and switch between all HD and Ultra HD formats up to 2160p60. Other connections include a headphone connection, USB-C, balanced XLR audio with phantom power, and timecode/reference input. There's also a front mounted 12 pin Hirose connector for broadcast lens control which can also power the lens. Plus for connecting a viewfinder or on set monitor there's even an HD-SDI monitoring output and a broadcast style 4 pin XLR 12V DC power output!

Supports All Broadcast Frame Rates
Whether you’re shooting a sporting event or a breaking news story, Blackmagic URSA Broadcast G2 can shoot super smooth, crystal clear slow motion video. To shoot slow motion video, URSA Broadcast supports the higher broadcast frame rates of 60 frames per second, but it can also record this high frame rate into a lower frame rate file, for smooth slow motion shooting. You can set up your preferred high speed frame rate using the camera’s on screen menus, then switch between standard sync speed and off speed frame rates using the HFR button on the side of the camera. That means you can have a higher frame rate setup and ready to go, so its instantly available when the action gets exciting!

Get Studio Camera Control via SDI
All Blackmagic Design ATEM switchers can control cameras via a protocol embedded into the URSA Broadcast G2's SDI video connections. Setup is easy because all ATEM switchers broadcast control commands from the switcher’s SDI program output to the camera via the SDI program input. The switcher can perform color correction, tally and lens control and these are sent to all cameras. All you need to do is select the correct camera number and it all works. This means someone can manage the image color and gain so the camera operator is not distracted trying to adjust their camera, and they are then free to focus on framing the shots.

Change to PL, EF and F Lens Mounts!
URSA Broadcast G2 features an interchangeable lens mount so you can easily swap the included B4 lens mount for an EF, PL or even F mount. URSA Broadcast G2 comes with a B4 mount already installed, plus a spare EF mount is included. That means if you’re starting out you can change the mount and use low cost photographic lenses. Photographic lenses are incredible quality because they're designed for high resolution photography. You can also purchase optional PL and F mounts separately. If you're shooting for digital film, the PL mount is best as it's the most common lens mount for cinema lenses. With URSA Broadcast G2, you get a single camera that works with virtually all modern lenses!

Incredible Blackmagic RAW Quality
Blackmagic RAW is a revolutionary new format designed to capture and preserve the quality of the sensor data from your camera. Common video files have a lot of video processing, so you can lose some of the original sensor detail. Blackmagic RAW eliminates this problem so you get stunning images with incredible detail and rich color throughout the whole post production pipeline. Blackmagic RAW also saves camera settings as metadata so you can change ISO, white balance and exposure later in DaVinci Resolve. Plus the files are small and fast, so editing responsiveness is incredible. Only Blackmagic RAW gives you the highest quality, smallest files and fastest performance!

Built in Timecode Generator
All models of Blackmagic URSA Broadcast G2 have a built in time of day timecode generator, so you can sync all the cameras and then do multi-cam editing later because all the recordings will have the same timecode. Simply plug in an external timecode generator to the BNC timecode input and the camera will automatically detect timecode and lock the internal generator. Now each camera can start and stop recording and the shots from all cameras will have matched timecode. Imagine shooting a music festival with multiple cameras! Then the DaVinci Resolve sync bin can be used to automatically sync the recordings and display them in a multiview for easy editing.

Technical Specifications

Camera Features
Effective Sensor Size: 2/3 inch sensor size when using 4K B4 mount (Actual sensor size 23.10mm x 12.99mm)
Lens Mount: B4 2/3 inch installed , Active EF mount also included
Lens Control: Electronic control via 12-pin broadcast connector. Control via EF mount pins when using URSA Mini Pro EF Mount with compatible EF lenses.
Lens Correction: In-camera correction of color fringing when using compatible broadcast lenses.
Dynamic Range: 13 Stops
Dual Native ISO: 0dB and 18dB gain.
Sensitivity at 0dB Gain: f11 with 2160p59.94. , f12 with 2160p50. at 2,000 lux with 89.9% reflectance. additional 1.1 stop light loss using 4K B4 mount.
Signal to Noise Ratio: 64.62dB for 2160p, Ultra HD scaled from 5.3K
Built in ND Filters: Four position ND filter wheel with clear, 2 stop, 4 stop and 6 stop ND filters.
Focus: Focus button triggers auto focus when using compatible lenses with focus servo. Touch and hold on LCD determines focus region and triggers auto focus.
Iris Control: Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses so no pixel is clipped in film mode. Scene average auto exposure in video and extended video mode.
Screen Dimensions: 4 inch
Screen Type: LCD capacitive touchscreen.
Controls: Touchscreen menus on 4 inch screen. Push buttons for other controls. 3 assignable shortcut keys and 2 assignable shortcut keys (VTR and RET) on compatible broadcast lenses.
ProRes Shooting Resolutions and Frame Rates:
3840 x 2160 (Ultra HD) up to 60 fps from Ultra HD window or scaled from 5.3K windowed sensor
3840 x 2160 (Ultra HD) up to 50 fps scaled from full sensor
1920 x 1080 (HD) up to 120 fps scaled from 2.7K windowed sensor
1920 x 1080 (HD) up to 60 fps scaled from Ultra HD or 5.3K windowed sensor
1920 x 1080 (HD) up to 50 fps scaled from full sensor
H.265 Shooting Resolutions and Frame Rates:
3840 x 2160 (Ultra HD) up to 60 fps from Ultra HD window or scaled from 5.3K windowed sensor
3840 x 2160 (Ultra HD) up to 50 fps scaled from full sensor
H.264 Shooting Resolutions and Frame Rates:
1920 x 1080 (HD) up to 60 fps scaled from Ultra HD or 5.3K windowed sensor
1920 x 1080 (HD) up to 50 fps scaled from full sensor
Blackmagic RAW Shooting Resolutions and Frame Rates:
6144 x 3456 (6K) up to 50 fps
6144 x 2560 (6K 2.4:1) up to 60 fps
5376 x 3024 (5.3K 16:9) up to 60 fps
3728 x 3104 (3.7K 6:5 anamorphic) up to 60 fps
3840 x 2160 (Ultra HD) up to 60 fps
1920 x 1080 (HD) up to 150 fps
Project Frame Rates: 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps. Off-speed frame rates up to 60p in Ultra HD and up to 150p in HD.
Metadata Support: Automatically populated lens data from electronic B4 lenses. Automatic recording of camera settings and slate data such as project, scene number, take and special notes.
Timecode Clock: Highly accurate timecode clock. Less than 1 frame drift every 8 hours.

Connections
SDI Video Inputs: 1
SDI Video Outputs: 1
SDI Monitor Outputs: 1
SDI Rates: 1.5G, 3G, 6G, 12G.
Analog Audio Inputs: 2 x XLR switchable between mic, line and AES digital audio. Phantom power support.
Analog Audio Outputs: 1 x 3.5mm headphone jack, supports iPhone style headset for talkback.
Reference Inputs: Tri-Sync/Black Burst/Timecode.
Lens Control: 1 x 12-pin Hirose Broadcast Lens Connector
Remote Control: 1 x 2.5mm LANC input for Rec Start/Stop, plus Iris and Focus control using compatible lenses.
Computer Interface: 1 x USB Type‑C 3.1 Gen 2 with power delivery for external drive recording and connecting Blackmagic Focus and Zoom Demand. 1 x USB Type‑C for software updates.

Audio
Microphone: Integrated stereo microphone.
Built in Speaker: 1 x mono speaker.

Streaming
Direct Streaming: Blackmagic URSA Broadcast G2 supports direct live streaming using Secure Reliable Transport (SRT) and Real Time Messaging Protocol (RTMP) in H.264 using a USB-C connection to a phone sharing mobile data or a USB-C to Ethernet connection to a local network or the internet.
Streaming Platforms: YouTube (SRT Beta), ATEM Streaming Bridge, ATEM Television Studio HD8 ISO, Facebook, Twitch, YouTube, Twitter, Restream.IO, Vimeo, BoxCast, Castr, Afreeca TV, Bilibili, DouYu, Weibo.

Standards
SD Video Standards: None
HD Video Standards: 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60
Ultra HD Video Standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
SDI Compliance: SMPTE 292M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1 and SMPTE 2082‑10
SDI Audio Sampling: 48 kHz and 24 bit

Media
Media: 2 x CFast 2.0 card slots, 2 x SD UHS‑II card slots, 1 x USB‑C 3.1 Gen 2 expansion port with power delivery for recording to external media.
Media Format: Can format media to ExFAT for Windows and Mac or HFS+ for Mac (file systems).
Media Page: Blackmagic Camera OS includes a Media Page for professional media management and viewing metadata information. Sort clips by duration, frame rate, resolution, codec, media slot, timecode, scene or upload status, plus search all clips, private storage or just clips within specific projects. Preview clips with duration, timecode and file name displayed and use the scrubber for fluid, precise frame control. Select clips to upload and share, and delete clips with a confirmation warning. You can also select multiple clips to batch upload, batch delete or playback in a custom timeline.

Supported Codecs
Codecs:
Apple ProRes 422 HQ,
Apple ProRes 422,
H.265 SDI (10-bit 4:2:2),
H.265 High (10-bit 4:2:0),
H.265 Medium (10-bit 4:2:0),
H.265 Low (10-bit 4:2:0),
H.264 SDI (10-bit 4:2:2),
H.264 High (8-bit 4:2:0),
H.264 Medium (8-bit 4:2:0),
H.264 Low (8-bit 4:2:0),
Blackmagic RAW Constant Bitrate 3:1,
Blackmagic RAW Constant Bitrate 5:1,
Blackmagic RAW Constant Bitrate 8:1,
Blackmagic RAW Constant Bitrate 12:1,
Blackmagic RAW Constant Quality Q0,
Blackmagic RAW Constant Quality Q1,
Blackmagic RAW Constant Quality Q3,
Blackmagic RAW Constant Quality Q5

Control
External Control: Lens control of compatible lenses using Blackmagic Zoom Demand and Blackmagic Focus Demand, Blackmagic SDI Control Protocol, iPad control via Bluetooth, 1 x 2.5mm LANC for lens and record control.

Talkback and Tally
Talkback: SDI Channels 15/16 and iPhone headset.
Live Tally Indicator: Tally on LCD, URSA Viewfinder and URSA Studio Viewfinder.

Storage Features
Storage Type:
2 x CFast 2.0
2 x SD UHS‑II cards
1 x high speed USB‑C expansion port for external media.
2.5 inch SSD using optional URSA Mini Recorder
Storage Rates:
Storage rates based on 30 frames per second.
6144 x 3456 (6K):
Blackmagic RAW 3:1 - 323 MB/s
Blackmagic RAW 5:1 - 194 MB/s
Blackmagic RAW 8:1 - 121 MB/s
Blackmagic RAW 12:1 - 81 MB/s
Blackmagic RAW Q0 - 242 to 483 MB/s
Blackmagic RAW Q1 - 162 to 387 MB/s
Blackmagic RAW Q3 - 108 to 277 MB/s
Blackmagic RAW Q5 - 65 to 162 MB/s
6144 x 2560 (6K 2.4:1):
Blackmagic RAW 3:1 - 240 MB/s
Blackmagic RAW 5:1 - 144 MB/s
Blackmagic RAW 8:1 - 90 MB/s
Blackmagic RAW 12:1 - 60 MB/s
Blackmagic RAW Q0 - 180 to 359 MB/s
Blackmagic RAW Q1 - 120 to 287 MB/s
Blackmagic RAW Q3 - 80 to 205 MB/s
Blackmagic RAW Q5 - 49 to 120 MB/s
5376 x 3024 (5.3K 16:9):
Blackmagic RAW 3:1 - 248 MB/s
Blackmagic RAW 5:1 - 149 MB/s
Blackmagic RAW 8:1 - 94 MB/s
Blackmagic RAW 12:1 - 63 MB/s
Blackmagic RAW Q0 - 186 to 371 MB/s
Blackmagic RAW Q1 - 125 to 297 MB/s
Blackmagic RAW Q3 - 84 to 213 MB/s
Blackmagic RAW Q5 - 51 to 125 MB/s
3728 x 3104 (3.7K 6:5 anamorphic):
Blackmagic RAW 3:1 - 177 MB/s
Blackmagic RAW 5:1 - 106 MB/s
Blackmagic RAW 8:1 - 67 MB/s
Blackmagic RAW 12:1 - 45 MB/s
Blackmagic RAW Q0 - 133 to 265 MB/s
Blackmagic RAW Q1 - 89 to 212 MB/s
Blackmagic RAW Q3 - 60 to 152 MB/s
Blackmagic RAW Q5 - 36 to 89 MB/s
3840 x 2160 (Ultra HD):
Apple ProRes 422 HQ - 110 MB/s
Apple ProRes 422 - 73.6 MB/s
H.265 SDI - 12.3 MB/s
H.265 High - 10.8 MB/s
H.265 Medium - 7.8 MB/s
H.265 Low - 3.2 MB/s
Blackmagic RAW 3:1 - 127 MB/s
Blackmagic RAW 5:1 - 77 MB/s
Blackmagic RAW 8:1 - 48 MB/s
Blackmagic RAW 12:1 - 32 MB/s
Blackmagic RAW Q0 - 96 to 190 MB/s
Blackmagic RAW Q1 - 64 to 153 MB/s
Blackmagic RAW Q3 - 43 to 109 MB/s
Blackmagic RAW Q5 - 26 to 64 MB/s
1920 x 1080:
Apple ProRes 422 HQ - 27.5 MB/s
Apple ProRes 422 - 18.4 MB/s
H.264 SDI - 7.0 MB/s
H.264 High - 5.6 MB/s
H.264 Medium - 3.2 MB/s
H.264 Low - 1.8 MB/s
Blackmagic RAW 3:1 - 19 MB/s
Blackmagic RAW 5:1 - 12 MB/s
Blackmagic RAW 8:1 - 7.8 MB/s
Blackmagic RAW 12:1 - 5.2 MB/s
Blackmagic RAW Q0 - 23 to 47 MB/s
Blackmagic RAW Q1 - 16 to 37 MB/s
Blackmagic RAW Q3 - 10 to 27 MB/s
Blackmagic RAW Q5 - 6 to 16 MB/s

Recording Formats
Apple ProRes 3840 x 2160 and 1920 x 1080 with film, video or extended video dynamic range or custom 3D LUT.
H.265 3840 x 2160 with film, video or extended video dynamic range or custom 3D LUT.
H.264 1920 x 1080 with film, video or extended video dynamic range or custom 3D LUT.
Blackmagic RAW Q0, Q1, Q3, Q5, 3:1, 5:1, 8:1 and 12:1 at 6144 x 3456, 6144 x 2560, 5376 x 3024, 3728 x 3104, 3840 x 2160, 1920 x 1080 recorded in non-linear 12 bit with film dynamic range and extended video, video or custom 3D LUT embedded in metadata.

Software
Software Included:
Blackmagic OS
DaVinci Resolve Studio for Mac and Windows including activation key
Blackmagic Camera Setup
Blackmagic RAW Player
Blackmagic RAW QuickLook Plugin
Blackmagic RAW SDK
Blackmagic RAW Speed Test

Blackmagic Cloud
Compatibility: Blackmagic Cloud and clip sharing features compatible with and DaVinci Resolve 18.6 or later.
Sharing: Integrated Login to Blackmagic Cloud for sharing to a DaVinci Resolve project.
Automatic Media Sharing: Captured media automatically uploads to a Blackmagic Cloud DaVinci Resolve project.
Manual Media Sharing: Select recorded clips or files manually share to a Blackmagic Cloud DaVinci Resolve project.
Upload Clips: Proxies Only or Originals and Proxies.

Power Requirements
Power Supply: 1 x External 12V DC 100W power supply with 100 - 240V AC 50/60Hz IEC C14 input.
External Power Input:
1 x 4-pin XLR port for external mains power supply or battery use.
1 x 12-pin Molex connector under rear battery plate.
Power Output:
+12V 4-pin XLR regulated output on side of camera
+12V D-Tap regulated output on VLock battery plate
Power: Rear camera mount compatible with industry standard V-mount or gold mount battery plates.

Accessories
Optional Accessories:
Blackmagic URSA Viewfinder
Blackmagic URSA Studio Viewfinder
Blackmagic Camera Fiber Converter
Blackmagic Studio Fiber Converter
Blackmagic URSA Mini Pro PL Mount
Blackmagic URSA Mini Pro F Mount
Blackmagic URSA Mini Mic Mount
Blackmagic URSA Mini Recorder
Blackmagic URSA Gold Battery Plate

Environmental Specifications
Operating Temperature: 0° to 40°C (32° to 104°F)
Storage Temperature: -20° to 45°C (-4° to 113°F)
Relative Humidity: 0% to 90% non-condensing

What's Included:
Blackmagic URSA Broadcast G2
4K B4 lens mount installed
B4 turret dust cap
EF Mount with dust cap
VLock Battery Plate installed
URSA 12V 100W power supply
URSA Mini Shoulder Pad
URSA Mini top handle & rubber stopper
Viewfinder mounting plate
2 x 1/4 inch baseplate screws
2 x long 1/4 inch top handle screws
2 x short 1/4 inch top handle screws
8 x EF Mount screws
4 x VLock plate spare screws
Welcome wallet with QR code for camera software download
DaVinci Resolve Studio wallet
DaVinci Resolve Studio activation key

Warranty: 1 Year Limited Manufacturer’s Warranty.
