Convert SDI to HDMI with Audio De-Embedding Options
The DAC-8PA allows you to convert an SDI signal (up to 1080p60) to HDMI. It includes the option to de-embed audio to a stereo RCA output.

Supports 1080p 50/60
Automatic input signal and color depth detection with support for Deep Color.

Supports SDI Loop-Through Output
Simultaneous SDI loop-through with HDMI output

Aluminum Alloy and Heavy Duty Design
Super sturdy and durable. The DAC series has a rugged metal housing for use in even the roughest conditions. Low heat dissipation, ideal for long hour operation in normal ventilated environment.

Model Number: DAC-8PA
Conversion: 3G/ HD/SD-SDI to HDMI
Video Inputs: 1x 3G/HD/SD-SDI
Loop Through: 1
Video Outputs: 1x HDMI audio embedded
Audio Inputs: 2x SDI audio embedded
Audio Outputs: 2x RCA (Stereo)
Supported Video Input Formats: 1080p (23.98/24/25/29.97/30/50/59.94/60Hz), 1080i (50/59.94/60Hz), 720p (50/59.94/60Hz), 625i 50 (PAL), 525i 59.94 (NTSC)
Output Resolutions: Automatically matches the SD, HD and 3G SDI video input
Equalizer: Yes
Reclock: Yes
SDI Cable Drive: Yes
Updates and Configuration: Mini USB x 1
Dimension (LxWxH): 112 x 85 x 45 mm
Weight: 0.4 kg
Operating Temp. Range: 0~40 °C
Power: DC 12V, 4W
What's in the Box: 1 x DAC-8PA product , 1 x AD Switch DC 12V
