The PTZOptics 12X-USB is a 1080p camera with 12X optical zoom for capturing both wide angles and long shots. With support for USB 3.0, HDMI, and IP streaming (H.264, H.265, & MJPEG), this camera is ideal for broadcasting high definition video signals for broadcast, recording, or video conferencing applications.
Versatile Control Options and Live Streaming Remote camera control options when and where you want them. Use PTZ controls built-in to your favorite video production software such as OBS, Livestream Studio, Wirecast, vMix, mimoLive or Tricaster. Or check out one of our hardware joystick controllers such as our IP joystick, serial joystick, or the SuperJoy. Try our free IP control application for Mac or PC, our open-source control software on GitHub, and our OBS plugin.
Discreet Mounting Options Mount your PTZ camera above, below or beside the action to capture the ideal view every time. PTZ mounts: Wall Mounts Ceiling Mounts Pole Mounts Outdoor Enclosures
Build your PTZ Camera System Our plug-and-play USB 3.0 camera models are built with ease of use and compatibility in mind, featuring game-changing optics and video communication installation options. USB connectivity is now available with options for HDMI and IP streaming in the latest USB PTZ cameras from PTZOptics. The combination of robust high-definition video outputs and flexible camera control options are what makes this camera powerful. Realize the value of connecting this camera to any application, and enjoy the advanced camera control options which include iOS, Android, PTZ controllers, joysticks and more.
KEY FEATURES • 72.5 degree wide-angle lens. • High performance in low light scenarios with Wide Dynamic Range. • Full 1920x1080p HD Resolutions up to 60 frames per second. • 2D and 3D noise reduction with our latest “low noise CMOS sensor”. • UVC 1.5 (USB), RS232 & RS485 (Serial), and IP (LAN/WAN) control • H.264, H.265, & MJPEG Streaming over RJ-45 LAN port • HDMI, USB 3.0, & IP streaming (all 3 simultaneously) • RTMP & RTSP IP streaming • 5-year warranty • Photobooth capable
WHAT’S IN THE BOX 12X Zoom USB 3.0 Camera Power Adapter + Cord USB 3.0 Cable IR Remote Control RS-232C Cable Quick Start Guide (2) AAA Batteries
Camera & Lens Video Sensor 1/2.7” CMOS, 2.12 Mega Pixels Frame Rates 1080p-60/50/30/25, 1080i-60/50, 720p-60/50/30/25 Frame Rates (CVBS) 576i-30, 480i-30 Focal Length 12x, F3.5mm-42.3mm, F1.8-F2.8 Lens Zoom 12x Field of View 72.5° Min Lux 0.05 Lux (@F1.8, AGC ON) Shutter Speed 1/30s - 1/10000s SNR ≥55dB Vertical Flip & Mirror Supported Horizontal Angle of View 6.9° (tele) to 72.5° (wide) Vertical Angle of View 3.9° (tele) to 44.8°(wide) Working Environment Indoor Pan & Tilt Movement Pan Movement ±170° Tilt Rotation Up: 90°, Down: 30° Presets 10 via IR (255 via Serial or IP) Rear Board Video Output HDMI, USB 3.0, IP Streaming, CVBS Network Interface RJ45 Audio Interface Line In, 3.5mm (USB & IP Stream Only) Communication RS-232, RS485, PELCO-D/P, UVC 1.5 Baud Rate 2400/4800/9600 bits Power Supply JEITA type Power Adapter (DC IN 12V) USB 3.0 Interface USB 3.0 (Requires Quad Core Processor) USB 2.0 Interface Future Use Electrical Index Power Supply 12W (Max) Input Voltage 12V DC (10.8 - 13.0V DC) Physical Specifications Dimensions (mm) 142W x 164H x 160D (198H max w/ Tilt) Box Dimensions 9”x9”x10”|229mmx254mmx229mm Camera Weight 3.15 lbs. (1.43 kg) Boxed Weight 5.4 lbs. (2.45 kg)
