Introducing the new SuperJoy Joystick Controller supporting Network and Serial Camera Control. Experience the full capabilities by pairing it with PTZOptics or HuddleCamHD cameras.

Create a Powerful, Precise and Versatile Production Experience
Introducing the PTZOptics SuperJoy, a PTZ camera joystick controller designed for smooth, efficient production workflows. The SuperJoy takes remote pan, tilt, and zoom camera operations to the next level in a simplified user interface with advanced controls for power users. The SuperJoy offers an intuitive, tactile interface, simplifying and streamlining even the most complex production setups.

SuperJoy’s HDMI video output provides a 1080p video preview for any camera connected to the SuperJoy that has an RTSP video feed available for use. This HDMI video output is ideal for viewing cameras over a local area network. In this way, a SuperJoy controller can be set up anywhere on a network to gain PTZ camera controls with a low-latency, live video preview.

Ergonomic, rubberized controls and pressure-sensitive dials for precise, on-the-fly-tuning, with no OSD adjustments required

Status-responsive backlit buttons and knobs indicate available camera modes, while optional tablet/computer control can allow for remote monitoring

Custom Control Across a Variety of Cameras and Devices
The PTZOptics SuperJoy Joystick Controller is a comprehensive solution supporting mix-and-match serial and network-based control for PTZ cameras of any generation.

Simultaneous pan, tilt and zoom control across IP, NDI® and serial cameras from multiple brands including PTZOptics, HuddleCamHD, Sony, BirdDog, and NewTek

If it’s IP-controlled, chances are the SuperJoy can control it – cameras, lights, projector screens and more – using four customizable buttons

Powerful Super-Preset buttons are programmable to trigger synchronized multi-preset commands across up to five unique camera groups with up to eight cameras each

Main Features
● Durable metal housing
● PTZOptics VISCA over IP & Serial control
● Limited NDI & Sony control
● PTZOptics Camera On Screen Display control
● Full Pan / Tilt / Zoom camera control
● PTZ, Focus, and Preset Speed Adjustment on the fly
● 5 Camera Control Groups
○ Groups 1-4 limited to 7 cameras
● 255 camera presets, 9 Quick presets
● 4 Customizable buttons (TCP, UDP, & HTTP)
● Fine tune zoom & focus control dials
● Buttons glow / flash when available
● RTSP Decoder via HDMI
● PTZOptics Focus Lock & Unlock
● Large LCD screen with controller status
● Import / Export settings via network & USB
● 2-Year warranty

What’s in the box?
● PT-SUPERJOY-G1 Joystick Controller
● 12V 2A DC International Power Supply
● RS-232C | DB9 to 8-pin mini-din cable
● PT-SUPERJOY-G1 Quick Start Guide
● Grounding Pin

Technical Specifications
Connections RS-232, RS-485, RS-422, RJ-45
Control Protocols VISCA, VISCA over IP, PELCO-D, PELCO-P, Sony, & NDI
Max Cameras 253 cameras total (Cam Groups 1-4: 7 channels Cam Group 5: 225 channels)
Recommended Max Distance RS-232 / RS-422: 50 ft | 15m, RS-485: 3,937 ft | 1200m, Ethernet: 328 ft | 100m
Baud rate 1200 ~ 19200 bps
Operation Specifications
Power 6W | 12VDC / PoE (802.3af) (Only use one (1) power source at a time.)
Working Temp 14° F ~ 122° F | -10° C ~ +50° C
Working Humidity 10% ~ 90% (non-condensation)
Weight 3.75 lbs | 1.70 kg
Dimensions (mm.) 370 W x 180 D x 101 H
