Key features:
4/3" CMOS 4K 160 FPS Max
3G-SDI + HDMI Connectivity
BNC Connector Timecode Interface
Built-in Gyroscope Sensor
PoE+ Power Over Ethernet
Genlock
Mini V-Lock Battery Plate
CF Express Type B Storage Media Slot

Probably the Most Versatile Camera
You might not have seen the Z CAM E2 at these venues, but you've likely watched the stunning images captured by it.

Multiple Camera Synchronization
Z CAM has been widely adopted in many multiple camera applications worldwide due to its high sync precision, open API and reliability.

Z CAM EzLink Sync
All cameras are connected to a network switch for Z CAM EzLink Sync.
Once connected, one camera must be designated as the master, with the others set as slaves.
Z CAM EzLink ensures precise synchronization, maintaining a tolerance of no more than 0.5ms.

Z CAM PixelLink*
Z CAM PixelLink Sync (Master/Slave) requires all cameras to be connected in a daisy chain using Z CAM sync cables.
Cameras are interconnected using Cat 6 Ethernet cables.
Ensuring perfect line sync precision.
* Only available on Z CAM E2 model

IP Streaming is the Future
Z CAM supports a number of streaming protocols. Easily accessible through the built-in web client.

Open API & SDK
Full set open API.
Facilitates easier secondary development.

Compact & Robust
Compact form factor.
Full metal body construction.
Weighted 1060g only*.
* measured on Z CAM E2-M4 Mark II model (without lens and battery)

Durability & Reliability
Both the Z CAM E2 and the Z CAM E2 Mark II series are engineered for sustained, long-term recording and streaming.
Fanless design. No active cooling.

Interchangeable Mounts
Z CAM E2-M4 Mark II : MFT Mount (Active Lock)

Optional Z CAM Interchangeable lens mount:
Z CAM PL Mount (Active Lock)
Z CAM LPL Mount (Active Lock)
Z CAM M Mount (Active Lock)

Stunning Image Quality
Go-to camera for many big film and documentary productions.
Entrusted by many well-known DOPs and Directors.
Qualified as A camera.
Perfect for B camera.

Technical Specifications

Camera
Sensor Type: 4/3" CMOS Sensor
Sensor Size: 19.0 x 13.0 mm (Diagonal 21.63mm)
Effective Pixels: 10.71M
Dynamic Range: 13~15 Stops (Z-Log2) / 16 Stops (with WDR activated)
Lens Mount: MFT Mount w/active lock (interchangeable)
Microphone: Built-in Stereo Microphone

Recording
Resolution & Max Frame Rate:
30fps max @ C4K Low Noise (4096x2160)
120fps max @ C4K (4096x2160)
150fps max @ C4K 2.4:1 (4096x1728)
30fps max @ 4K Low Noise (3840x2160)
120fps max @ 4K (3840x2160)
160fps max @ 4K 2.4:1 (3840x2160)
30fps max @ 3696x2772 Low Noise
60fps max @ 3696x2772
60fps max @ 3312x2760
170fps max @ S16 16:9 (2752x1548)
160fps max @ S16 (2704x1600)
240fps max @ 1920x1080
Video Encoder: H.264 / H.265 / ProRes 422 Proxy / ProRes 422 LT / ProRes 422 / ProRes 422 HQ / ZRAW*
RAW over HDMI: ProRes RAW (using Atomos Ninja V); BRAW (using BMD VideoAssist)
Color Bit-depth: 10-bit 4:2:0 (H.265) / 8-bit 4:2:0 (H.264)
Audio Format: 16-bit 48 kHz
Audio Encoder: AAC / PCM (for MOV only)
File Format: MOV / MP4
Record Mode: Video / Time Lapse Video / Still Image Capture

Settings
ISO: Auto, Manual (500 ~ 102400), Dual Native ISO: 500 / 2500
Shutter: Shutter Speed: Auto, Manual (1”~ 1/8000”) Shutter Angle: Auto, Manual (1° ~ 360°)
White Balance: Auto, Preset, Manual (2300K ~ 30000K)
Focus Mode: MF / AF / CAF
Image: Brightness / Contrast / Saturation / Sharpness / Gamma Setting
Image Config: Rec.709, Z-Log2, Flat, Concert, Vivid 0, Vivid 1, Vivid 2, HLG, Gamma
Time Code: Current Time / Manual Input / External Input

Connectivity
HDMI: HDMI 2.0 Type A (up to 4K DCI 60p, 10-bit 4:2:2)
SDI: 3G-SDI
Timecode In: LTC Timecode Input via BNC
Genlock: BB/Tri-Level Genlock Input via BNC
USB: USB 3.0 Type C for camera control & data transfer only
Remote Port: 2.5 mm jack socket (Sony LANC compatible)
Audio In: 3.5 mm stereo jack socket (TRS) or 5-pin LEMO port for dual channel XLR microphone (require additional XLR audio connector)
Audio Out: 3.5 mm stereo jack socket
Wi-Fi: 5G, up to 802.11n, external antenna port
CTRL: Serial port
Ethernet: Gigabit Ethernet port

Power
Battery: Mini V-Lock 14.8V (Battery not included)
Power Input: DC 12~18V (2-pin LEMO socket) / PoE+ (802.3at)
Power Output (AUX): DC 12V 2A (2-pin LEMO socket)
Power Consumption: 50W maximum, not inclusive of AUX power consumption

Physical
Camera Body: Aluminum Alloy
Weight - Camera (w/o Lens): 1.06 kg (with MFT mount)
Weight - Full Package: 1.40kg
Dimensions (HxWxL) - Camera: 105 x 98 x 116 mm / 4.13 x 3.86 x 4.57 inch (MFT mount)
Dimensions (HxWxL) - Package: 145 x 195 x 162 mm / 5.71 x 7.68 x 6.38 inch

Environment
Storage Temperature: -20 °C ~ 60 °C
Operation Temperature: 0 °C ~ 40 °C
