Small in size, big on features. With new best in class latency at under 50ms, the CineView SE can transmit a video source via SDI & HDMI up to 1080p 60fps inputs/outputs. It transmits the signal on 2.4GHz+5GHz Dual-Band frequencies simultaneously for increased signal stability and sends video at an impressive maximum range of 1200ft line-of-sight.

CineView SE
Small in size, big on features. With new best in class latency at under 50ms, the CineView SE can transmit a video source via SDI & HDMI up to 1080p 60fps inputs/outputs. It transmits the signal on 2.4GHz+5GHz Dual-Band frequencies simultaneously for increased signal stability and sends video at an impressive maximum range of 1200ft line-of-sight.

Market proved wireless stability.
The CineView SE utilizes dual-band transmission technology, which allows it to stream video via 2.4GHz and 5GHz Wi-Fi at the same time. The receiver can then intelligently identify interference and combine the two streams to form the complete audio and video stream.

BREAKTHROUGH Superlow. Superfar.
The CineView SE is the most powerful model ever created for a faster, more responsive feel. Add to that a strong and powerful enough signal that can transmit up to 1200ft distance.

CONNECT Everything you need.
The TX and RX feature both HDMI and SDI connections that support 1080p video inputs at up to 60fps.

DESIGN Compact and lightweight. Easy to rig.
Rugged design with a 1.3-inch OLED display that fits in the palm of your hand. The solid aerospace-grade aluminum construction keeps the weight of the units down to a minimum.

PRO POWER Lower power draw for longer shootings.
Choose between an NP-F style battery, a DC input port (7.4V~16.8V) as well as a USB-C power source (5V).

SILENT COOLING No noise at all
Seriously, you won’t hear any noise. And it’s very COOL.

VIEW Monitoring as you like
Enjoy monitoring on up to 4 different devices.
Dedicated Receiver Monitor
Android Phone, iOS iPad, IMac Macbook (M1)

SPECIFICATIONS
CineView SE Details

Projects Transmitter
Video Input SDI/HDMI
SDI Input Format 1080p 23.98/24/25/29.97/30/50/59.94/60fps Level A/B
HDMI Input Format 1080p 23.98/24/25/29.97/30/50/59.94/60fps
DC Port 5.5mmx2.1mm center positive
DC Voltage 7.4~16.8V
Audio 44.1KHz/48KHz 16bit/24bit PCM
Latency <0.05s (Camera latency not included)
OLED Display 1.3inch
Transmission Power 17~20dBm
Transmission Range 350m (No obstacles, no interference)
Power Consumption 4.5Watt (Typical)
Operating Environment Temperature -10~40℃
Dimensions 105mmx66mmx32mm (Antennas not included)
Weight 210g (Antennas not included)
