BirdDog 4K SDI Streaming NDI Encoder
BD-BD4KSDI
Price: €1,069.00
No tax
We offer EU-wide sales, invoicing for VAT-free intra-community delivery.
BirdDog 4K SDI puts full-bandwidth NDI® into the heart of UHD production pipelines, delivering visually-lossless I-frame video up to 2160 p60. Its custom silicon sits inside an aircraft-grade aluminium 135 × 85 × 25 mm chassis that weighs just 260 g. Twin 12G-SDI connectors—switchable as input or loop-out—partner an HDMI 2.0 port for 4 : 2 : 2 10-bit monitoring, while the built-in cross-converter routes any SDI feed to HDMI to keep patch panels tidy.
The unit encodes or decodes at up to 360 Mb/s over the on-board Gigabit NIC, and an open SFP+ cage unlocks 1–10 GbE fibre for latency-free REMI or OB workflows. PoE+ 802.3at or 12 V DC power options, a four-line OLED, and an embedded web GUI streamline deployment, while the free RESTful API exposes diagnostics and control endpoints for facility automation.
Embedded 2-ch 48 kHz audio travels on SDI, HDMI and NDI and is complemented by a 3.5 mm Comms port for intercom. A bi-colour tally lamp plus user-selectable tally borders give talent instant on-air feedback. USB-to-Ethernet adapters enable VISCA-over-IP or NDI|HX PTZ control, so BD4KSDI can double as a compact RCP.
Built for trucks, studios and fly-packs, the fan-free aluminium enclosure keeps weight and noise to a minimum. Central 2.0 software allows effortless NDI distribution or decode, and USB ISO-recording plus firmware updates preserve long-term value in fast-moving IP workflows.
UE Shipping
We ship all over the European Union for €20, free shipping on orders over €1,000.
B2B Shop
Our offer is aimed only to B to B Customers, all prices are exclusive of tax.
Secure checkout
Secure online payments via Stripe.
Individual quotation
Send your enquiry via the form or email avgear@avgear.shop
4K SDI
1x HDMI 2.0 Output
1x 12G SDI Input or Output
1x 12G SDI Input or Output
Next Level NDI® Tools.
Following on from the award winning HD NDI® products, the 4K Family has been engineered from the ground up for real-world users. Built around BirdDog’s custom NDI® silicon chip and housed in an aircraft grade aluminium case, features include 12G SDI and HDMI 2.0 inputs and outputs, built-in cross converter, SFP+ port for 10GbE connectivity, active loop outs, audio intercom system, NDI® tally system, PoE, and compatibility with BirdDog’s Comms Pro and Central Pro apps.
Encode & Decode up to 4Kp60.
With support for all resolutions up to 4Kp60, including all HD resolutions, Encoding and Decoding 4K Full NDI® has never been easier.
12G & HDMI 2.0 connections.
All SDI connectors on the 4K line are 12G SDI, including all four SDI connectors on 4K Quad. All the HDMI connectors are 2.0 for maximum compatibility with your sources and destinations. The HDMI port is not enabled on QUAD.
SFP+ for 10GbE & long range.
Industry standard SFP+ connection allows for short, medium, and long range connections over fiber and supports Ethernet protocols from 1GbE to 10GbE.
NDI Tally that just works.
A full Tally system is built right into the 4K Family and it requires zero configuration. Includes a built-in large Tally light for your on-air talent to easily see which camera is live, plus user selectable Tally borders on loop out.
Cross Converter.
4K SDI and 4K HDMI include a built-in cross converter and any of the 12G SDI inputs can be looped out the HDMI 2.0 port and any of the HDMI 2.0 inputs can be looped out the 12G SDI. This function is not available in QUAD.
RESTful API. DIY automation.
Download the free BirdDog RESTful API and program your own automation for all BirdDog hardware endpoints, including cameras.
Distribute NDI® content everywhere. Just add Central 2.0.
BirdDog Central 2.0 is a software platform set to redefine the way we think about driving content to TV screens. By teaming up Central 2.0 with any NDI® source, including all BirdDog hardware capable of creating NDI® sources, you can now drive your NDI® streams to any BirdDog Studio NDI, Mini or 4K Family to decode NDI® back to SDI or HDMI.
4K SDI – Tech Specs
SUPPORTED VIDEO FORMAT
UHD 3840x2160: 23.98, 24.00, 25.00, 29.97, 30.00, 50.00, 59.94, 60.00
HD 1920x1080p: 23.98, 24.00, 25.00, 29.97, 30.00, 50.00, 59.94, 60.00
HD 1920x1080i: 50.00i, 59.94i
HD 1280x720p: 50.00p, 59.94p, 60.00p
VIDEO I/O CONNECTIVITY
12G SDI 2.0 Input: ✔
HDMI 2.0 Output: ✔
12G SDI Output: ✔
AUDIO INPUT
SDI: 2Ch, 48kHz
3.5mm AUDIO: Microphone (BirdDog Comms)
AUDIO OUTPUT
HDMI: 2Ch, 48kHz
SDI: 2Ch, 48kHz
3.5mm AUDIO: Stereo Headphone (BirdDog Comms)
VIDEO CODEC SUPPORT
NDI (Full bandwidth i-frame compression): ✔
DISPLAY
Integrated 4-line OLED Status Display: ✔
TALLY
Onboard Bi-color Tally indicator: ✔
Selectable Tally indicator on video loop outputs: ✔
NETWORK CONNECTIVITY
Ethernet RJ45 1000baseT w/integrated PoE (Power over Ethernet): ✔
Open SFP+ Cage (10gb SFP+ Adapters sold separately): ✔
Embedded Web configuration Panel: ✔
WEIGHTS & DIMENSIONS
Size: 135x85x25mm
Weight: 260g
POWER
DC Input: DC 12v / 16w
PoE (Power over Ethernet): PoE+ 802.3at
BD-BD4KSDI
5 Items
Data sheet
- Video Input
- SDI
- Video Output
- HDMI
NDI
SDI - Audio Input
- Mini Jack 3.5mm
SDI Embedded - Audio Output
- HDMI Embedded
Mini Jack 3.5mm
NDI Embedded
SDI Embedded - Max Output Resolution
- 4K UltraHD (3840 x 2160) 50/60 fps
- Output colour sampling
- RGB 4:2:2 10-bit
- Built-in scaler
- No
- Max bitrate
- 360Mbps
- Streaming protocols
- NDI
- Network Connection
- Ethernet
Specific References
- ean13
- 9354873000041
- mpn
- BD4KSDI
