REVOLUTIONARY PERFORMANCE ACROSS MULTIPLE SCREENS
BrightSign XC5 is in a category of its own that outperforms signage PCs with ease. Two models offer differing levels of HTML5 performance, both offer stunning 8K and a complete set of connectivity options. From 4-screen video walls to blazing-fast 3D Web GL applications, XC5 does it all. Crafting video wall and multi-screen presentations are significantly streamlined with multi- output players and our BrightWall feature. With multiple HDMI outputs, stellar HTML5 performance and stunning 8k video, XC5 is the most powerful player BrightSign has ever created.

Features
• Revolutionary HTML5 performance
• Discover ultra-smooth motion graphics rendered at incredibly high framerates
• Interact with highly responsive multi-touch HTML5 animations
• Runs intense CSS animations, 3D WebGL & JavaScript
• Experience significantly accelerated content load times
• Streamline video walls & multiple screens with a single multi-output player • Offers stunning 8K video & graphics
• Performs hardware accelerated 4K video rotation
• Runs BrightSign OS to boost reliability, security & uptimes

Power with Purpose
HTML Performance that exceeds a signage PC.
Ultra-smooth motion graphics at incredibly high frame rates
Highly responsive multi-touch HTML5 animations
Runs intense CSS, 3D WebGL and Javascript
Delivers significantly accelerated content load times

8K Content Engine
Delivers brilliant 8K video to a single display.
Delivers industry-best 60p, 8-bit decoding
Displays full resolution graphics and video in 8K
Supports common and custom display resolutions
Optimized storage with cutting-edge video codecs

Multiple HDMI Output
2 HDMI Outputs
Single player drives 2 screens at once

Elite HTML Performance
5x more Graphics Power
Full OpenGL Support
Chromium-based Platform

Elite 8K Content
Single 8K60p 8-bit video decoding
Dual 4K60p video decoding
Stunning 8K graphics & HTML
Native 4K video rotation to portrait mode

The XC5 Lineup
Experience the unparalleled performance of BrightSign XC5, surpassing signage PCs effortlessly. Choose from two models that deliver varying levels of HTML5 performance and support stunning 8K resolution, along with a comprehensive range of connectivity options. Whether it’s 4-screen video walls or high-speed 3D Web GL applications, XC5 excels. Simplify the creation of video walls and multi-screen presentations with multi-output players and the innovative BrightWall feature. Equipped with multiple HDMI outputs, outstanding HTML5 performance, and breathtaking 8K video capabilities, XC5 stands as BrightSign’s most powerful player ever.

MODEL XC4055
VIDEO & HTML5 ENGINES
Single 8K60p video decoding X (8-bit)
4K60p video decoding Dual (8-bit)
HDR10, HLG & Rec.2020/BT.2020 Support
4K video rotation
8K Full Resolution Graphics
HTML5 Performance Elite 5x more powerful
HTML: Full OpenGL Support

MEDIA FORMATS
HTML5: .html, Chromium-based, CSS, JavaScript, WebGL
8K video codecs: H.265
8K Video Containers: .ts, .mov, .mp4, .mkv
4K Video codecs: H.265, H.264
4K Video Containers: .ts, .mov, .mp4, .mkv
Full HD Video Codecs: H.265, H.264 (MPEG-4, Part 10), MPEG-2
Full HD Video Containers: .ts, .mpg, .vob, .mov, .mp4, .m2ts
Images: BMP, JPEG, PNG up to 8K resolution X X
Audio: MP2, MP3, AAC and WAV (AC3 is passed through)

DISPLAY RESOLUTIONS
Supports all common screen resolutions up to 8K (7680x4320 @60fps)
Supports customizable display resolutions with unique aspect ratios

HARDWARE INTERFACES
HDMI outputs 2
HDMI 1 Out (HDMI 2.1a)
HDMI 2 Out (HDMI 2.0a)
HDMI inputs Not Applicable
USB Type C port: supports high-speed host mode & provides 5V/1A power to peripheral devices: 1
USB Type A port: provides 5V/1A power to peripheral devices: 1
12-pin Phoenix GPIO port with 8 bi-directional GPIOs
3.5mm RS-232 Serial Port
3.5mm IR In/Out
3.5mm Audio Out (analog & SPDIF digital)
Gigabit Ethernet
Primary Storage: External micro SD slot protected by a new tool-less cover
Optional Storage: M.2 PCIe for NVMe SSD
Optional Wi-Fi/Bluetooth: E Key M.2 Interface only for WD-105 module
4 Status LEDs
Reset and Service Buttons
Real Time Clock 14-day life
Locking Power Connector

SOFTWARE & SERVICES
Free BrightAuthor:connected Software
BSN.cloud

ACCESSORIES
BP200 & BP900 USB Button Pads
WD-105 Dual Antenna Wireless/Bluetooth Module
MicroSD Class 10 Cards (various capacities)
256GB PCIe NVMe M.2 SSD

MISCELLANEOUS
Power Supply 19V / 4.7A
Dimensions (W x D x H) 253.2 x 232.12 x 48mm
Multi-Country Power & Regulatory Approvals
Built-in Wall Mounting
1 Year Warranty, parts and labor*
*2 year warranty, parts and labor, for units shipped from an EU or UK distribution center and to an EU or UK address.
