The Osprey Video Raptor 916 Capture Card offers a high-quality solution for professionals requiring reliable video and audio capture. This PCIe 2.0 x4 card features a single 3G-SDI input, supporting a wide range of video formats:
• 525i59.94 NTSC
• 625i50 PAL
• 720p at frame rates from 23.98 to 60 fps
• 1080psf at frame rates from 23.98 to 30 fps
• 1080p at frame rates from 23.98 to 60 fps
• 1080i50, 59.94, and 60
The card supports 8-bit color depth with various color spaces, including 4:2:2 (UYVY, YUY2, NV16, NV61), 4:2:0 (I420, NV12, NV21, YVU9, YV12), and 4:4:4 (RGB15, RGB24, RGB32, BGR24, BGR32). It also captures up to 16 embedded audio channels per SDI input at a 48 kHz sampling rate with 24-bit depth. Compliant with SMPTE standards 259M, 292M, 296M, 372M, 424M, 425M, and 435M (3G-SDI Level A only), the Raptor 916 ensures compatibility across various broadcast environments. The card’s dimensions are 6.60 inches in length by 2.71 inches in height (16.76 cm x 6.88 cm), fitting into half-height slots, and it includes both full-height and half-height PCI brackets for flexible installation. With a power consumption of approximately 5W, it is energy-efficient for continuous operation. For demanding environments, a rugged version is available, featuring an extended operating temperature range of -20°C to 60°C and protective coatings suitable for high humidity or outdoor applications.
Osprey Video Raptor 916 Capture card
VS-OS-95-00500
Price: €869.00
No tax
We offer EU-wide sales, invoicing for VAT-free intra-community delivery.
Out of stock (Delivery time to be confirmed.)
The Osprey Video Raptor 916 Capture Card offers a high-quality solution for professionals requiring reliable video and audio capture. This PCIe 2.0 x4 card features a single 3G-SDI input, supporting a wide range of video formats:
• 525i59.94 NTSC
• 625i50 PAL
• 720p at frame rates from 23.98 to 60 fps
• 1080psf at frame rates from 23.98 to 30 fps
• 1080p at frame rates from 23.98 to 60 fps
• 1080i50, 59.94, and 60
The card supports 8-bit color depth with various color spaces, including 4:2:2 (UYVY, YUY2, NV16, NV61), 4:2:0 (I420, NV12, NV21, YVU9, YV12), and 4:4:4 (RGB15, RGB24, RGB32, BGR24, BGR32). It also captures up to 16 embedded audio channels per SDI input at a 48 kHz sampling rate with 24-bit depth. Compliant with SMPTE standards 259M, 292M, 296M, 372M, 424M, 425M, and 435M (3G-SDI Level A only), the Raptor 916 ensures compatibility across various broadcast environments. The card’s dimensions are 6.60 inches in length by 2.71 inches in height (16.76 cm x 6.88 cm), fitting into half-height slots, and it includes both full-height and half-height PCI brackets for flexible installation. With a power consumption of approximately 5W, it is energy-efficient for continuous operation. For demanding environments, a rugged version is available, featuring an extended operating temperature range of -20°C to 60°C and protective coatings suitable for high humidity or outdoor applications.
UE Shipping
We ship all over the European Union
B2B Shop
Our offer is aimed only to B to B Customers, all prices are exclusive of tax.
Secure checkout
Secure online payments
Individual quotation
Send your enquiry via the form or email avgear@avgear.shop
1 Channel 3G-SDI
8-bit Color Depth
16 Audio Channels
CEA-608, CEA-708 Closed Caption Support
Video Formats
525i59.94 NTSC, 625i50 PAL
720p23.98, 24, 25, 29.97, 30, 50, 59.94, 60
1080psf 23.98, 24, 25, 29.97, 30
1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60
1080i50, 59.94, 60
SDI Compliance
SMPTE 259/292/296/372/424/425/435 (3G-SDI Level A only)
SDI Metadata Support
CEA-608, CEA-708 for closed captioning
SDI Color Spaces 8-bit
4:2:2 - UYVY, YUY2, NV16, NV61
4:2:0 – I420, NV12, NV21, YVU9, YV12
4:4:4 – RGB15, RGB24, RGB32, BGR24, BGR32
Multiple Rate Support
Video Format Auto Detect
SDI Audio Inputs
Embedded 16 Channels (8 Stereo) per connection
Audio Sampling
Television standard sample rate of 48 kHz at 24-bit
Connections
Video Inputs Full Size-BNC
PCIe 2.0 x4
Power Consumption
~ 5W
Warranty
2 years
Compliance
CE, FCC, RoHs, REACH
In the Box
Capture Card with Full Height Bracket
Half Height Bracket
Environmental Specifications
Operating Temperature 0 to 40C
Operating Temperature 0 to 60C for Rugged Version
Non-Operating Temperature -40 to 75C
Operating Humidity Range 5% to 80% (non-condensing)
Operating Humidity Range Rugged 5% to 95% (non-condensing)
Operating Altitude Range 0 to 20,000ft
Non-Operating Altitude Range 0 to 50,000ft
VS-OS-95-00500
Data sheet
- Video Input
- SDI
- Video Output
- PCIe
- Audio Input
- SDI Embedded
- Audio Output
- PCIe
- Interface
- PCIe
- Max Output Resolution
- 1080p 50/60 fps
- For Operating System
- Linux
Windows - Output colour sampling
- RGB 4:4:4 8-bit
- Video input channels
- 1
Specific References
- ean13
- 850189006757
- mpn
- 95-00500
