HuddleCamHD 3XA Conference Camera with a Built-in Microphone Array
The HuddleCamHD 3XA is ideal for small to medium sized meeting rooms. This camera is compatible with every system that accepts USB cameras.
USB Conference Room Webcam
The 3XA is our new USB web-conferencing camera and microphone solution. With 3X Optical Zoom, it’s built for capturing all the action in small to medium-sized rooms.
Affordable Video Conferencing is Here
Our customer’s favorite 3X camera with a built-in dual microphone array providing an easy USB 2.0 connection to any PC or Mac computer for web video conferencing simplicity.
KEY FEATURES
• 3X Optical Zoom
• Dual Mic Array
• USB 2.0
• RS232 over USB
• 1920 x 1080p
• 91° Field of View
• Up to 30 fps
• 64 Presets
• IR Remote
• OSD Control
WHAT’S IN THE BOX
• 3X Zoom USB 2.0 Camera with built-in mic array
• 12V/2.0A DC Power Adapter
• Mounts: Tripod Adapter
• USB 2.0 Data Cable (16ft/4.9m)
• IR Remote Control
• Quick Start Guide
Image Sensor & Lens
Video CMOS Sensor 1/2.8” CMOS, 2.1 Mega Pixel
Resolutions 1080p-30/25, 720p-30/25, SVGA, VGA
Frame Rate Up to 30fps (MJPEG)
Lens Zoom 3X Optical Zoom f=3.3-10mm F1.6
Field of view 34° (tele) to 91° (wide)
Pan/Tilt Movement
Pan Movement ±175°
Tilt Rotation Up: 90°, Down: 30°
Presets 64 Presets
Electrical Index
Power Supply Adapter 12V DC 2A
Input voltage 12V DC (10.5-14V DC)
Input Power 15W (Max)
Built-in Audio
Microphone Array Dual Mics on front of camera base
Pickup Range 360° up to 16.5 ft (5m)
Processing Advanced Auto Gain and Noise Control
Physical
Material Aluminum, Plastic
Dimensions (in) 7.1 W x 5.2 H x 3.1 D (5.5 H w/ tilt)
Dimensions (mm) 180 x 132 x 78 (140 H max w/ tilt)
Weight 1.41 lbs (0.64 kg)
Operating Temperature 32°F to 113°F (0°C to 45°C)
Color Black & White
Rear Board Connectors
Video Interface USB 2.0 UVC
Controller Signal Interface USB 2.0 Virtual Com Port (VISCA)
Controller Baud Rate 9600, 38400 bps
Audio Interface USB 2.0 Plug and Play
Controller Signal Config. Dip-Switch Pin 6/TTL Signal
Power Supply Interface DC 12V 1.2A
Other
Mfg. Warranty 2 Years Parts & Labor
Quality Management System
QMS Certified ISO9001: 2008
Compatibility
• Windows 7/8/8.1/10
• Mac OSX
• Acano
• Adobe Connect
• Blue Jeans
• Cisco Jabber
• Cisco Webex*
• Easy Meeting
• Facetime
• Fuzebox
• Google Hangouts
• GoTo Meeting
• Lifesize
• Skype for Business (Lync)
• Polycom Real Presence
• Radavision
• Spontania
• Skype
• TurboMeeting US
• Vidyo
• Zoom.US
• Google Hangouts on Air
• YouTube Live
• Any app that supports the UVC camera interface
*These apps do not supposed image flip
