Lumens VC-A53 White PTZ Camera

    VC-A53-W
    Price: €1,699.00
    No tax
    We offer EU-wide sales, invoicing for VAT-free intra-community delivery.
    Available from supplier (Delivery time to be confirmed.)

    White casings have become a quiet operational asset in modern broadcast: they vanish against lecture-hall ceilings, blend into hotel ballroom décor, and stay invisible in clean corporate sets. The Lumens VC-A53 White brings that visual discretion together with serious Full HD PTZ engineering, so a production owner can specify the same camera body across permanent installs and high-end rental jobs without compromising image consistency. Around its 1/2.8" Sony CMOS sensor of 2.13 megapixels, the unit captures clean 1080p60 footage with above 50 dB SNR and a minimum illumination of 1.0 lux.

    The optical block carries a 20x optical zoom across a 5.33–110 mm range at f/1.6–3.8, giving a 57° horizontal angle wide enough for theatre stages and tight enough to isolate a single presenter from the back of a 30-metre conference room. Pan moves through ±170° and tilt from -30° to +90° at speeds reaching 225° per second, which keeps preset recalls snappy on a live programme. The on-board memory holds 256 presets, addressable from RS-232, RS-422, IR remote or IP control, and the tally indicator helps stage hosts catch when their feed is live.

    Integration is where the VC-A53 White earns its keep on a busy gallery. Video leaves the camera at the same time through 3G-SDI, HDMI, USB 2.0 and IP (RJ45), so an event producer can route a clean signal to a hardware mixer, a confidence display, a NewBlue or vMix encoder, and a remote shader station simultaneously. The Ethernet port supplies both signal and PoE+ for a single-cable run — a meaningful time saving when six cameras hang from a truss above a corporate plenary. Encoding covers H.264 and MJPEG, with streaming support over RTSP, RTMP/RTMPS, SRT, MPEG-TS, HTTP and HTTPS, while VISCA, VISCA over IP, ONVIF and FreeD are available for control and AR tracking.

    For a production company that values predictable purchasing decisions, the Lumens VC-A53 White ships with a five-year manufacturer warranty, an image-flip function for inverted ceiling installs and an audio input that lets a stage microphone feed travel with the picture. From hybrid town halls to e-sport studios, theatre captures and museum lectures, the white finish keeps the camera unobtrusive while the underlying spec sheet holds its own against units twice the price.

    UE Shipping

    We ship across the EU for €20, free over €1,000.

    B2B Shop

    B2B sales only, prices excl. VAT.

    Safe Shopping

    Official EU distribution and warranty.

    Secure checkout

    Secure online payments via Stripe.

    Individual quotation

    Send your enquiry via the form or email avgear@avgear.shop

    VC-A53 Full HD PTZ IP Camera

    • Professional Sony CMOS sensor (1/2.8" 2.16 MP)
    • Supports 1080p at 60fps and versatile 20x optical zoom
    • Simultaneous HD video output via Ethernet, HDMI, USB 3.0 and 3G-SDI
    • High-precision motors with up to 225°/second pan speed
    • Versatile control options: RS-232, RS-422, USB, and Ethernet
    • Integrated intelligent auto modes for focus, exposure and white balance
    • Supports common streaming protocols and IP control
    • 256 preset positions for quick camera positioning
    • Robust design with WDR and 3D noise reduction for clear images in low light

    Professional High Speed Robotics
    With high-precision motors, the VC-A53 can run at up-to 225° per second for very fast movement between preset positions. The unit is also able to move at low speed to deliver smooth and judder-free tracking shots.

    Networking Built-in
    The VC-A53’s Ethernet port is truly multi-purpose. It supports power over Ethernet, video streaming in a variety of secure and broadcast standard formats, and IP control. Users can remotely control multiple units and manage their cameras facility-wide using the complimentary Lumens Deployment Tool 2.0

    Production Ready
    The VC-A53 is based around a professional Sony sensor, making the video output easy to integrate into mixed camera productions. The unit can be controlled using RS-232, RS-422 , USB and Ethernet control interfaces enabling users to add the camera into existing workflows.

    Intelligent Auto
    VC-A53 offers full manual settings to give producers full creative control. The camera also incorporates intelligent automatic modes that deliver exceptional auto-focus, predictive auto-exposure and auto-white balance. These features allow users to trust the camera to run without user-input and to deliver consistently professional results.

    More Details
    Sensor1/2.8" 2.16 MP CMOS
    Video Format1080p : 60 / 50 / 30 / 25
    720p : 60 / 50 / 30
    Video Output (HD) Interface3G-SDI / HDMI / Ethernet / USB3.0
    Optical Zoom20x
    Digital Zoom12x
    Horizontal Viewing Angle57°
    Vertical Viewing Angle32.1°
    Diagonal Viewing Angle65.4°
    ApertureF1.6~F3.8
    Focal Length5.33mm~110mm
    Shutter Speed1/1 ~ 1/10,000 sec
    Minimum Object DistanceWide: 0.5M / Tele: 1.5M
    Video S / N Ratio> 50dB
    Minimum Illumination1.0 lux (F1.6, 50IRE, 30fps)
    Focus SystemAuto / Manual / Smart AF
    Gain ControlAuto / Manual
    White BalanceAuto / Manual
    Exposure ControlAuto / Manual / Smart AE
    WDRYes
    3D NRYes
    Image FlipYes
    AR / VR SystemsFreeD
    Tally LightYes
    Panning Angle+170° ~ -170°
    Panning Speed225°/sec
    Tilting Angle+90° ~ -30°
    Tilting Speed225°/sec
    Preset Positions256
    HDMI / 3G-SDI1080p 60
    IP StreamMain : H.264 1080p 60
    Second : H.264 640x360p 30
    Webpage Preview: 1280x720 30
    IP CompressionH.264
    USB Output1080p 60
    USB CompressionH.264 / MJPEG
    IP ProtocolRTSP / RTMP / RTMPS / MPEG-TS / SRT / HTTP / HTTPS
    PoEPoE (IEEE802.3af)
    InputLine In / MIC In
    OutputEthernet / USB 3.0 / HDMI / SDI
    Compression FormatAAC / PCM
    InterfaceRS-232 / RS-422 / Ethernet / USB / Remote
    ProtocolVISCA / VISCAIP / ONVIF
    UVC1.1
    UACYes
    DC In12V +/- 20%
    Power ConsumptionPoE : 13W
    DC In : 12W
    Weight2 kg (4.4 lbs)
    Dimension (WxHxD)6.85" x 7.76" x 7.09"
    (174 x 197 x 180 mm)
    VC-A53-W

    Data sheet

    Video Output
    HDMI
    RJ-45 (IP)
    SDI
    Audio Input
    Mini Jack 3.5mm
    Audio Output
    HDMI Embedded
    RJ-45
    SDI Embedded
    Max Output Resolution
    1080p 50/60 fps
    Control protocol for PTZ cameras
    NDI
    ONVIF
    RS-232
    RS-422
    VISCA
    VISCA IP
    Network Connection
    Ethernet
    Sensor Size
    1/2.8"
    Optical Zoom
    20x
    PoE Technology
    Yes
    Auto-Tracking
    No
    Tally Light
    Yes

    Specific References

    ean13
    4711246503328
    mpn
    VC-A53-W

    Contact us

    optional

    Reviews

    Write your review

    Lumens VC-A53 White PTZ Camera

    White casings have become a quiet operational asset in modern broadcast: they vanish against lecture-hall ceilings, blend into hotel ballroom décor, and stay invisible in clean corporate sets. The Lumens VC-A53 White brings that visual discretion together with serious Full HD PTZ engineering, so a production owner can specify the same camera body across permanent installs and high-end rental jobs without compromising image consistency. Around its 1/2.8" Sony CMOS sensor of 2.13 megapixels, the unit captures clean 1080p60 footage with above 50 dB SNR and a minimum illumination of 1.0 lux.

    The optical block carries a 20x optical zoom across a 5.33–110 mm range at f/1.6–3.8, giving a 57° horizontal angle wide enough for theatre stages and tight enough to isolate a single presenter from the back of a 30-metre conference room. Pan moves through ±170° and tilt from -30° to +90° at speeds reaching 225° per second, which keeps preset recalls snappy on a live programme. The on-board memory holds 256 presets, addressable from RS-232, RS-422, IR remote or IP control, and the tally indicator helps stage hosts catch when their feed is live.

    Integration is where the VC-A53 White earns its keep on a busy gallery. Video leaves the camera at the same time through 3G-SDI, HDMI, USB 2.0 and IP (RJ45), so an event producer can route a clean signal to a hardware mixer, a confidence display, a NewBlue or vMix encoder, and a remote shader station simultaneously. The Ethernet port supplies both signal and PoE+ for a single-cable run — a meaningful time saving when six cameras hang from a truss above a corporate plenary. Encoding covers H.264 and MJPEG, with streaming support over RTSP, RTMP/RTMPS, SRT, MPEG-TS, HTTP and HTTPS, while VISCA, VISCA over IP, ONVIF and FreeD are available for control and AR tracking.

    For a production company that values predictable purchasing decisions, the Lumens VC-A53 White ships with a five-year manufacturer warranty, an image-flip function for inverted ceiling installs and an audio input that lets a stage microphone feed travel with the picture. From hybrid town halls to e-sport studios, theatre captures and museum lectures, the white finish keeps the camera unobtrusive while the underlying spec sheet holds its own against units twice the price.
