The Osprey Video Raptor 927 Capture Card offers a versatile solution for professionals requiring simultaneous capture from both SDI and HDMI sources. This PCIe 2.0 x4 card features one 3G-SDI input and one HDMI 1.4 input, accommodating diverse video formats and resolutions.
Key Technical Features:
Video Inputs:
• 3G-SDI Input: Supports standard and high-definition formats, including 525i59.94 NTSC, 625i50 PAL, 720p (23.98 to 60 fps), 1080psf (23.98 to 30 fps), 1080p (23.98 to 60 fps), and 1080i (50, 59.94, 60 fps).
• HDMI 1.4 Input: Handles resolutions up to 4K UHD 2160p at 30 fps and 4K DCI 2160p at 24 fps, along with 480p, 576p, 720p, 1080p, and 1080i formats.
Audio Capabilities:
• SDI Input: Embeds up to 16 audio channels (8 stereo pairs).
• HDMI Input: Embeds up to 8 audio channels (4 stereo pairs).
• Analog Audio: Supports both balanced and unbalanced stereo inputs via a 6-pin Mini XLR connector.
Connectivity:
• SDI: Utilizes DIN 1.0/2.3 connectors.
• HDMI: Employs Mini HDMI interfaces.
• Analog Audio: Accessible through an 8-pin Mini XLR port.
Performance and Compliance:
• Power Consumption: Approximately 5W, ensuring energy-efficient operation.
• Environmental Tolerance: Operates within temperatures ranging from 0 to 40°C and humidity levels between 5% and 80% (non-condensing).
• Certifications: Meets CE, FCC, RoHS, and REACH standards, affirming its adherence to international safety and environmental regulations.
The Raptor 927’s dual-input design and comprehensive audio support make it a valuable asset for video production environments requiring flexibility and high-quality capture capabilities.
Osprey Video Raptor 927 Capture card
VS-OS-95-00507
Price: €1,089.00
No tax
We offer EU-wide sales, invoicing for VAT-free intra-community delivery.
Out of stock (Delivery time to be confirmed.)
The Osprey Video Raptor 927 Capture Card offers a versatile solution for professionals requiring simultaneous capture from both SDI and HDMI sources. This PCIe 2.0 x4 card features one 3G-SDI input and one HDMI 1.4 input, accommodating diverse video formats and resolutions.
Key Technical Features:
Video Inputs:
• 3G-SDI Input: Supports standard and high-definition formats, including 525i59.94 NTSC, 625i50 PAL, 720p (23.98 to 60 fps), 1080psf (23.98 to 30 fps), 1080p (23.98 to 60 fps), and 1080i (50, 59.94, 60 fps).
• HDMI 1.4 Input: Handles resolutions up to 4K UHD 2160p at 30 fps and 4K DCI 2160p at 24 fps, along with 480p, 576p, 720p, 1080p, and 1080i formats.
Audio Capabilities:
• SDI Input: Embeds up to 16 audio channels (8 stereo pairs).
• HDMI Input: Embeds up to 8 audio channels (4 stereo pairs).
• Analog Audio: Supports both balanced and unbalanced stereo inputs via a 6-pin Mini XLR connector.
Connectivity:
• SDI: Utilizes DIN 1.0/2.3 connectors.
• HDMI: Employs Mini HDMI interfaces.
• Analog Audio: Accessible through an 8-pin Mini XLR port.
Performance and Compliance:
• Power Consumption: Approximately 5W, ensuring energy-efficient operation.
• Environmental Tolerance: Operates within temperatures ranging from 0 to 40°C and humidity levels between 5% and 80% (non-condensing).
• Certifications: Meets CE, FCC, RoHS, and REACH standards, affirming its adherence to international safety and environmental regulations.
The Raptor 927’s dual-input design and comprehensive audio support make it a valuable asset for video production environments requiring flexibility and high-quality capture capabilities.
UE Shipping
We ship all over the European Union
B2B Shop
Our offer is aimed only to B to B Customers, all prices are exclusive of tax.
Secure checkout
Secure online payments
Individual quotation
Send your enquiry via the form or email avgear@avgear.shop
2 Channels, 1x3G-SDI & 1x HDMI1.4
Balanced & Unbalanced Audio
16/8 Audio Channels per Input
HDMI Video Formats
480p, 576p
720p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
1080i 50, 59.94, 60
4K UHD 2160p 23.98, 24, 25, 29.97, 30
4K DCI 2160p 23.98, 24
HDMI PC Video Formats
1920x1200, 1600x1200, 1400x1050, 1200x1024, 1280x960, 1360x768, 1280x768, 1024x768, 800x600, 640x480
SDI Video Formats
525i59.94 NTSC, 625i50 PAL
720p23.98, 24, 25, 29.97, 30, 50, 59.94, 60
1080psf 23.98, 24, 25, 29.97, 30
1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60
1080i50, 59.94, 60
SDI Compliance
SMPTE 259/292/296/372/424/425/435 (3G-SDI Level A only)
SDI Metadata Support
CEA-608, CEA-708 for closed captioning
SDI Color Spaces 8-bit
4:2:2 - UYVY, YUY2, NV16, NV61
4:2:0 – I420, NV12, NV21, YVU9, YV12
4:4:4 – RGB15, RGB24, RGB32, BGR24, BGR32
Multiple Rate Support
Video Format Auto Detect
Audio Inputs
Embedded SDI 16 Channels (8 Stereo) per connection
Embedded HDMI 8 Channels (4 Stereo) per connection
Balanced and Unbalanced Analog Stereo
Audio Sampling
Television standard sample rate of 48 kHz at 24-bit
Connections
SDI DIN1.0/2.3
Mini HDMI
Analog Audio 8pos Mini XLR
PCIe 2.0 x4
Power Consumption
~ 5W
Warranty
2 years
Compliance
CE, FCC, RoHs, REACH
In the Box
Capture Card with Full Height Bracket
Half Height Bracket
Environmental Specifications
Operating Temperature 0 to 40C
Operating Temperature 0 to 60C for Rugged Version
Non-Operating Temperature -40 to 75C
Operating Humidity Range 5% to 80% (non-condensing)
Operating Humidity Range Rugged 5% to 95% (non-condensing)
Operating Altitude Range 0 to 20,000ft
Non-Operating Altitude Range 0 to 50,000ft
VS-OS-95-00507
Data sheet
- Video Input
- HDMI
SDI - Video Output
- PCIe
- Audio Input
- HDMI Embedded
RCA
SDI Embedded
XLR - Audio Output
- PCIe
- Interface
- PCIe
- Max Output Resolution
- 1080p 50/60 fps
- For Operating System
- Linux
Windows - Output colour sampling
- RGB 4:4:4 8-bit
- Video input channels
- 2
Specific References
- ean13
- 850189006894
- mpn
- 95-00507
