RGBlink Aura UHD 27 (Gen 2) Monitor

Name: RGBlink Aura UHD 27 (Gen 2) Monitor
Brand: RGBlink
SKU: RGAURA27G2
Price: 5190.00 EUR
Availability: InStock

MPN: RGAURA27G2

Price: €5,190.00

No tax

We offer EU-wide sales, invoicing for VAT-free intra-community delivery.

Available from supplier (Delivery time to be confirmed.)

The RGBlink Aura UHD 27 (Gen 2) Monitor stands as a pinnacle of precision in professional video production. Its 27-inch 4K UHD display, boasting a resolution of 3840×2160, ensures unparalleled clarity for critical visual tasks. With a brightness of 800 nits and a contrast ratio of 1200:1, this monitor delivers vibrant and true-to-life images, essential for accurate color grading and editing.

Designed for versatility, the Aura UHD 27 (Gen 2) supports multiple HDR formats, including SMPTE ST2084 (PQ) and hybrid log-gamma (HLG), accommodating various production requirements. Its advanced 3D LUT capabilities, featuring tetrahedral interpolation, ensure precise color calibration, maintaining consistency across different devices and workflows.

Connectivity is robust, featuring four 12G-SDI inputs and outputs and two HDMI 2.0 ports, facilitating seamless integration into diverse production setups. The monitor’s quad-view functionality allows simultaneous monitoring of up to four 12G-SDI signals, each with independent color settings, enhancing workflow efficiency.

Constructed with a durable aluminum alloy frame, the Aura UHD 27 (Gen 2) ensures longevity and effective heat dissipation, making it suitable for rigorous production environments. Its flexible control options, including intuitive button operations and support for (optional) V-mount battery plates, provide adaptability for various on-set configurations.

Incorporating the RGBlink Aura UHD 27 (Gen 2) Monitor into your production setup elevates visual monitoring capabilities, ensuring accurate and reliable performance for professional video production needs.

UE Shipping

We ship all over the European Union for €20, free shipping on orders over €1,000.

B2B Shop

Our offer is aimed only to B to B Customers, all prices are exclusive of tax.

Secure checkout

Secure online payments via Stripe.

Individual quotation

Send your enquiry via the form or email avgear@avgear.shop

aura UHD 27 Gen 2, 3840 x 2160 16:9 aspect ratio, 1000nits, 100% DCI-P3 wide color gamut, custom 3D LUT import, designed for professional production and post production workflow. Offers the precise color reproduction and the unique and advanced features. The aura UHD 27 Gen 2 also supports various HDR gamma curves, such as PQ, HLG, S-Log3.

Key Features
- Compared with the 1st generation, four 12G SDI signals can be monitored in quad-view at the same time. Window C is no longer limited to HDMI In 2 and USB-C
- ARRI and Red added to false color
- Support to install v mount battery plate
- Under quad-view mode, each window has corresponding audio pillar
- Each window is allowed to select independent color mode under multiview
- Support HDR waveform
- Optimize energy saving, ESD, EMI circuit
- DC 24V XLR

Specification

Connectors
Input: 12G-SDI 4 × BNC
HDMI: 2 × HDMI-A (*HDMI In 2: HDCP supported, HDMI In 1: HDCP not supported)
SFP: 12G Fiber (Single Mode)

Output (Loop)
12G-SDI: 4 × BNC

Performance

Panel
Size: 27 inch
Brightness: 800 cd/m2
Type: LCD Panel
Resolution: 3840 x 2160
Pixel Pitch: 0.1369 (H) × 0.1369 (V) mm
Aspect Ratio: 16:9
Backlight: LED
Contrast Ratio: 1200:1
Color Depth: 10bits(1.07B)
Image Processing: 12bits
Response: 9ms
Viewing Angle: 178°/178°

Video Signal Format
SDI Signal Format
1080p@50/59.94/60;
1080p@23.98/24/25/29.97/30;
720p@50/59.94/60;
3840×2160p@23.98/24/25/29.97/30/50/59.94/60;
2048×1080@23. 98/24/25/29.97/30p/psf, 47.95/48/50/59.94/60p;
3840×2160p@24/25/30;
3840×2160p@24/25/30/50/60;

HDMI Signal Format
720p@50/59.94/60;1080i@50/59.94/60;
1080p@23.98/24/25/29.97/30/50/59.94/60;
3840×2160p@23.98/24/25/29.97/30/50/59.94/60;
4096×2160p@23.98/24/25/29.97/30/50/59.94/60;

Audio
Audio: De-embedding Support
Audio Meter: 16 channels （Up to 8 channels can be displayed simultaneously.）
Built-in Speaker: 1×8 ohm/0.5W
Headphone: Stereo mini Jack×1

General
Control/Update: 1×RJ45
GPI: GPI1-5, 1×RJ-45
Serial Port: RS-422, 2×RJ-45 (1 IN | 1 OUT)

Supported Standard
HDMI IN1
HDCP 1.X
HDCP 2.2
SDI
SMPTE-425M-A/B
SMPTE-274M
SMPTE-296M
SMPTE ST 2036-1:2009
SMPTE ST 2048-2:2011
SMPTE ST 2081
SMPTE ST 2082

Power
Input Voltage: AC 100~240V 50/60Hz
Power Consumption (Max): 98W

Environment
Operating Temperature: -10℃～55℃ (14°F to 155°F)
Operating Humidity: 30% ~ 85%, RH
Storage Humidity: -20 ~ 60℃

Physical
Net Weight: 11.4kg
Packaged Weight: 15.3kg
Net Dimension: 661mm × 420mm × 179mm
Packaged Dimension: 890mm × 270mm × 595mm
