The RGBlink Aura UHD Studio 27 (Gen 2) Monitor offers a 27-inch 4K UHD (3840×2160) display, delivering exceptional image clarity essential for professional applications. With a brightness of 800 nits and a contrast ratio of 1200:1, it ensures vivid visuals suitable for various lighting environments. The monitor supports a 10-bit color depth, displaying over 1.07 billion colors for accurate color representation.
This monitor covers 100% of the DCI-P3 color gamut, ensuring precise color reproduction critical for broadcast and cinematic applications. It supports various HDR formats, including SMPTE ST2084 (PQ) and hybrid log-gamma (HLG), catering to diverse production requirements.
Connectivity is robust, featuring four 12G-SDI inputs and outputs, supporting up to 8K signal input and backward compatibility with 4K at 60Hz. The inclusion of a Thunderbolt port enables direct integration with editing applications like Adobe Premiere Pro and DaVinci Resolve, streamlining post-production workflows.
The monitor’s quad-view capability allows simultaneous monitoring of four 12G-SDI signals, with each window supporting independent color modes and corresponding audio pillars, enhancing workflow efficiency. Advanced monitoring tools such as waveform, vectorscope, and histogram are included, providing comprehensive signal analysis. The monitor also supports custom 3D LUT imports with tetrahedral interpolation, ensuring accurate color grading and consistency across projects.
Designed with a durable aluminum alloy frame, the Aura UHD Studio 27 (Gen 2) is built to withstand rigorous production environments. It offers flexibility with V-mount battery plate support and a DC 24V XLR power input, accommodating various on-set power configurations.
RGBlink Aura UHD Studio 27 (Gen 2) Monitor
RGAURA27SG2
Price: €5,490.00
No tax
We offer EU-wide sales, invoicing for VAT-free intra-community delivery.
Out of stock (Delivery time to be confirmed.)
The RGBlink Aura UHD Studio 27 (Gen 2) Monitor offers a 27-inch 4K UHD (3840×2160) display, delivering exceptional image clarity essential for professional applications. With a brightness of 800 nits and a contrast ratio of 1200:1, it ensures vivid visuals suitable for various lighting environments. The monitor supports a 10-bit color depth, displaying over 1.07 billion colors for accurate color representation.
This monitor covers 100% of the DCI-P3 color gamut, ensuring precise color reproduction critical for broadcast and cinematic applications. It supports various HDR formats, including SMPTE ST2084 (PQ) and hybrid log-gamma (HLG), catering to diverse production requirements.
Connectivity is robust, featuring four 12G-SDI inputs and outputs, supporting up to 8K signal input and backward compatibility with 4K at 60Hz. The inclusion of a Thunderbolt port enables direct integration with editing applications like Adobe Premiere Pro and DaVinci Resolve, streamlining post-production workflows.
The monitor’s quad-view capability allows simultaneous monitoring of four 12G-SDI signals, with each window supporting independent color modes and corresponding audio pillars, enhancing workflow efficiency. Advanced monitoring tools such as waveform, vectorscope, and histogram are included, providing comprehensive signal analysis. The monitor also supports custom 3D LUT imports with tetrahedral interpolation, ensuring accurate color grading and consistency across projects.
Designed with a durable aluminum alloy frame, the Aura UHD Studio 27 (Gen 2) is built to withstand rigorous production environments. It offers flexibility with V-mount battery plate support and a DC 24V XLR power input, accommodating various on-set power configurations.
UE Shipping
We ship all over the European Union
B2B Shop
Our offer is aimed only to B to B Customers, all prices are exclusive of tax.
Secure checkout
Secure online payments
Individual quotation
Send your enquiry via the form or email avgear@avgear.shop
Next generation of RGBlink aura UHD monitors brings with it a new model, aura UHD studio, featuring capabilities to connect directly with applications such as Adobe PremierPro™ and DiVinci Resolve™ via Thunderbolt™ port.
aura UHD studio 27 is broadcast-grade 4K HDR monitor, equipped with UHD (3840×2160) screen, supports quad link 12G SDI signal up to 8K input backward compatible with 4K@60Hz, supports high-precision 3D LUT with tetrahedral interpolation algorithm, supports HDR formats such as SMPTE ST2084(PQ), hybrid log-gamma HLG, various Gamma curves, camera Log and other professional functions which are widely used in film, television and advertisement industry.
Key Features
- Compared with the 1st generation, four 12G SDI signals can be monitored in quad-view at the same time. Window C is no longer limited to HDMI In 2 and USB-C
- Preview video editing app such as Davinci output through Thounderbolt
- ARRI and Red added to false color
- DC 24V XLR
- Support HDR waveform
- Each window is allowed to select independent color mode under multiview
- Under quad-view mode, each window has corresponding audio pillar
- Optimize energy saving, ESD, EMI circuit
- Support to install V mount battery plate
Specification
Connectors
Input
12G-SDI: 4 × BNC
HDMI: 2 × HDMI -A (*HDMI In 2: HDCP supported, HDMI In 1: HDCP not supported)
SFP: 12G Fiber (Single Mode)
Type-C/Thunderbolt3: 1 × USB-C (*Only for previewing Davinci app output, does not support desktop duplication or extension.)
Output (Loop)
12G-SDI: 4 × BNC
Performance
Panel
Size: 27 inch
Brightness: 800 cd/m2
Type: LCD Panel
Resolution: 3840 x 2160
Pixel Pitch: 0.1369 (H) × 0.1369 (V) mm
Aspect Ratio: 16:9
Backlight: LED
Contrast Ratio: 1200:1
Color Depth: 10bits(1.07B)
Image Processing: 12bits
Response: 9ms
Viewing Angle: 178°/178°
Video Signal Format
SDI Signal Format
1080p@50/59.94/60;
1080p@23.98/24/25/29.97/30;
720p@50/59.94/60;
3840×2160p@23.98/24/25/29.97/30/50/59.94/60;
2048×1080@23. 98/24/25/29.97/30p/psf, 47.95/48/50/59.94/60p;
3840×2160p@24/25/30;
3840×2160p@24/25/30/50/60;
HDMI Signal Format
720p@50/59.94/60;1080i@50/59.94/60;
1080p@23.98/24/25/29.97/30/50/59.94/60;
3840×2160p@23.98/24/25/29.97/30/50/59.94/60;
4096×2160p@23.98/24/25/29.97/30/50/59.94/60;
Audio
Audio De-embedding: Support
Audio Meter: 16 channels （Up to 8 channels can be displayed simultaneously. ）
Built-in Speaker: 1×8 ohm/0.5W
Headphone: Stereo mini Jack×1
General
Control/Update: 1×RJ45
GPI: GPI1-5, 1×RJ-45
Serial Port: RS-422, 2×RJ-45 (1 IN | 1 OUT)
Supported Standard
HDMI IN1
HDCP 1.X
HDCP 2.2
SDI
SMPTE -425M -A/B
SMPTE -274M
SMPTE -296M
SMPTE ST 2036-1:2009
SMPTE ST 2048-2:2011
SMPTE ST 2081
SMPTE ST 2082
Power
Input Voltage: AC 100~240V 50/60Hz
Power Consumption (Max): 98W
Environment
Operating Temperature: -10℃～55℃ (14°F to 155°F)
Operating Humidity: 30% ~ 85%, RH
Storage Humidity: -20 ~ 60℃
Physical
Net Weight: 11.4kg
Packaged Weight: 15.3kg
Net Dimension: 661mm × 420mm × 179mm
Packaged Dimension: 890mm × 270mm × 595mm
RGAURA27SG2
Data sheet
- Video Input
- HDMI
SDI
USB - Screen Size
- 27"
- Display Brightness
- 800 nits
- Aspect Ratio
- 16:9
- Features
- Built-in speakers
Compatible with RED Cameras
HDCP 1.4
HDCP 2.2
HDR
Quad 4K Video - Screen Resolution
- 3840x2160
- Max Input Resolution
- 4K UHD (3840 x 2160)
Specific References
- ean13
- 6976965940030
- mpn
- 410-2700-01-1
