VELVET Mini Power 2 IP54 Pack is a compact panoramic bi-color LED panel for professional video, television and streaming sets where mounting depth is limited. The low-carbon aluminium chassis is IP54 rainproof for wet or dusty locations, and the thermal architecture uses fan-free passive cooling to stay silent on dialog. The light engine pairs selected BIN LEDs with an optic diffuser and CPU software control for stable output and consistent tint across the CCT range.
Colour temperature is adjustable from 2700K to 6500K in 100K steps, with quick access to 3200K / 5600K. Photometrics are specified at up to 8900 lux at 1 m and 1250 lux at 3 m with a 35° beam angle, which is practical for punchy keys, backlights and bounces in narrow rooms. Output is dimmable 0–100% with smooth, flicker-free behaviour for high-speed capture up to 2000 fps. Colour rendition is rated CRI 96 with TLCI 93 (3200K) / 96 (5600K) for clean skin tones on camera.
Control is available locally via shock-proof buttons and a digital display, or from a lighting console using DMX/RDM on XLR-5 (DMX input; In/Out available through a splitter). DC power lands on a locking Neutrik XLR-3 connector; power draw is 100 W. The docking plate accepts removable V-Mount (V-Lock) or Gold Mount battery plates and supports universal mains via a Smart AC adapter (90–264 V). Operating temperature is specified from -20°C to +40°C, and LED life is rated at 50,000 hours (L70).
The IP54 Pack ships as a ready-to-rig set with yoke and spigot plus a V-Lock adapter and cable, and multiple 1/4"-20 rigging points for clamps, car mounts or grid hanging. Typical deployments include rain-exposed interviews, ENG and documentary runs, compact TV studios, corporate streaming stages, tabletop product shoots, vehicle interiors and greenscreen key lighting. Dedicated diffusion, grids and barn doors remain available when tighter spill control or softer wrap is required.
VELVET Mini Power 2 IP54 Pack is a compact panoramic bi-color LED panel for professional video, television and streaming sets where mounting depth is limited. The low-carbon aluminium chassis is IP54 rainproof for wet or dusty locations, and the thermal architecture uses fan-free passive cooling to stay silent on dialog. The light engine pairs selected BIN LEDs with an optic diffuser and CPU software control for stable output and consistent tint across the CCT range.
Colour temperature is adjustable from 2700K to 6500K in 100K steps, with quick access to 3200K / 5600K. Photometrics are specified at up to 8900 lux at 1 m and 1250 lux at 3 m with a 35° beam angle, which is practical for punchy keys, backlights and bounces in narrow rooms. Output is dimmable 0–100% with smooth, flicker-free behaviour for high-speed capture up to 2000 fps. Colour rendition is rated CRI 96 with TLCI 93 (3200K) / 96 (5600K) for clean skin tones on camera.
Control is available locally via shock-proof buttons and a digital display, or from a lighting console using DMX/RDM on XLR-5 (DMX input; In/Out available through a splitter). DC power lands on a locking Neutrik XLR-3 connector; power draw is 100 W. The docking plate accepts removable V-Mount (V-Lock) or Gold Mount battery plates and supports universal mains via a Smart AC adapter (90–264 V). Operating temperature is specified from -20°C to +40°C, and LED life is rated at 50,000 hours (L70).
The IP54 Pack ships as a ready-to-rig set with yoke and spigot plus a V-Lock adapter and cable, and multiple 1/4"-20 rigging points for clamps, car mounts or grid hanging. Typical deployments include rain-exposed interviews, ENG and documentary runs, compact TV studios, corporate streaming stages, tabletop product shoots, vehicle interiors and greenscreen key lighting. Dedicated diffusion, grids and barn doors remain available when tighter spill control or softer wrap is required.
We ship across the EU for €20, free over €1,000.
B2B sales only, prices excl. VAT.
Official EU distribution and warranty.
Secure online payments via Stripe.
Send your enquiry via the form or email avgear@avgear.shop
2x1/2 feet bicolor weatherproof compact panoramic concentrated light LED panel
Two in one compact panel for low ceilings. Rainproof IP54 rated bicolor mini panel. Long throw concentrated beam of 15º or 30º. High TLCI (96). Precise color temperature adjustment from 2700K to 6500K. Totally silent fanless operation. Robust and lightweight lowcarbon aluminum body. High efficiency means 100% output even with batteries. V-mount, Gold mount available. DMX-RDM control.
Weatherproof LED panel standard pack with yoke, spigot, with Vlock adapter and cable.
SPECIFICATIONS
COLOUR TEMPERATURE: Adjustable from 2700K a 6500K (100K increments)
LIGHT INTENSITY: Dimmable 0 to 100 (smooth and flicker-free)
LOCAL CONTROL: Shock proof buttons and display
WIRE CONTROL: DMX-RDM with XLR-5 In connector (In & Out with DMX splitter)
PHOTOMETRICS: 8900 lux / 827 fc at 1m / 3 feet, 1250 lux / 116 fc at 3m / 10 feet
BEAM ANGLE: 35º
DIMENSIONS: 607 x 190 x 90 m / 24” x 7.5” x 3.5” (panel), 680 x 275 x 90 mm / 26.8”x 10.8” x 3.5” (panel + yoke)
WEIGHT: 3 kgs / 6.5 lbs (panel), 3.4 kgs / 7.5 lbs( panel + yoke)
POWER DRAW: 100W (0.90A at 110 VAC — 0.22A at 220 VAC)
POWER SUPPLY: Vock or Gold battery mount, 90-264 VAC 50/60Hz through Smart AC adapter
LED RATED LIFE: More than 50.000 hours L70 , More than 35.000 hours L80
POWER CONNECTION: Neutrik XLR-3 DC In connector
OUTPUT FREQUENCY: 2000 fps
OPERATION TEMPERATURE: From -20ºC to +40ºC
COOLING: No-noise, fan-free passive cooling
PROTECTION: IP51 dustproof, indoor or outdoor protected use
VELVET LED TECHNOLOGY: Selected BIN LED + optic diffuser + CPU software control
RIGGING OPTIONS: Aluminum yoke with 16 baby receiver combined with 28 junior pin, multiple ¼-20”rigging points, multipanels yokes, pole-operated studio yoke
QUICK MOUNTING ACCESSORIES (optional): Smart Vlock AC power supply, quarter, half and full hard diffusion, foldable Snapgrid, removable barn doors, remote control, cordura case, hard case
CONSTRUCTION & FINISH: Black anodized extruded aluminum and black powder coated sheet aluminum
