Z-CAM P2-R1N 24x Zoom is a network-native PTZ camera for studios that need real optical reach without giving up a large sensor look. The 24x lens covers a 35 mm-equivalent 32–768 mm range and pairs with a 1/1.5" CMOS imager, letting you hold a wide master and then pull a tight close-up from the back of an auditorium. Exposure control is broadcast-friendly—shutter from 1/10000 to 1 s and gain up to 36 dB (ISO 200–12800)—so the camera can ride between spotlights, LED walls and dim audience areas. At the wide end you get a 60° horizontal view, tightening down to 3.2° for long-throw close-ups.
Focus stays usable on moving presenters thanks to PDAF plus manual override, while E.I.S. reduces micro-vibration from truss mounts and balcony rails. When you need “operatorless” coverage, AI auto framing keeps the subject centered for panels, training rooms and classrooms, so you can cut between multiple PTZs without chasing framing.
For live switching and remote production, the “N” version adds native NDI_HX3 alongside IP streaming such as SRT, RTMP/RTMPS and RTSP. Outputs cover baseband and USB workflows: 3G-SDI, HDMI 2.0, Ethernet and USB-C 3.0. Video reaches UHD 4K 59.94p, with looks including Rec.709 and HLG; the built-in multiple color matrix helps matching cameras in a multi-cam room. Audio embeds on SDI/HDMI and can be fed via the 3.5 mm mic/line input.
PTZ motion is tuned for repeatability: up to 180°/s with 0.01° positioning, plus 256 presets via CGI (100 via VISCA) for instant shot recall in vMix/Tricaster/ATEM control rooms. Control includes VISCA over IP, VISCA RS-422 and a web client; Genlock supports multi-camera timing, and FreeD data can drive AR graphics. On-board SD recording creates a safety master in H.265 (up to 4K60, 8-bit) and offers 1080p120 for fast-action analysis. Power stays clean with single-cable PoE+ (802.3at), and tally support keeps talent and operators aligned during talk shows, worship services and corporate events.
Z-CAM P2-R1N 24x Zoom is a network-native PTZ camera for studios that need real optical reach without giving up a large sensor look. The 24x lens covers a 35 mm-equivalent 32–768 mm range and pairs with a 1/1.5" CMOS imager, letting you hold a wide master and then pull a tight close-up from the back of an auditorium. Exposure control is broadcast-friendly—shutter from 1/10000 to 1 s and gain up to 36 dB (ISO 200–12800)—so the camera can ride between spotlights, LED walls and dim audience areas. At the wide end you get a 60° horizontal view, tightening down to 3.2° for long-throw close-ups.
Focus stays usable on moving presenters thanks to PDAF plus manual override, while E.I.S. reduces micro-vibration from truss mounts and balcony rails. When you need “operatorless” coverage, AI auto framing keeps the subject centered for panels, training rooms and classrooms, so you can cut between multiple PTZs without chasing framing.
For live switching and remote production, the “N” version adds native NDI_HX3 alongside IP streaming such as SRT, RTMP/RTMPS and RTSP. Outputs cover baseband and USB workflows: 3G-SDI, HDMI 2.0, Ethernet and USB-C 3.0. Video reaches UHD 4K 59.94p, with looks including Rec.709 and HLG; the built-in multiple color matrix helps matching cameras in a multi-cam room. Audio embeds on SDI/HDMI and can be fed via the 3.5 mm mic/line input.
PTZ motion is tuned for repeatability: up to 180°/s with 0.01° positioning, plus 256 presets via CGI (100 via VISCA) for instant shot recall in vMix/Tricaster/ATEM control rooms. Control includes VISCA over IP, VISCA RS-422 and a web client; Genlock supports multi-camera timing, and FreeD data can drive AR graphics. On-board SD recording creates a safety master in H.265 (up to 4K60, 8-bit) and offers 1080p120 for fast-action analysis. Power stays clean with single-cable PoE+ (802.3at), and tally support keeps talent and operators aligned during talk shows, worship services and corporate events.
We ship across the EU for €20, free over €1,000.
B2B sales only, prices excl. VAT.
Official EU distribution and warranty.
Secure online payments via Stripe.
Send your enquiry via the form or email avgear@avgear.shop
PTZ Camera with Stunning Image Quality
Key features:
P2-R1 24x zoom
1/1.5" Sensor Size
32mm to 768mm Focal Length (35mm equivalent)
NDI Bridge
iris Enabled
PDAF Auto Focus
4K 60FPS Video
AI Auto Framing
Stunning Image
Now iris-Enable
Easily control, manage and monitor your Z CAM P2-R1, anytime, anywhere, just via the cloud in your browser. No extra hardware required!
PDAF - Phase Detection Auto Focus
Boasting quick and accurate capabilities, PDAF achieves state-of-the-art auto focus for professional shooting.
AI Auto Framing
AI-powered real-time intelligent target tracking enables the P2-R1 to deliver perfectly framed shots at all times.
Face Registration
Register faces to increase tracking priority.
Multi-target
Enable simultaneous recognition and tracking of multiple human targets.
Tracking Zone
Set specific boundaries for tracking activation.
Multiple Color Matrix
6 groups of RGB cross adjustment for precise customization of image colors.
What's in the box
Z CAM P2-R1 PTZ Camera Body
12V AC-DC Power Adapter & AC Cable
Ceiling Mount Bracket
Remote Controller
Technical Specifications
Imaging
Image Sensor: P2-R1(N) 24x zoom: 1/1.5" CMOS sensor
Image Stabilization: E.I.S.
Horizontal Resolution (TV Lines): 2160 TV Lines
Focus Control: PDAF (Phase Detection Auto Focus), Manual Focus
Built in ND Filter: No
Image Profile: Rec 709, Cine, High Contrast, Vivid, HLG, HLG Vivid, Concert, Gamma
Exposure Control
Shutter Speed: 1/10000 to 1 second
Gain: P2-R1(N) 24x zoom: 0 to 36 dB (ISO 200 to 12800)
White Balance: Auto, Incandescent, Cloudy, D10000, Fluorescent, Indoor, Daylight, Shade, Manual, Expert
Lens
Focal Length: P2-R1(N) 24x zoom: 32mm to 768mm (35mm equivalent)
Maximum Aperture: P2-R1(N) 24x zoom: f/1.6 (W) / f/4.5 (T) to f/7.1
Optical Zoom Ratio: P2-R1(N) 24x zoom: 24x
Minimum Focus Distance: P2-R1(N) 24x zoom: Wide - 6.5mm, Tele - 156mm
Max Digital Zoom: P2-R1(N) 24x zoom: 48x (in 1080p)
ND: No
Field of View: P2-R1(N) 24x zoom - Horizontal: 60º to 3.2º
OLPF: No
Video Capture
External Recording Modes:
HDMI 2.0:
UHD 4K (3840 x 2160) at 23.98/24/25/29.97/50/59.94 fps
HD (1920 x 1080p) at 23.98/24/25/29.97/50/59.94 fps
HD (1920 x 1080i) at 50/59.94 fps
SDI / BNC:
HD (1920 x 1080p) at 23.98/24/25/29.97/50/59.94 fps
HD (1920 x 1080i) at 50/59.94 fps
RJ45 / USB:
UHD 4K (3840 x 2160) at 24/25/29.97/50/59.94 fps
HD (1920 x 1080p) at 24/25/29.97/50/59.94
Audio Recording : 3.5 mm TRS (Mic in / Line in)
Internal Recording Modes: HD (1920 x 1080p) at 23.98/24/25/29.97/50/59.94/120fps max
Broadcast Output: NTSC / PAL
IP Streaming:
RTMP, RTMPS, RTSP, SRT, SSP, NDI_HX3
UHD 4K (3840 x 2160) at 24/25/29.97/50/59.94 fps
HD (1920 x 1080p) at 24/25/29.97/50/59.94
Control
Presets: 256 via CGI, 100 via VISCA, 9 via IR
Tally Light: Yes
Move Speed: Pan: 0.1 to 180º/sec, Tilt: 0.1 to 180º/sec
Supported Control Methods:
IR
VISCA over RS-422
VISCA over IP
Web Client
USB
Movement Range: Pan: 350º (-175º to +175º), Tilt: 240º (-30º to +210º)
FreeD: Yes
Movement Accuracy: 0.01º
Interface
Media / Memory Card Slot: SD (4K 60fps max, H.265, 8-bit color)
Audio I/O: 1x 1/8" / 3.5 mm TRS Stereo Mic/Line Input
Video I/O:
1x BNC (3G-SDI) Output
1x RJ45 (IP) Output
1x HDMI 2.0 Output
1x USB-C 3.0 Gen 1 Output
Other I/O:
1x BNC (Genlock) Input
1x RJ45 (VISCA / RS-422) Input
1x RJ45 (VISCA / RS-422) Output
Power
PoE Support: PoE+ 802.3at
Power Consumption: 18W maximum
Power I/O: 1x Barrel (12V DC) Input
Environmental
Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
General
Mounting: 3/8" Screw Hole + 1/4" Adapter, Desktop / Ceiling / Wall Mount (Optional accessory)
Environmental Resistance: No
Certifications: CE, FCC, RoHS
Color: Black
Dimensions (W X H x D): P2-R1(N) 24x zoom: 6.8 x 9.3 x 7.6" / 175.0 x 235.5 x 192.5mm
Color: Black
Weight: P2-R1(N) 24x zoom: 6.77 lb / 3.07 kg (Camera Unit only), 11.4 lb / 5.17kg (Full Package)
Fanless Design: Yes
