Blackmagic Studio Camera 6K Pro is a powerful studio camera model that features an EF lens mount, a larger 6K sensor for improved colorimetry and fine detail handling, ND filters and built-in live streaming via Ethernet or mobile data. Blackmagic Studio Camera 6K Pro shares the same compact all-in-one design of the Studio Camera family with a lightweight carbon fiber reinforced polycarbonate body, large integrated 7" HDR viewfinder and powerful broadcast connections.

Blackmagic Studio Cameras have the same features as large studio cameras, miniaturized into a single compact and portable design. Plus with digital film camera dynamic range and color science, the cameras can handle extremely difficult lighting conditions while producing cinematic looking images. The sensor features an ISO up to 25,600 so customers can create amazing images even in dimly lit venues. Advanced features include talkback, tally, camera control, built in color corrector, Blackmagic RAW recording to USB disks, live streaming and more. Plus, the Blackmagic Studio Camera 4K Pro G2 and 6K Pro models add built-in live streaming via Ethernet or mobile data so customers can place cameras remotely, almost anywhere in the world.

Blackmagic RAW Recording
While Blackmagic Studio Camera is designed for live production, it’s not limited to use with a live switcher. That’s because it records Blackmagic RAW to USB disks, so it can be used in any situation where customers use a tripod. The large 7" viewfinder makes it perfect for work such as chat shows, television production, broadcast news, sports, education, conference presentations and even weddings. The large bright display with side handles, touch screen and physical controls makes it easy to track shots while being comfortable to use for long periods of time.

Generation 5 Color Science
Amazing sensors combined with Blackmagic Generation 5 Color Science give customers the same imaging technology used in digital film cameras. The color corrector can even be controlled from the switcher. With 13 stops of dynamic range, the camera has darker blacks and brighter whites, perfect for color correction. Great for both HD and Ultra HD production, the 4K models feature a resolution of 3840 x 2160 and the 6K model has a resolution of 6144 x 3456. Plus, all models support 23.98 to 60 fps.

Lens Mounts
With the popular EF (Blackmagic Studio Camera 6K Pro) or MFT (Blackmagic Studio Camera 4K) lens mounts, the cameras are compatible with a wide range of affordable photographic lenses. Photographic lenses are incredible quality because they're designed for use in high resolution photography. To eliminate the need to reach around to adjust the lens manually, the optional focus and zoom demands let customers adjust the lens from the tripod handles just like a large studio camera. It gives customers the same feel as an expensive B4 broadcast lens.

Broadcast Connections
Unlike consumer cameras, the Blackmagic Studio Camera 4K Pro G2 and 6K Pro models have SDI connections that include talkback so the switcher operator can communicate with cameras during live events. That means the director can talk to the camera operators to guide shot selection, eliminating the problem where all cameras could have the same shot, at the same time. The talkback connector is built into the side of the camera and supports standard 5 pin XLR broadcast headsets.

Blackmagic Studio cameras have lots of connections for connecting to both consumer and broadcast equipment. The advanced Blackmagic Studio Camera Pro models are designed for broadcast workflows so have 12G-SDI, 10GBASE-T Ethernet, talkback and balanced XLR audio inputs. The 10G Ethernet allows all video, tally, talkback and camera power via a single connection so setup is much faster. That's just like a SMPTE fiber workflow, but using standard Category 6A copper Ethernet cable so it's much lower cost.

Live Streaming
Now customers can place cameras remotely, anywhere in the world as the Blackmagic Studio Camera 4K Pro G2 and 6K Pro models have built in live streaming. This means customers can place a camera in a remote location and it can generate a H.264 HD live stream that is sent over the internet back to the studio. Simply connect the camera to the internet using the built in Ethernet connection, or customers can connect a 4G or 5G phone to the USB-C port to stream via remote data.

ND Filters
Blackmagic Studio Camera 6K Pro features high quality, remote controllable ND filters that let customers quickly reduce the amount of light entering the camera. Designed to match the colorimetry and color science of the camera, the 2, 4 and 6 stop filters give customers additional latitude even under harsh lighting. The filters are designed to filter both optical and IR wavelengths evenly, eliminating IR contamination of the images. The ND filters can be electronically controlled by the function buttons on the back of the camera, using buttons on the demand and remotely. Because they can be controlled remotely by the camera control operator, the camera operator is free to focus on getting the perfect shot.

Technical Specifications

Camera Features
Effective Sensor Size: 23.10mm x 12.99mm (Super 35)
Lens Mount: Active EF mount.
Lens Control: Iris, focus, zoom on supported lenses.
Dynamic Range: 13 Stops.
Dual Native ISO: 0dB and 18dB gain.
Sensitivity at 0dB Gain: f11 with 2160p59.94. , f12 with 2160p50. at 2,000 lux with 89.9% reflectance.
Signal to Noise Ratio: 64.62dB for 2160p , Ultra HD scaled from 5.3K
Recording Resolutions:
6144 x 3456 (6K) up to 50 fps
6144 x 2560 (6K 2.4:1) up to 60 fps
5376 x 3024 (5.3K 16:9) up to 60 fps
3840 x 2160 (Ultra HD) up to 60 fps
Video Output Standards: 2160p, 1080p, 1080i
Frame Rates: Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported. Off-speed frame rates 5 ‑ 50 fps in 6K, and 5 ‑ 60 fps for all other recording resolutions.
Built in ND Filters: Four position ND filter with clear, 2‑stop, 4‑stop and 6‑stop IR ND filters.
Focus: Auto focus available using compatible lenses.
Screen Dimensions: 7 inch 1920 x 1200
Screen Type: LCD capacitive touchscreen.
Screen Brightness: 2000 nits
Controls: Touchscreen camera settings and menus with rotary settings dial, program button, F1, F2 and F3 assignable function buttons, brightness contrast and peaking dials.
Mounting Options: 2 x 1/4 inch tripod mount. 1 x 3/8 inch tripod mount.

Connections
SDI Video Inputs: 1
SDI Video Outputs: 1
SDI Rates: 1.5G, 3G, 6G, 12G.
HDMI 2.0 Video Outputs: 1
Analog Audio Input: 2 x XLR analog switchable between mic and line levels. Phantom power support. 1 x 3.5mm Stereo Input. Can also be used for Timecode input.
Analog Audio Output: 1 x 5-pin XLR for talkback headset. 1 x 3.5mm TRRS mini jack for headphones with mic.
SDI Audio Output: 2 channels of program audio embedded in 1.5G/3G/6G/12G-SDI. 2 talkback channels on 15 and 16.
Reference Inputs: Tri-Sync or Black Burst when used with optional Blackmagic Studio Converter.
Remote Control: Remote camera control over SDI, HDMI or Ethernet.
Ethernet: 10Gb/s
Computer Interface: 2 x USB Type‑C 3.1 Gen 1 (up to 5Gb/s) expansion ports for external recording and focus / zoom demand connection. Software updates using USB‑C Port A.

Audio
Microphone: Integrated stereo microphone.
Built in Speaker: 1 x mono speaker.

Streaming
Direct Streaming: Blackmagic Studio Camera 6K Pro supports direct live streaming using Real Time Messaging Protocol (RTMP) over ethernet or a shared mobile internet connection over USB‑C.
Streaming Platforms: ATEM Television Studio HD8 ISO, ATEM Streaming Bridge, Facebook, Twitch, YouTube, Twitter, Restream.IO, Vimeo, BoxCast, Castr, Afreeca TV, Bilibili, DouYu, Weibo.

Standards
SD Video Standards: None
HD Video Standards: 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60
Ultra HD Video Standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
SDI Compliance: SMPTE 292M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1 and SMPTE 2082‑10
SDI Audio Sampling: Television standard sample rate of 48 kHz and 24‑bit.

Media
Media: 2 x USB-C 3.1 Gen 1 expansion ports for external media for recording Blackmagic RAW.
Media Format: Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems.

Supported Codecs
Codecs:
Blackmagic RAW Constant Bitrate 3:1
Blackmagic RAW Constant Bitrate 5:1
Blackmagic RAW Constant Bitrate 8:1
Blackmagic RAW Constant Bitrate 12:1
Blackmagic RAW Constant Quality Q0
Blackmagic RAW Constant Quality Q1
Blackmagic RAW Constant Quality Q3
Blackmagic RAW Constant Quality Q5

Storage Features
Storage Type: 2 x USB‑C 3.1 Gen 1 expansion ports for external media.
Recording Formats: Blackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0, Q1, Q3 and Q5 in 6K (6144 x 3456), 6K 2.4:1 (6144 x 2560), 5.3K 16:9 (5376 x 3024), Ultra HD (3840 x 2160) at the selected frame rate.
Storage Rates:
Storage rates based on 30 frames per second.
6144 x 3456 (6K):
Blackmagic RAW 3:1 - 323 MB/s
Blackmagic RAW 5:1 - 194 MB/s
Blackmagic RAW 8:1 - 121 MB/s
Blackmagic RAW 12:1 - 81 MB/s
Blackmagic RAW Q0 - 242 to 483 MB/s
Blackmagic RAW Q1 - 162 to 387 MB/s
Blackmagic RAW Q3 - 108 to 277 MB/s
Blackmagic RAW Q5 - 65 to 162 MB/s
6144 x 2560 (6K 2.4:1):
Blackmagic RAW 3:1 - 240 MB/s
Blackmagic RAW 5:1 - 144 MB/s
Blackmagic RAW 8:1 - 90 MB/s
Blackmagic RAW 12:1 - 60 MB/s
Blackmagic RAW Q0 - 180 to 359 MB/s
Blackmagic RAW Q1 - 120 to 287 MB/s
Blackmagic RAW Q3 - 80 to 205 MB/s
Blackmagic RAW Q5 - 49 to 120 MB/s
5376 x 3024 (5.3K 16:9):
Blackmagic RAW 3:1 - 248 MB/s
Blackmagic RAW 5:1 - 149 MB/s
Blackmagic RAW 8:1 - 94 MB/s
Blackmagic RAW 12:1 - 63 MB/s
Blackmagic RAW Q0 - 186 to 371 MB/s
Blackmagic RAW Q1 - 125 to 297 MB/s
Blackmagic RAW Q3 - 84 to 212 MB/s
Blackmagic RAW Q5 - 50 to 125 MB/s
3840 x 2160 (Ultra HD):
Blackmagic RAW 3:1 - 127 MB/s
Blackmagic RAW 5:1 - 77 MB/s
Blackmagic RAW 8:1 - 48 MB/s
Blackmagic RAW 12:1 - 32 MB/s
Blackmagic RAW Q0 - 96 to 190 MB/s
Blackmagic RAW Q1 - 64 to 153 MB/s
Blackmagic RAW Q3 - 43 to 109 MB/s
Blackmagic RAW Q5 - 26 to 64 MB/s

Constant Quality storage rates quoted are indicative only.
Actual storage rates are entirely dependent on image subject matter.

Control
External Control: Blackmagic Zoom Demand and Blackmagic Focus Demand for controlling your camera and lens from tripod handles.

Blackmagic Control Protocol over SDI, RTMP and HDMI for external control when used with a compatible ATEM switcher with ATEM Software Control or ATEM Camera Control Panel. Includes control of some camera settings, focus, iris and zoom with compatible lenses, color corrector, tally and record start and stop to external media via USB expansion port.

Camera Control REST API over Ethernet or USB Ethernet for external control via HTTP when used with REST client applications such as Postman.

Network Management
NTP: Network time protocol support allows you to sync the time on your camera, whenever connected to a network with any NTP server of your choice.
Web Media Manager: Using a browser connected over Ethernet, web media manager allows you to access, browse, download and delete files from any drive connected to the camera.
FTP: Download files from any drive attached to your camera using FTP.
SMB: File sharing using SMB

Color Corrector: DaVinci YRGB

Talkback and Tally
Live Tally Indicator: 1 x front facing for talent, 1 x rear facing for operator.
Talkback: SDI Channels 15 and 16.

Software
Software Included: Blackmagic Camera Setup for Mac and Windows.

Power Requirements
Power Supply: 1 x External 12V DC 60W power supply.
Power Inputs:
1 x 12V DC locking 5.5 mm barrel connector.
1 x 12V DC 4 pin XLR input for external power supply or battery use.
1 x RJ45 Ethernet connector for power from Type 4 PoE power supplies.
Power Usage: 32 ‑ 52 W using DC input. , 38 ‑ 59 W using Type 4 PoE input.

Optional Accessories:
Blackmagic Focus Demand
Blackmagic Zoom Demand
Blackmagic Studio Converter
ATEM Mini switchers
ATEM SDI switchers
ATEM Constellation switchers
ATEM Television Studio switchers
ATEM Streaming Bridge
Blackmagic MultiDock 10G
HyperDeck Studio HD Plus
HyperDeck Studio 4K Pro
SmartView 4K
Blackmagic Cloud Pod
Blackmagic Cloud Store
Blackmagic Cloud Store Mini 8TB
Ultimatte 12 HD Mini
Ultimatte 12 HD
Ultimatte 12 4K
Blackmagic 3G SDI Shield for Arduino

Environmental Specifications
Operating Temperature: 0° to 40° C (32° to 104° F)
Storage Temperature: -20° to 45° C (-4° to 113° F)
Relative Humidity: 0% to 90% non-condensing

What's Included:
Blackmagic Studio Camera 6K Pro
Blackmagic Studio Camera Sun Shade
Tripod Mount compatible with 15mm lightweight rails
Tripod Mount Plate
Turret Dust Cap
External 12V DC power supply with locking connector and international sockets adapters for most countries.
Welcome wallet with QR code for software download
DaVinci Resolve download card
Blackmagic Design sticker

Warranty: 1 Year Limited Manufacturer’s Warranty.
