Datavideo DAC-8P 4K | 12G-SDI to HDMI 2.0 Converter

    2000-2281
    Price: €590.00
    No tax
    We offer EU-wide sales, invoicing for VAT-free intra-community delivery.
    Out of stock (Delivery time to be confirmed.)

    The Datavideo DAC-8P 4K is a versatile 12G-SDI to HDMI 2.0 converter designed to integrate high-resolution video into professional workflows. It supports video resolutions up to 4K 60p, ensuring seamless conversion from SDI to HDMI for use with 4K displays and equipment. The DAC-8P includes an SDI loop-through, allowing simultaneous monitoring and conversion without signal loss. It supports embedded audio for streamlined audio-visual transmission. Compact and easy to integrate, the DAC-8P is ideal for studios, live events, and broadcasting setups requiring reliable 4K SDI to HDMI conversion. Deliver crisp, high-quality video output with the DAC-8P 4K.

    Broadcast Quality 4K SDI to HDMI Converter
    The DAC-8P 4K Converter converts 12G-SDI in resolutions up to 4K50/60 to 4K HDMI, it is easy to connect the 4K HDMI signal devices and professional 12G-SDI video equipment. Featuring SDI input and both an SDI and HDMI output, audio is de-embedded from the SDI input, and available in the HDMI output and analog audio output. The DAC-8P 4K Converter is useful for a variety of broadcast, professional AV and education applications.

    Supports Up to DCI 4K (4096 x 2160) and UHD 4K (3840 x 2160)
    The DAC-8P 4K is broadcast quality converter, and it supports up to DCI 4K (4096 x 2160) and UHD 4K (3840 x 2160). The DAC-8P 4K is also very easy to use. It is a plug and play converter, and there is no setting needed from your laptop.

    12G-SDI Input and Loop-Through Output
    In addition to the converted 4K HDMI output, there is a 12G-SDI loop thru for sending a signal to other devices in your workflow.

    Supports SDI Re-clocking
    DAC-8P 4K will regenerate the SDI video, and provideo less SDI jitter to improve SDI eye pattern. DAC-8P 4K allows for a long cable transmission.

    Not Only a Video Converter, but Also an Audio De-Embedder
    DAC-8P 4K provides a video converter from SDI to HDMI, and it also provides you an additional de-embedded 2-channel RCA analog audio output from SDI video to your live production.

    Supports HDMI Deep Color
    HDMI Deep Color supports more realistic and stunning of the video. Much better video quality than the regular HDMI video.

    Aluminum Appearance Design, Rugged and Durable
    Super sturdy and durable. The DAC series has a rugged metal housing for use in even the roughest conditions. Low heat dissipation, ideal for long hour operation in normal ventilated environment.

    Model Number: DAC-8P 4K
    Conversion: 12G-SDI to HDMI 2.0
    Video Inputs: 12G-SDI x 1
    Loop Through: 1
    Video Outputs: 1x HDMI 2.0 with embedded Audio
    Audio Inputs: SDI embedded audio, 24-bit, 16-channel
    Audio Outputs: RCA x 2 (Unbalanced Audio L/R)
    HDMI embedded audio, 24-bit, 8-channel
    Supported Video Input Formats: 4096x2160p: 60/59.94/50/30/29.97/25/24/23.98 , 3840x2160p: 60/59.94/50/30/29.97/25/24/23.98 , 1080p: 60/59.94/50/30/29.97/25/24/23.98 , 1080i: 60/59.94/50 , 720p: 60/59.94/50
    Output Resolutions: Automatically matches the HD, 3G and 12G SDI video input
    Equalizer: Yes
    Reclock: Yes
    SDI Cable Drive: Yes
    Updates and Configuration: USB Type C x 1
    Dimension (LxWxH): 112 x 85 x 45 mm
    Weight: 0.3 kg
    Operating Temp. Range: 0~40 °C
    Power: DC 12V, 8.64W
    What's in the Box: 1 x DAC-8P 4K , 1 x AD Switch DC 12V

    2000-2281

    Data sheet

    Video Input
    SDI
    Video Output
    HDMI
    Audio Input
    SDI Embedded
    Audio Output
    HDMI Embedded
    RCA
    Max Output Resolution
    4K (4096 x 2160) 50/60 fps
    Built-in scaler
    No

    Specific References

    ean13
    672255009277
    mpn
    DAC-8P 4K
