Datavideo DAC-90 | SDI...
€355.00
The Datavideo DAC-90 is a professional SDI audio de-embedder, designed to extract audio from SDI video signals. It supports both SD and HD-SDI...
The Datavideo DAC-9P is a high-performance HDMI to 3G-SDI converter designed for seamless integration of HDMI sources into SDI-based workflows. It supports resolutions up to 1080p, delivering sharp, high-quality video conversion. With dual 3G-SDI outputs, the DAC-9P allows simultaneous signal transmission to two destinations, enhancing flexibility for live events, broadcast setups, or professional AV environments. Compact and easy to use, it also supports embedded audio, ensuring synchronized AV output. Ideal for productions requiring reliable HDMI to SDI conversion, the DAC-9P offers dependable performance and smooth integration into any video workflow.
Datavideo DAC-9P | HDMI to 3G-SDI Converter
2000-2290
Price: €354.00
No tax
We offer EU-wide sales, invoicing for VAT-free intra-community delivery.
The Datavideo DAC-9P is a high-performance HDMI to 3G-SDI converter designed for seamless integration of HDMI sources into SDI-based workflows. It supports resolutions up to 1080p, delivering sharp, high-quality video conversion. With dual 3G-SDI outputs, the DAC-9P allows simultaneous signal transmission to two destinations, enhancing flexibility for live events, broadcast setups, or professional AV environments. Compact and easy to use, it also supports embedded audio, ensuring synchronized AV output. Ideal for productions requiring reliable HDMI to SDI conversion, the DAC-9P offers dependable performance and smooth integration into any video workflow.
HDMI to SDI Conversion
The DAC-9P supports HDMI to 3G/HD/SD-SDI conversion, allows users to connect HDMI devices to professional SDI equipment, like video switchers or recorders.
Better Transmission Through SDI
By using the DAC-9P, user can convert HDMI to High Definition & Standard Definition SDI and take advantage of the long-distance transmission, high quality and affordable connectivity that SDI cables offer.
Audio Embedded within SDI Output Signal
The DAC-9P embeds the audio from HDMI into the SDI signal so only one single cable is needed.
Aluminum Alloy and Heavy Duty Design
Super sturdy and durable. DAC series has a rugged metal housing for use in even the roughest conditions. Low heat dissipation, ideal for long hour operation in normal ventilated environment.
Model Number
DAC-9P: Conversion HDMI to 3G/HD/SD-SDI
Video Inputs: 1x HDMI
Video Outputs: 2x 3G/HD/SD-SDI with embedded Audio
Audio Inputs: HDMI Audio embedded
Audio Outputs: 2x SDI Audio embedded
Supported Video Input Formats: 1080p (23.98/24/25/29.97/30/50/59.94/60Hz), 1080i (50/59.94/60Hz), 720p (50/59.94/60Hz), 576i (PAL), 480i (NTSC)
Output Resolutions: Automatically matches the SD, HD and 3G HDMI video input
SDI Cable Drive: Yes
Dimension (LxWxH): 112 x 85 x 45 mm
Weight: 0.3 kg
Operating Temp. Range: 0~40 °C
Power: DC 12V, 5W
What's in the Box: 1 x DAC-9P , 1 x AD Switch DC 12V
2000-2290
2 Items
Data sheet
- Video Input
- HDMI
- Video Output
- SDI
- Audio Input
- HDMI Embedded
- Audio Output
- SDI Embedded
- Max Output Resolution
- 1080p 50/60 fps
- Built-in scaler
- No
Specific References
- ean13
- 672255004166
- mpn
- DAC-9P
