DZOFilm Arcana 75mm T2.1 Anamorphic 1.5x PL Mount

DZO-AR75PLM
Price: €949.00
No tax
We offer EU-wide sales, invoicing for VAT-free intra-community delivery.
Available from supplier (Delivery time to be confirmed.)

DZOFilm Arcana 75mm T2.1 Anamorphic 1.5x PL Mount puts anamorphic character where it is most visible on screen: in the shape of highlights, the stretch of the frame and the way subjects separate from the background. Its 1.5x squeeze and oval-aperture rendering produce wide-screen composition, elongated flare behaviour and pronounced oval bokeh suited to portrait coverage, close dialogue scenes, branded films and music-video imagery. At T2.1, the lens keeps isolation strong while covering full-frame cinema sensors, which makes it a serious option for productions chasing anamorphic texture without moving into much heavier glass.

The 75 mm focal length gives Arcana a more compressed, more selective look than the shorter lenses in the range. Faces step forward cleanly, background structure tightens, and medium close-ups can be framed without pressing the camera too close to the subject. A minimum focus distance of 0.78 m supports product detail, beauty coverage and controlled close framing, while the front-cylindrical optical structure keeps the squeeze ratio stable from near focus to distance. That steadiness helps restrain the familiar “mumps” effect and leaves less image correction to sort out later.

Inside, the lens uses 15 elements in 11 groups and fully manual cine mechanics. The long 270° focus rotation gives assistants proper space for repeatable marks during narrative work, and the 14-blade iris preserves the lens’s anamorphic signature across the stop range instead of draining the frame of shape as exposure changes. Flares remain expressive rather than messy, reacting to practical lamps, headlights and hard backlight with coloured horizontal streaks that can support commercial gloss or a more restrained dramatic mood.

That combination also makes the lens easy to place in mixed shooting packages. The PL mount suits dedicated cinema cameras, and the short rear optical layout supports use with selected PL adapters, VND solutions and autofocus adapter systems on other platforms. For crews moving between tripod, shoulder support and gimbal work, DZOFilm Arcana 75mm T2.1 Anamorphic 1.5x PL Mount offers a compact route into short fiction, fashion films, automotive spots and premium social production with a clear anamorphic signature.

UE Shipping

We ship across the EU for €20, free over €1,000.

B2B Shop

B2B sales only, prices excl. VAT.

Safe Shopping

Official EU distribution and warranty.

Secure checkout

Secure online payments via Stripe.

Individual quotation

Send your enquiry via the form or email avgear@avgear.shop

Iconic Cinematic Anamorphic Look & Pro Image Quality
Innovative 1.5x hybrid anamorphic design delivers classic 2x waterfall bokeh and color-shifting horizontal streaking flares. 3 ED ultra-low dispersion, 4 high-refractive and 4 cylindrical lenses ensure sharp clarity, edge detail and low chromatic aberration, with full-frame coverage and consistent T2.1 aperture for professional film-grade aesthetics.

Ultra-Portable 700g Gimbal-Friendly Build
Each lens weighs only 690–710g (≈700g) with compact 80mm length, ideal for handheld, gimbal and Ronin 4D use. Uniform 80mm front diameter supports 77mm filters across the Arcana series, and consistent weight avoids repeated gimbal balancing, streamlining workflow.

Stable Optics & Less Post-Production Work
Front cylindrical lens design ensures constant squeeze ratio from close focus to infinity, effectively suppressing face widening and reducing post-production correction. 48–78cm minimum focus enables versatile close-ups, while full aluminum alloy body with titanium anti-fingerprint coating provides durable, premium finish.

Professional Filmmaking for Diverse Creators
Arcana Anamorphic Lens is ideal for film students, upgrading photographers and independent production teams. Backed by DZOFilm, it delivers professional anamorphic quality for short dramas, web series and creative content creation.

Specifications
Focal Length: 75mm
Colour: Titanium
Mount: PL
Aperture: T2.1-16
Image Circle: ø43.3mm (Full-Frame)
Construction of Optics: 15 Elements in 11 Groups
Angle of View (horizontal, vertical): 42.6°(H) × 18.8°(V)
Close Focus (from sensor plane): 0.78m / 2ft 7in
Max. Mag. Ratio: 0.116
Squeeze Factor: 1.5X
Iris Control: Manual (59.53°)
Focus Control: Manual 270°
Front Dia.: ø80
Length (from lens front to flange plane): 80mm
Iris Blade: 14
Filter Size: M77
Gear Pitch: 0.8mod
Material: Aluminum Alloy
Weight (Product): 709g

DZO-AR75PLM

Data sheet

Lens Mount
PL Mount
Focal Lengths
75mm
Maximum Aperture
T2.1
Lens Format Coverage
Full Frame
Lens Type
Anamorphic
Cinema Lens
Prime

Specific References

ean13
6970604945950
mpn
DZO-AR75PLM
