DZOFilm Catta Zoom 70-135mm T2.9 Black Sony E Mount (FF)

    DZO-FF70135E-BLK
    Price: €1,179.00
    No tax
    We offer EU-wide sales, invoicing for VAT-free intra-community delivery.

    Long-lens coverage on full-frame Sony cameras, without losing a stop as the zoom moves in, is what the DZOFilm Catta Zoom 70-135mm T2.9 Black Sony E Mount brings to a kit. It sits at the telephoto end of DZOFilm's full-frame cine zoom trio. A 43.5 mm image circle covers full frame, and the aperture holds at T2.9 through the 1.9x range, so exposure stays put during a zoom on air. On APS-C or Super 35 bodies it frames roughly like a 105–200 mm.

    Place the camera 8 m from a conference stage: at 70 mm a speaker appears full-length with about 4 m of set around them, while 135 mm narrows the frame to roughly 2 m. Because the optics are parfocal, that move works live once back focus has been set with the shims supplied in the box. Breathing is kept minimal, which counts on the second angle of an interview or when a focus pull crosses from moderator to panellist. On documentaries it also earns its place as a slider-mounted second camera. Close focus sits at 0.76 m from the sensor, near enough for a technician's hands on a circuit board in an industrial film.

    Inside are 17 elements in 11 groups. A 16-blade iris keeps out-of-focus bulbs and LED walls behind a stage round rather than polygonal. Every ring is cut with 0.8 MOD gears, with a 270° focus throw, 100° for zoom and 80° for the iris. The 70-135 shares its mechanical layout with the Catta 35-80, so gear positions line up and a lens change on a motorised rig leaves motors and follow focus where they were. Colour is matched across the series as well, which shortens the grade on multicam jobs.

    A support base and rod come with the lens, and they are worth fitting: a long cine zoom on a mirrorless body should not hang from the bayonet alone. Up front, the 80 mm diameter suits clamp-on matte boxes and the M77 thread takes screw-in filters. At the rear, a slot accepts optional Catta COIN inserts, for example an ND to stay at T2.9 on a sunny sports sideline. Its glass-fibre-reinforced polycarbonate shell keeps a three-axis gimbal simple to trim. The Sony E mount fits FX and Alpha bodies directly; swapping in an optional RF, L, X or Z bayonet lets the same lens go out on whatever camera a client specifies.

    Quantity
    Last items in stock

    UE Shipping

    We ship across the EU for €20, free over €1,000.

    B2B Shop

    B2B sales only, prices excl. VAT.

    Safe Shopping

    Official EU distribution and warranty.

    Secure checkout

    Secure online payments via Stripe.

    Individual quotation

    Send your enquiry via the form or email avgear@avgear.shop

    Specification
    Focal Length70-135 mm
    ColourBlack
    MountSony E
    T-StopT2.9-T22
    Image Circleφ43.5mm (FULL FRAME)
    Optical Construction17 Elements in 11 Groups
    Flange Distance18mm (E)
    Close Focus
    (from sensor plane)
    0.76m/2ft6in
    Zoom Ratio1.9X
    Iris ControlManual (rotation angle 80°)
    Focus ControlManual (rotation angle 270°)
    Zoom ControlManual (rotation angle 100°)
    Front Dia.ø80mm/3.15"
    Length214.4mm/8.44” (E)
    Iris Blade16
    Filter SizeM77
    Gear Pitch0.8 Mod
    MaterialPC+GF
    Weight≈1597g
    DZO-FF70135E-BLK
    1 Item

    Data sheet

    Lens Mount
    Sony E-Mount
    Focal Lengths
    70-135mm
    Maximum Aperture
    T2.9
    Lens Format Coverage
    Full Frame
    Lens Type
    Cinema Lens
    Zoom

    Specific References

    ean13
    6970604940108
    mpn
    DZO-FF70135E-BLK
