HuddleCamHD 10XA Conference Camera with a Built-in Microphone Array
The HuddleCamHD 10XA is ideal for small to medium sized meeting rooms. This camera is compatible with every system that accepts USB cameras.

A camera for medium conference room
The black HuddleCamHD 10XA 1080p PTZ Camera is suitable for medium-sized conference rooms. You can easily connect your camera to a Windows, Mac, or ChromeBox without the need for additional software.

It offers complete USB-based video conferencing systems designed to work with any online meeting software such as Skype for Business, GoToMeeting, WebEX, and Skype. Furthermore, the camera features a microphone array built into the camera for clear audio pick-up. The camera includes an IR remote control which can be used for camera PTZ and configuration.

KEY FEATURES
• 10X Optical Zoom
• Dual Mic Array
• USB 2.0
• RS232 via USB
• 1920 x 1080p
• 60° Field of View
• Up to 30fps
• 64 Presets
• IR Remote
• OSD Control

WHAT’S IN THE BOX
• 10X Zoom USB 2.0 Camera with built-in mic array
• 12V/2.0A DC Power Adapter
• Mounts: Tripod Mount
• USB 2.0 Data Cable (16ft/4.9m)
• IR Remote Control
• Quick Start Guide

Image Sensor
Video CMOS Sensor 1/2.8” CMOS, 2.1 Mega Pixel
Resolutions 1080p-30/25, 720p-30/25, SVGA, VGA
Frame Rate Up to 30fps (MJPEG)
Lens Zoom 10X Optical Zoom f=4.7-47mm F1.6
Field of view 8° (tele) to 60° (wide)
Pan/Tilt Movement
Pan Movement ±175°
Tilt Rotation Up: 90°, Down: 30°
Presets 64 Presets
Electrical Index
Power Supply Adapter 12V DC 2A
Input voltage 12V DC (10.5-14V DC)
Input Power 24W (Max)
Built-in Audio
Microphone Array Dual Mics on front of camera base
Pickup Range 360° up to 16.5 ft (5m)
Processing Advanced Auto Gain and Noise Control
Physical
Material Aluminum, Plastic
Dimensions (in) 7.1 W x 5.2 H x 3.1 D (5.5 H w/ tilt)
Dimensions (mm) 180 x 132 x 78 (140 H max w/ tilt)
Weight 1.41 lbs (0.64 kg)
Operating Temperature 32°F to 113°F (0°C to 45°C)
Color Black & White
Working Environment Indoor
Rear Board Connectors
Video Interface USB 2.0 UVC
Controller Signal Interface USB 2.0 Virtual Com Port (VISCA, PelcoD)
Controller Baud Rate 9600, 38400 bps
Audio Interface USB 2.0 Plug and Play
Power Supply Interface DC 12V 1.2A
Other
Mfg. Warranty 2 Years Parts & Labor
Quality Management System
QMS Certified ISO9001: 2008

Compatibility
• Windows 7/8/8.1/10
• Mac OSX
• Acano
• Adobe Connect
• Blue Jeans
• Cisco Jabber
• Cisco Webex*
• Easy Meeting
• Facetime
• Fuzebox
• Google Hangouts
• GoTo Meeting
• Lifesize
• Skype for Business (Lync)
• Polycom Real Presence
• Radavision
• Spontania
• Skype
• TurboMeeting US
• Vidyo
• Zoom.US
• Google Hangouts on Air
• YouTube Live
• Any app that supports the UVC camera interface
*These apps do not supposed image flip
