Canon CR-N100 White PTZ Camera

    CR-N100 WH
    Price: €1,859.00
    No tax
    We offer EU-wide sales, invoicing for VAT-free intra-community delivery.

    A white chassis matters more than it looks on a spec sheet — in light-toned studios, corporate atriums and university lecture halls, the housing should disappear so the talent stays the focus. The Canon CR-N100 White ships with the same broadcast-grade internals as its black sibling but wears a finish that blends into bright ceilings and pale acoustic panels. At the core sits a 1/2.3-type CMOS sensor and a DIGIC DV6 processor, working with a 20x optical zoom (f=3.67–73.4 mm, F/1.8–2.8) whose 8-bladed circular aperture renders natural background separation on tight portraits.

    4K UHD acquisition climbs to 30P in 4:2:2 10-bit, and Full HD pushes 60p for sports cadence or fast-paced stage action. Focus stays decisive through Hybrid AF, which folds phase-detection speed into the accuracy of contrast detection — Face AF and Tracking AF then hold steady framing across keynote talks, debate panels or remote interviews. Operators retain headroom in mixed lighting: gain spans 0–36 dB, minimum subject illumination sits near 1.5 lux, a motor-driven gradation ND filter (up to 1/8) tames bright stages, and Night Mode lifts the IR cut for security-grade low-light capture.

    For multi-camera operations, the Canon CR-N100 White drops into IP mixing rooms via NDI|HX, SRT, RTMP/RTMPS and RTSP/RTP, with XC and Standard Communication protocols on tap for legacy joystick controllers. One RJ45 cable carries PoE+ (IEEE 802.3at) plus signal, simplifying long-run installs in atriums or gymnasiums, while HDMI, USB-C 3.1 and an RS-422 RJ45 keep parallel feeds and serial control available. Up to 100 stored positions ride alongside pan-tilt speeds from 0.2° to 300°/sec — slow enough for cinematic reveals, quick enough to chase a soloist crossing the stage.

    The free Auto Tracking App RA-AT001 (Lite) arrives with the August 2025 firmware and follows a chosen subject automatically; the licensed RA-AT001 layer adds multi-person framing, sit/stand framing and five tracking memories for unattended captures, hybrid classrooms or e-sport tournaments. For a production house owner weighing total cost of ownership, the Canon CR-N100 White reads as a long-term asset: stable colorimetry, fine-grained control and a manufacturer roadmap that keeps the camera in service long after the install crew leaves.

    Quantity
    Add to Wishlist
    Add to Compare

    UE Shipping

    We ship across the EU for €20, free over €1,000.

    B2B Shop

    B2B sales only, prices excl. VAT.

    Safe Shopping

    Official EU distribution and warranty.

    Secure checkout

    Secure online payments via Stripe.

    Individual quotation

    Send your enquiry via the form or email avgear@avgear.shop

    Experience the flexibility of a 1/2.3-type 4K sensor and DIGIC DV6 processor with Hybrid AF and a 20x image stabilized optical zoom. Compatible with the built-in Auto Tracking app*, IP streaming and control protocols, this camera offers seamless integration for the corporate, education, houses of worship and live event industries.

    Smooth and precise control
    The CR-N100 has a high-precision drive mechanism for fine Pan and Tilt movement as slow as 0.2°/s. Compatible with the RC-IP100 controller and Remote Camera Control Application controllers, it can also be configured with selected third-party units.

    Precise focusing with Hybrid AF
    Combining high-precision contrast AF with high-speed phase-detection AF, the CR-N100 delivers rapid and accurate focusing of the subject, even in low light conditions.

    The CR-N100 PTZ camera has an external sensor measuring subject distance, and compares the point of focus with that determined by the Contrast AF system. This Auto Focus system delivers faster and more accurate focussing than conventional contrast AF, assisting the camera operator.

    Auto Tracking
    Auto Tracking Application RA-AT001. Unlock the potential to track one or more speakers with face detection as they move around the stage, automatically. Optimise production efficiency for lectures, corporate events, houses of worship, live performances and broadcast.

    Upgrade your content with a new firmware update available August 2025
    Download the latest firmware and take advantage of newly added Auto Tracking App RA-AT001* features. Auto Framing features include Multi-Person Framing, that detects and includes multiple people in the frame, while Face Direction Framing and Sit/Stand Framing deliver natural composition for a single person in frame. Additionally, RTMP/SRT auto reconnection and improved camera control from the iOS app is now included.

    *Free Auto Tracking App RA-AT001(Lite) available via FW, 1.1.0 or later. A paid license is necessary for full functionality of auto tracking.

    FeatureAuto Tracking Application (Lite)Auto Tracking Application
    Tracking subjectAuto-select onlyAuto-/manual select possible
    Tracking sensitivityFixedAdjustable from 1 to 10 levels
    Tracking subject display sizeCan be set at two levelsCan be set at five levels
    Tracking target display positionFixed at centerCan be set to any area
    Auto Framing—Multi-Person Framing, Face Direction Framing, Sit/Stand Framing
    Priority display area—Can be set
    Fixed angle of view—Can be set
    Save tracking settingsOne onlyUp to five can be saved/recalled

    Specifications

    Camera
    Image SensorType 1/2.3 (1/2.3 in.) single-plate CMOS sensor
    Effective Pixelsapprox. 8.29 megapixels (3840 x 2160)
    Lensf=3.67 – 73.4 mm, F/1.8 – 2.8, 20x optical zoom, 8-bladed circular aperture
    Optical Zoom20x optical zoom
    Digital Zoom20x digital zoom
    Focal Length3.67 – 73.4 mm, f/1.8 – 2.8,
    35mm equivalent focal length:
    [4K UHD] approx. 29.3 (W) – 601 mm (T)
    [Full HD] approx. 30.5 (W) – 627 mm (T)
    Angle of View[4K UHD]
    Horizontal: 65.6 (W) – 3.6° (T)
    Vertical: 39.8° (W) – 2.0° (T)
    [Full HD]
    Horizontal: 63.5 (W) – 3.4° (T)
    Vertical: 38.4° (W) – 1.9° (T)
    Minimum Subject IlluminationApprox. 1.5 lux (shutter speed 1/30 sec., frame rate 59.947P (P (Programmed AE) shooting mode, auto slow shutter on)
    Shutter Speed1/6 – 1/2000 sec. (specific values depend on the frame frequency and frame rate)
    IrisManual/Automatic aperture
    Gain0.0 dB – 36 dB
    ND FilterBuilt-in (1/8 at maximum, gradation ND), motor operated
    Night Mode (IR Cut Filter Off)No
    White BalanceAUTO (AWB), Set A, Set B, preset settings (daylight: 5,600 K¹, tungsten lamp: 3,200 K²),
    color temperature setting (2,000 K – 15,000 K), Manual
    FocusFocus mode: Manual, Continuous AF, Face AF, Tracking
    AF type: Hybrid AF, Contrast AF
    GammaNormal1 (Standard), Normal3 (BT.709)
    Pan and TiltPan operation range: Horizontal ±170°
    Pan operation speed: 0.2° – 300°/sec.
    Tilt operation range: Vertical -30° – +100°
    Tilt operation speed: 0.2° – 180°/sec.
    Server
    Video Output Format: HDMI3840 x 2160: 29.97P, 25.00P, 23.98P (4:2:2 10 bit)
    1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P (4:2:2 10 bit)
    1280 x 720: 59.94P, 50.00P (4:2:2 10 bit)
    Video Output Format: IP[Frame frequency 59.94 Hz]
    1920 x 1080: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    1280 x 720: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    640 x 360: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    [Frame frequency 29.97 Hz]
    3840 x 2160: 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    1920 x 1080: 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    1280 x 720: 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    640 x 360: 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    [Frame frequency 50.00 Hz]
    1920 x 1080: 50.00 fps, 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    1280 x 720: 50.00 fps, 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    640 x 360: 50.00 fps, 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    [Frame frequency 25.00 Hz]
    3840 x 2160: 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    1920 x 1080: 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    1280 x 720: 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    640 x 360: 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    [Frame frequency 23.98 Hz]
    3840 x 2160: 23.98 fps, 11.99 fps, 5.99 fps (4:2:0 8 bit)
    1920 x 1080: 23.98 fps, 11.99 fps, 5.99 fps (4:2:0 8 bit)
    1280 x 720: 23.98 fps, 11.99 fps, 5.99 fps (4:2:0 8 bit)
    640 x 360: 23.98 fps, 11.99 fps, 5.99 fps (4:2:0 8 bit)
    – JPEG has one pattern fixed depending on the frame frequency (format is fixed and cannot be selected)
    Resolution: 1280 x 720
    When frame frequency is 59.94/29.97 Hz: 14.99 fps,
    When frame frequency is 50.00/25.00 Hz: 12.50 fps,
    When frame frequency is 23.98 Hz: 11.99 fps
    Video Output Format: USBMotion JPEG:
    1920 x 1080
    59.94 Hz: 30.00 fps, 15.00 fps, 5.00 fps
    50.00 Hz: 25.00 fps, 12.50 fps, 5.00 fps
    1280 x 720
    59.94 Hz: 30.00 fps, 15.00 fps, 5.00 fps
    50.00 Hz: 25.00 fps, 12.50 fps, 5.00 fps
    640 x 360
    59.94 Hz: 30.00 fps, 15.00 fps, 5.00 fps
    50.00 Hz: 25.00 fps, 12.50 fps, 5.00 fps
    YUV:
    640 x 360
    59.94 Hz: 30.00 fps, 15.00 fps, 5.00 fps
    50.00 Hz: 25.00 fps, 12.50 fps, 5.00 fps
    Video Transmission ProtocolProtocol: XC (Canon's original), RTSP/RTP, NDI|HX, RTMP/RTMPS, Standard Communication (Serial), Standard Communication (IP), SRT.
    PresetNumber of presets: Max. 100 (including home position)
    Interface
    Communication ControlLAN, Serial, IR
    Network TerminalLAN x 1, RJ45, 1000Base-T
    GEN-LOCK TerminalNo
    HDMI OUT TerminalHDMI connector x 1, output only
    RS-422 TerminalRJ45 connector x 1
    Audio INPUT 1/INPUT 2 TerminalsNo
    MIC Terminalϕ3.5 mm stereo mini jack (unbalanced, plug-in power supported)
    Sensitivity (MIC): -72 dBV (Manual volume center, full scale -18 dB)/1 kΩ or more/Att.: 20 dB
    Sensitivity (LINE): -10 dBV (Manual volume center, full scale -18 dB)/1 kΩ or more
    Supply Voltage: 2.4 V DC (Bias resistance: 2.2 kΩ)
    USB TerminalType-C (USB 3.1) x 1
    Physical Features
    Operating EnvironmentTemperature
    0°C – +40°C (+32°F – +104°F)
    Humidity
    10% – 90% (without condensation)
    Power SupplyPoE: PoE+ power supply via LAN connector (IEEE802.3at compliant)
    – PoE cannot be used
    External power source: 24 V DC (using included AC adaptor)
    Power ConsumptionPoE+ Input: Approx. 16.2 W³ max. (body only)
    DC Input: Approx. 15.0 W max. (body only)
    Dimensions (W x H x D)Approx. 154 x 178 x 164 mm (excluding protrusions)
    WeightApprox. 2.2 kg (4.86 lb.) (body only)
    NoiseNC35 or less
    CR-N100 WH
    21 Items

    Data sheet

    Video Output
    HDMI
    NDI
    RJ-45 (IP)
    USB
    Audio Input
    Mini Jack 3.5mm
    Audio Output
    HDMI Embedded
    NDI Embedded
    RJ-45
    USB
    Max Output Resolution
    4K UltraHD (3840 x 2160) 25/30 fps
    Control protocol for PTZ cameras
    Canon XC
    NDI
    RS-422
    Network Connection
    Ethernet
    Sensor Size
    1/2.3"
    Optical Zoom
    20x
    PoE Technology
    Yes
    Auto-Tracking
    Yes
    Tally Light
    Yes

    Specific References

    ean13
    4549292229035
    mpn
    6527C004
