Magewell Eco Capture 12G SDI 4K Plus M.2 (11561) | Video capture card PCIe Gen3 x4

Magewell Eco Capture 12G SDI 4K Plus M.2 (11561) | Video capture card PCIe Gen3 x4

Name: Magewell Eco Capture 12G SDI 4K Plus M.2 (11561) | Video capture card PCIe Gen3 x4
Brand: Magewell
SKU: 11561
Price: 699.00 EUR
Availability: InStock

MPN: 11561

Price: €699.00

No tax

We offer EU-wide sales, invoicing for VAT-free intra-community delivery.

Out of stock (Delivery time to be confirmed.)

The Magewell Eco Capture 12G SDI 4K Plus M.2 is a powerful video capture card that combines high-end performance with a compact design. Tailored for professionals, this card captures stunning 4K video at up to 60fps via a 12G-SDI input, delivering exceptional clarity and detail. Whether you’re involved in broadcasting, live streaming, or sophisticated video production, the Eco Capture 12G SDI 4K Plus M.2 ensures your content meets the highest standards. With its M.2 form factor, this capture card is perfect for embedded systems, small form factor PCs, and custom builds. This ensures fast data transfer, low latency, and efficient operation, making it ideal for demanding video capture tasks.This card features HDMI embedded audio capture, and support for both Windows and Linux systems.

UE Shipping

We ship all over the European Union

B2B Shop

Our offer is aimed only to B to B Customers, all prices are exclusive of tax.

Secure checkout

Secure online payments

Individual quotation

Send your enquiry via the form or email avgear@avgear.shop

The Eco Capture 12G SDI 4K Plus M.2 is a signle-channel 12G SDI or quad-link 3G SDI + embedded audiocapture card with connection for a M.2 slot. This Eco card supports video capture for SDI signals up to 4096x2160, frame rates up to 240fps. These cards (22x80mm) are designed for small and portable systems that do not have space for full-size PCIe slots.

- Captures 1-channel single-link 12G SDI or quad-link 3G SDI + embedded audio
- High throughout for capture and supports higher frame rates
- M.2 2280 standard size for small or portable systems

The Magewell Eco Capture M.2 cards offer high-performance and powerful video capture solutions with low power consumption. The Magewell SDK enables developers to customize the Magewell APIs for lower-latency capture and synchronize channels across multi-channel or even multiple capture cards.

Video Engine
Auto detection of input signal format
Color formats conversion
Low latency mode
SG-DMA transmission mode
Multiple replicated capture streams
Closed caption (SDK required)

Others
2-year warranty
Continuously work for 24hx7
LED status indicator
Multiple devices on one host
On-board dip switch to set card number

Software Environment
Window & Linux driver and SDK
Upgradable firmware
Compatible with Capture Express, Magewell Bridge for NDI®, Plugin for Premiere®

Eco Capture 12G SDI 4K Plus M.2 Specifications

Input Features
Max input at 4096x2160 60fps 4:2:2 10-bit
Input single SD/HD/3G/6G/12G SDI, dual 6G-SDI to 12G-SDI , or quad 3G-SDI to 12G-SDI
SD (ST 259)/HD (ST 292)/3Ga (ST 425)/3Gb-DL (ST 425)/3Gb-DS (ST 425)/6G (ST 2081) /12G (ST 2082) standard
Support for 4K (4096x2160) mode
Up to 8-channel 48KHz embedded audio
Input SDI signals transmitted up to 75m for 12G-SDI, 80m for 6G-SDI, 200m for 3G-SDI, 430m for SD signal
Support for Closed Caption via SDK

Process and Capture Features
Video processing pipelines with ~700Mpixels/s processing bandwidth
~2400MB/s per channel DMA bandwidth in PCIe 3.x system
~1600MB/s per channel DMA bandwidth in PCIe 2.x system
~800MB/s per channel DMA bandwidth in PCIe 1.x system
Capture videos up to 4096x2160, frame rates up to 240fps. Typical outputs include (actual capture frame rate can be limited by the PCIe bandwidth and internal working frequency.):
4096x2160p 5/10/15/25/29.97/30/50/60
3840x2160p 5/10/15/25/29.97/30/50/60
1920x1080p 5/10/15/25/29.97/30/50/60/120
1280x720p 5/10/15/25/29.97/30/50/60/120 etc.
Output NV12/I420/YUYV/UYVY/RGB24/RGB32 videos
Support custom output formats using Magewell Capture SDK
Support custom EDID, up/down scaling, de-interlacing, color space conversion and frame rate conversion
Multiple capture streams, unlimited capture streams for any one input channel
Support timestamp & A/V synchronization
Hardware based 100ns high resolution clock
Audio frames (192 audio samples) & video frames are stamped with hardware clock
Hardware clock can be synchronized across cards (via SDK)
Support extraction of SMPTE timecode using SDK
Support extracting ANC metadata for custom DID/SDID
Support firmware upgrade

SDK & APIs
The MWCapture SDK provides functions including signal status extraction, capture configuration and real-time audio & video capture, etc
Windows DirectShow/DirectKS/Wave API/DirectSound/WASAPI
Linux V4L2/ALSA

Supported OS
Windows 10/11/Server 2016 (x86 & x64) and above
Linux (x86, x64 & ARM architecture)

Input Interfaces
2 x SD/HD/3G-SDI
2 x SD/HD/3G/6G/12G-SDI

Host Interfaces
M.2 2280 Type M (PCIe Gen3 x4)

Supported Softwares
VLC
VirtualDub
OBS
XSplit
vMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any other DirectShow/V4L2/AVCaptureSession based encoding or streaming software

LED Indicator
Status LEDs indicate the working state of each channel:
Pulsing slowly: input signal unlocked
On: input signal locked
Double blinks: memory failed or FPGA configuration failed
Off: firmware or power supply abnormal

Form Factor
M.2 2280 standard size (22 x 80 mm)

Accessories
2 x 3G BNC (Part number: ELE00018)
2 x 3G H.FL75–2LPG–084N2-A–140 (14cm) (Part number: ELE00019)
2 x 12G DFL75–2LPP–084N9D-A–140 (14cm) (Part number: ACC10020)
2 x 12G BNC (Part number: ACC10021)

Power Consumption
Max current at 3.3V: ~ 1.96 A
Max power consumption: ~ 6.5 W

Working Environment
Operating temperature: 0 to 40 deg C
Storage temperature: –20 to 70 deg C
Relative Humidity: 5% to 90% non-condensing
