Osprey Video Raptor 927 Capture card

The Osprey Video Raptor 927 Capture Card is a versatile solution for professionals seeking reliable video capture capabilities. It features dual-channel inputs: one 3G-SDI and one HDMI 1.4, accommodating various video formats. The HDMI input supports resolutions from 480p up to 4K UHD at 30fps and 4K DCI at 24fps, while the SDI input handles formats including 525i59.94 NTSC, 625i50 PAL, 720p, 1080i, and 1080p up to 60p. Audio integration is robust, with the SDI input supporting up to 16 embedded audio channels and the HDMI input accommodating up to 8 embedded audio channels. For additional flexibility, the card offers both balanced and unbalanced analog stereo audio inputs via mini XLR and RCA connections, utilizing an optional audio breakout cable. The Raptor 927 ensures compatibility with a wide range of professional equipment through adherence to SMPTE standards, including SMPTE 259, 292, 296, 372, 424, 425, and 435 for 3G-SDI Level A. It also supports SDI metadata for closed captioning (CEA-608 and CEA-708). Color space support is comprehensive, covering 8-bit 4:2:2 (UYVY, YUY2), 4:2:0 (I420, NV12), and 4:4:4 (RGB24, BGR24) formats. Designed for efficiency, the card operates with a power consumption of approximately 5W and interfaces via PCIe 2.0 x4. It includes both full-height and half-height brackets to accommodate various system configurations. Environmental specifications allow for operating temperatures between 0 to 40°C (up to 60°C for the rugged version) and operating humidity ranges from 5% to 80% non-condensing. Incorporating the Osprey Video Raptor 927 into your workflow enhances your system’s ability to handle diverse video and audio input formats, ensuring high-quality capture for professional applications.
