Telycam Vision+ SE HDMI BK PTZ Camera
€959.00
Telycam Vision+ SE HDMI BK pairs UHD 4K60 capture with precise PTZ mechanics for multi-camera studios and control rooms. A 1/2.8-type 9...
Telycam Drive+ SE HDMI BK is a compact PTZ camera built for workflows that need stable 1080p60 over HDMI with simultaneous NDI|HX and USB 3.0 (UVC). A 1/2.8" 2.4 MP CMOS with 2D/3D noise reduction delivers clean images from 0.7 lux. The 20× optical system (f=4.9–98 mm, F1.5–F3.0) covers a 60° H-FOV at wide and keeps detail tight at tele, with fast, precise AF. Encoding via H.264/H.265 supports bitrates from 1 to 16 Mbps for studio or IP production.
The camera outputs HDMI up to 1080p60/50 (including 59.94/29.97 and 1080i), plus NDI|HX streams from 360p to 1080p60, and UVC over USB for conferencing or capture. Built-in IP streaming includes SRT, RTMP/RTMPS, RTSP, RTP multicast and HTTP. Tally indication is native to NDI workflows. Audio embeds from a 3.5 mm line-in. For power and single-cable installs, PoE+ (IEEE 802.3at) is supported.
Robotic movement is smooth and repeatable: pan −170° to +170° and tilt −30° to +90° with speeds from 0.1 to 120°/s (pan) and 0.1 to 80°/s (tilt). Store 128 presets via serial (10 by IR) with 0.1° stop accuracy. Control options include VISCA over IP/TCP/UDP, VISCA, Pelco-D/P, RS-232/RS-485, web UI and IR remote; third-party PTZ joystick panels integrate too. RS-485 daisy-chain reduces cabling. Image tools cover AWB modes, anti-flicker 50/60 Hz, flip/mirror and manual shutter/iris/focus.
For integration, the Drive+ SE HDMI BK body measures 220 × 190 × 173 mm and weighs 1.35 kg. Operating range is −10 °C to +50 °C. Typical use cases include multicam live streaming, lecture capture and broadcast contribution where Full HD, low latency NDI|HX and deterministic PTZ moves are essential. Choose it when you require reliable HDMI 1080p60, NDI|HX interoperability and 20× optical zoom in a single PoE+-ready unit.
Telycam Drive+ SE HDMI BK PTZ Camera
Drive+ SE HDMI BK
Price: €695.00
No tax
We offer EU-wide sales, invoicing for VAT-free intra-community delivery.
Telycam Drive+ SE HDMI BK is a compact PTZ camera built for workflows that need stable 1080p60 over HDMI with simultaneous NDI|HX and USB 3.0 (UVC). A 1/2.8" 2.4 MP CMOS with 2D/3D noise reduction delivers clean images from 0.7 lux. The 20× optical system (f=4.9–98 mm, F1.5–F3.0) covers a 60° H-FOV at wide and keeps detail tight at tele, with fast, precise AF. Encoding via H.264/H.265 supports bitrates from 1 to 16 Mbps for studio or IP production.
The camera outputs HDMI up to 1080p60/50 (including 59.94/29.97 and 1080i), plus NDI|HX streams from 360p to 1080p60, and UVC over USB for conferencing or capture. Built-in IP streaming includes SRT, RTMP/RTMPS, RTSP, RTP multicast and HTTP. Tally indication is native to NDI workflows. Audio embeds from a 3.5 mm line-in. For power and single-cable installs, PoE+ (IEEE 802.3at) is supported.
Robotic movement is smooth and repeatable: pan −170° to +170° and tilt −30° to +90° with speeds from 0.1 to 120°/s (pan) and 0.1 to 80°/s (tilt). Store 128 presets via serial (10 by IR) with 0.1° stop accuracy. Control options include VISCA over IP/TCP/UDP, VISCA, Pelco-D/P, RS-232/RS-485, web UI and IR remote; third-party PTZ joystick panels integrate too. RS-485 daisy-chain reduces cabling. Image tools cover AWB modes, anti-flicker 50/60 Hz, flip/mirror and manual shutter/iris/focus.
For integration, the Drive+ SE HDMI BK body measures 220 × 190 × 173 mm and weighs 1.35 kg. Operating range is −10 °C to +50 °C. Typical use cases include multicam live streaming, lecture capture and broadcast contribution where Full HD, low latency NDI|HX and deterministic PTZ moves are essential. Choose it when you require reliable HDMI 1080p60, NDI|HX interoperability and 20× optical zoom in a single PoE+-ready unit.
local_shipping
UE Shipping
We ship across the EU for €20, free over €1,000.
business_center
B2B Shop
B2B sales only, prices excl. VAT.
security
Safe Shopping
Official EU distribution and warranty.
payment
Secure checkout
Secure online payments via Stripe.
contact_mail
Individual quotation
Send your enquiry via the form or email avgear@avgear.shop
Full HD Clarity
The Drive+ SE features an industry-leading image processor and a 1/2.8-inch 2.4-megapixel sensor, delivering FHD video at 1920x1080p60. It pro-vides vivid, sharp visuals even in challenging low-light conditions.
Precision Zoom
With a 20X optical zoom lens and a 60-degree field of view, the Drive+ SE ensures rapid, accurate focus with its proprietary algorithm. Capture every detail effortlessly, whether zooming in or panning.
Latest NDI®HX Integration
Using Newtek’s NDI® technology, the Drive+ SE enables seamless plug-and-play integration across various live streaming platforms.
Versatile Outputs
In addition to NDI®HX, the Drive+ SE simultaneously outputs via 3G-SDI and USB3.0, providing unmatched connectivity flexibility.
Intuitive Tally System
The built-in indicator light doubles as a tally, responding to notifications from NDI® devices. Easily discern when you're live with a glance.
Specifications
TLC-300-IP-20(NDI)-SE-HDMI
1/2.8 inch, 2.4MP CMOS sensor
20X optical zoom
Lens: f= 4.9mm~98 mm, F1.5~F3.0
Horizontal View Angle: 60°(Wide)~3.2°(Tele)
Vertical Viewing Angle: 34.14°~1.12°
Diagonal Viewing Angle: 67.08°~2.27°
Minimum Working Distance: 1.0m
S/N Ratio: ≥50dB
Image Parameters
Noise Reduction: 2D&3D
Minimum lux: 0.7Lux(50 IRE Max AGC, 1/30, F1.8)
White Balance: ATW/Manual/Auto/Indoor/Outdoor/One Push/Sodium/Fluorescent
Exposure: Auto/Manual/Shutter Priority/Iris Priority/Brightness Priority
Anti-Flicker: OFF, 50Hz, 60Hz
Image Flip: Supported
Mirroring: Supported
Focus: Auto/Manual
Iris: Auto/Manual
Electronic-shutter: Auto/Manual
Gamma: Supported
Backlight Compensation: Supported
Video Format
NDI®HX: 1920*1080@3~60; 1280*720@3~60; 1024*576@3~60; 640*360@3~60 (low bandwidth mode)
HDMI: 1920*1080P60/50/30/25/59.94/29.97/24/23.98; 1920*1080I60/50/59.94; 1280*720P60/50/30/25/59.94/29.97
USB 3.0: 1920*1080P60/50/30/25 1280*720P60/50/30(USB 3.0); 1280*720P25(USB 3.0&USB 2.0); 1024*576P30(USB 3.0&USB 2.0); 960*540P30(USB 2.0); 640*360P30(USB 2.0); 512*288P30(USB 2.0)
IP Streaming
Video Encoding: H.264/H.265
Bitrate Control: Variable bitrate(VBR), Constant bitrate(CBR)
Bitrate Range: 1024Kbps~ 16384Kbps
Network Port Speed: 1000M
Protocol: NDI®HX, SRT, HTTP, RTSP, RTMP, DHCP, ONVIF, VISCA over IP, VISCA TCP, VISCA UDP, Pelco P/D, RTP Multicast, HTML
Pan/Tilt Movement
Preset: Remote controller: 10; Serial port: 128; Accuracy: 0.1°
Pan Rotation Angle: -170°~+170°
Tilt Rotation Angle: -30°~+90°
Pan Rotation Speed: 0.1°~120°/s
Tilt Rotation Speed: 0.1°~80°/s
I/O Interface
Control Port: RS232, RS485, NDI®HX, USB 3.0(UVC1.5), USB 2.0(UVC1.1)
Video Port: NDI®HX, 3G-SDI(or HDMI), USB 3.0
Audio Port: stereo 3.5mm linear inputs
Tally: Supported
POE+: Supported
Daisy Chain: Supported
General
Input Voltage: DC12V, POE+(IEEE802.3at)
Operating Temperature: -10℃~50℃
Operating Humidity: ≤80%
Dimension(L×W×H): 220mmx190mmx173mm
Net Weight: 1.35kg
Color: Black/White
Drive+ SE HDMI BK
8 Items
Data sheet
- Video Output
- HDMI
NDI
RJ-45 (IP)
USB - Audio Input
- Mini Jack 3.5mm
- Audio Output
- HDMI Embedded
NDI Embedded
RJ-45
USB - Max Output Resolution
- 1080p 50/60 fps
- Control protocol for PTZ cameras
- PELCO-D
PELCO-P
RS-232
RS-485
VISCA
VISCA IP - Sensor Size
- 1/2.8"
- Optical Zoom
- 20x
- PoE Technology
- Yes
- Auto-Tracking
- No
- Tally Light
- Yes
Specific References
- ean13
- 768486167760
- mpn
- TLC-300-IP-20(NDI)-SE-HDMI
