AVMATRIX PKC4000-NDI PTZ Camera Controller
€599.00
AVMATRIX PKC4000-NDI gives one operator direct command of a multi-camera PTZ system without splitting control between software panels, browser...
One operator behind a desk can now cover what once demanded an assistant on every tripod. The Atomos A-Eye Control gathers pan, tilt, zoom and complete image adjustment for a whole fleet of A-Eye PTZ cameras under two hands, talking to each head either over IP with ONVIF support or through classic RS-232 and RS-422 serial lines. Because network and serial paths sit side by side, the console drops into an existing Ethernet infrastructure just as readily as into a fully cabled studio installation.
At the centre of the panel, a variable-speed 4D joystick turns small wrist movements into smooth, broadcast-grade camera moves; a twist drives the zoom while dedicated keys take care of focus and iris. The 5-inch LCD screen shows connection status and menu parameters at a glance, so exposure, white balance and pan/tilt speed can be corrected mid-programme without anyone walking up to a camera. Stored presets snap each head back to a rehearsed framing within seconds — invaluable once a conference agenda starts jumping between lectern, panel and audience.
Power arrives from the included 12 V adapter or straight over PoE, so a single network cable can carry both control and supply — a tidy solution for mobile racks. Drawing under 5 W, with a polycarbonate-ABS shell rated from −10 °C to +55 °C, the unit shrugs off cold OB vehicles and warm technical booths alike, and its customisable function buttons keep recurring commands, such as recalling the AI auto-tracking A-Eye heads, one press away.
For a production business the maths is plain: one PTZ controller in place of several camera operators shortens setup, trims crew costs and keeps multi-camera coverage consistent across corporate streams, sports halls, lecture theatres and television studios. Supplied with an RS-232 lead and a multi-plug power adapter, the Atomos A-Eye Control earns its desk space from the first live call.
Atomos A-Eye Control PTZ Controller
ATOMAECT01
Price: €990.00
No tax
We offer EU-wide sales, invoicing for VAT-free intra-community delivery.
Available from supplier (Delivery time to be confirmed.)
One operator behind a desk can now cover what once demanded an assistant on every tripod. The Atomos A-Eye Control gathers pan, tilt, zoom and complete image adjustment for a whole fleet of A-Eye PTZ cameras under two hands, talking to each head either over IP with ONVIF support or through classic RS-232 and RS-422 serial lines. Because network and serial paths sit side by side, the console drops into an existing Ethernet infrastructure just as readily as into a fully cabled studio installation.
At the centre of the panel, a variable-speed 4D joystick turns small wrist movements into smooth, broadcast-grade camera moves; a twist drives the zoom while dedicated keys take care of focus and iris. The 5-inch LCD screen shows connection status and menu parameters at a glance, so exposure, white balance and pan/tilt speed can be corrected mid-programme without anyone walking up to a camera. Stored presets snap each head back to a rehearsed framing within seconds — invaluable once a conference agenda starts jumping between lectern, panel and audience.
Power arrives from the included 12 V adapter or straight over PoE, so a single network cable can carry both control and supply — a tidy solution for mobile racks. Drawing under 5 W, with a polycarbonate-ABS shell rated from −10 °C to +55 °C, the unit shrugs off cold OB vehicles and warm technical booths alike, and its customisable function buttons keep recurring commands, such as recalling the AI auto-tracking A-Eye heads, one press away.
For a production business the maths is plain: one PTZ controller in place of several camera operators shortens setup, trims crew costs and keeps multi-camera coverage consistent across corporate streams, sports halls, lecture theatres and television studios. Supplied with an RS-232 lead and a multi-plug power adapter, the Atomos A-Eye Control earns its desk space from the first live call.
local_shipping
UE Shipping
We ship across the EU for €20, free over €1,000.
business_center
B2B Shop
B2B sales only, prices excl. VAT.
security
Safe Shopping
Official EU distribution and warranty.
payment
Secure checkout
Secure online payments via Stripe.
contact_mail
Individual quotation
Send your enquiry via the form or email avgear@avgear.shop
Atomos A-Eye Control – PTZ Camera Remote
Precision camera control in the palm of your hand
The Atomos A-Eye Control is a dedicated remote control unit designed to give you full access to pan, tilt, zoom, and image adjustments on A-Eye PTZ cameras. Whether mounted in a studio, auditorium, or live production environment, this compact control surface makes managing multiple cameras simple, responsive, and efficient.
Key Features
• Compatible with Atomos A-Eye PTZ cameras
• RS-232 and RS-422 serial control
• Joystick for smooth pan and tilt operation
• Dedicated zoom and focus controls
• Access to white balance, exposure, and image settings
• Store and recall preset camera positions
• Compact design for desktop or control room use
• Ideal for live events, studios, corporate video, and houses of worship
Effortless Multi-Camera Operation
Connect and control multiple A-Eye PTZ cameras from one centralized unit. The A-Eye Control remote provides intuitive joystick navigation, tactile zoom control, and quick access to exposure, focus, white balance, and preset recall—all from a compact desktop interface.
Designed for Seamless A-Eye Integration
Built specifically for use with the Atomos A-Eye PTZ series, the controller communicates over RS-232 and RS-422 protocols for reliable wired performance. It integrates easily into production environments that require consistent, synchronized camera operation across multiple units.
Simple Setup with Professional Results
Whether you’re operating a multi-camera broadcast, managing a corporate stream, or capturing worship services, the A-Eye Control offers quick setup and real-time adjustments with minimal learning curve. With support for preset recall and manual adjustments, it provides precision and flexibility on demand.
Specifications
Physical
Dimensions (W x H x D mm): 340 x 268 x 140mm
Weight: 900gms
Environmental
Ambient operating temperature: -10 degrees to 55 degrees Celsius
Construction
Body: Polycarbonate ABS
Power
Input voltage: DC12V-2A
Operating power: ≤5W
ATOMAECT01
Data sheet
- Interface
- Ethernet
RS-232
RS-422 - Control protocol for PTZ cameras
- ONVIF
RS-232 - Network Connection
- Ethernet
- Device type
- PTZ Camera Controller
- PoE Technology
- Yes
- Tally Light
- No
- Screen Size
- 5"
Specific References
- ean13
- 814164023269
- mpn
- ATOMAECT01
