Coverage comes from a ø43.3 mm image circle, within a tenth of a millimetre of a 36 × 24 mm sensor's diagonal. Recording 3:2 at full height de-squeezes to 2.25:1, and a 2.39:1 master then gives up only about 6% of the height. From 16:9 you get 2.67:1, with roughly 10% cropped from the sides for the same delivery. Bigger gates need checking first. ALEXA Mini LF Open Gate has a 44.71 mm diagonal and overshoots the circle, whereas its 4.3K 16:9 mode, at 40.89 mm, stays inside. If your package mixes bodies, tell us which camera and recording mode are planned and we will check the numbers before you order.

The formula runs to 15 elements in 13 groups. Across the range DZOFilm specifies up to four cylindrical, three ED and four high-refractive elements, and it rates the series beyond 12K. Field reports add useful nuance for anyone budgeting a shoot around this T2.1 cine lens: centre detail is strong wide open, edges fall away gradually, and the peak arrives near T5.6. At 300% magnification RedShark saw almost no chromatic aberration or coma. That falloff suits faces and atmosphere. A landscape plate that must hold detail into every corner is another matter, so plan to stop down or choose a spherical lens.

Barrel distortion is the trait to test before booking. Both hands-on reviews we read found it strongest at 32 mm within the trio, and one compared the result to a mild fisheye. A music video or fashion-led spot can exploit that curve; an architectural interior with strict verticals will want correcting in post. Focus breathing was visible but modest in those same tests.

Flares rely on a neutral white coating, a recipe DZOFilm carried over from its Pavo line. A horizontal streak therefore picks up the hue of its source: the amber beacon on a snowplough draws an amber line, and a client's brand colours are not tinted blue. Under clean high-CRI lamps, RedShark logged white primary streaks with teal secondaries, long at T2.1 and broken into shorter separations once stopped down. Fstoppers found the effect mostly needs a direct source, so light for it if the script calls for a streak.

Rigging is where time comes back. The three Arcana primes share one barrel format, with an 80 mm front for clamp-on matte boxes, M77 filters and 0.8 MOD gears in matching positions, so a swap on a gimbal should need neither rebalancing nor new motor positions. Focus travels 270° over metric scales. The iris covers T2.1 to T16 in 52.26°, close to the 51.96° of the 45 mm, although the 75 mm at 59.53° asks for a fresh motor calibration. DZOFilm also lists compatibility with the LiDAR focusing system on the DJI Ronin 4D.

DZOFilm supplies the Arcana in PL mount only, citing structural limits, so no alternative mount can be fitted. Four indexing slots let the lens seat at 90° for vertical deliverables, turning the flare vertical too. A short rear section leaves room for drop-in VND holders and PL adapters, and DZOFilm's Octopus range, sold separately, takes the lens to E, L and RF bodies; each camera then needs its own shimming. In the box: front cap, PL rear cap, shims, screws, a T6 screwdriver and stickers.

Nothing electronic sits inside, so focal length and stop go into VFX notes by hand. The aluminium-alloy barrel wears an anti-fingerprint titanium finish and is rated from −30 °C to 70 °C, which suits a winter sports documentary, though it has no weather sealing.

For a production house the purchase can be staged. Put one 32 mm through a real job, then add the 45 and 75 mm for a matched anamorphic package that a single operator can carry. Owned in-house, an anamorphic wide-angle lens of this size works across brand films, documentaries, music videos and short-form drama, on full-frame and Super 35 PL cameras alike.
