Capturing cinematic footage with a distinct anamorphic character no longer demands oversized, multi-kilogram glass. The DZOFilm Arcana 32/45/75mm T2.1 Anamorphic 1.5x 3-Lens Set PL Mount bundles three full-frame primes — 32mm, 45mm, and 75mm — each opening to T2.1 and sharing a uniform 80mm length, 80mm front diameter, and a mass between 690 and 710 grams. That consistency lets gimbal operators swap lenses on a DJI Ronin 4D or RS5 without re-balancing, a practical advantage on fast-paced narrative shoots and single-operator music-video productions.
The optical formula packs 15 elements in 13 groups (32mm/45mm) or 11 groups (75mm), combining three ED ultra-low dispersion elements, four high-refractive elements, and four cylindrical elements. A front-mounted cylindrical group — a construction more common in high-end cine glass — holds a constant 1.5x squeeze ratio from the closest focusing distance to infinity, reducing the facial distortion known as "anamorphic mumps." Close focus reaches 0.48 m on the 32mm, 0.53 m on the 45mm, and 0.78 m on the 75mm, giving room for tight detail shots during interviews or product work.
Where the Arcana set truly stands apart is its 14-blade elliptical aperture, which replicates the oval, waterfall-style bokeh associated with 2x anamorphic optics. Horizontal colour-shifting flares change tone with the colour temperature of the light source, thanks to a neutral coating inherited from DZOFilm's PAVO line. The full-frame 43.3 mm image circle covers the entire 36 × 24 mm sensor area without cropping.
The kit uses ARRI PL mount with a four-keyway flange supporting 90° rotation for vertical anamorphic compositions. Standard 0.8 MOD gears, a 270° focus throw, and a 77mm filter thread ensure seamless integration with wireless follow-focus units and screw-in NDs. The DZOFilm Octopus Adapter extends compatibility to Canon RF, Sony E, Leica L, and Nikon Z bodies — making the Arcana trio a practical foundation for rental houses and owner-operators building a full-frame anamorphic package.
Instead of €2,847.00
Capturing cinematic footage with a distinct anamorphic character no longer demands oversized, multi-kilogram glass. The DZOFilm Arcana 32/45/75mm T2.1 Anamorphic 1.5x 3-Lens Set PL Mount bundles three full-frame primes — 32mm, 45mm, and 75mm — each opening to T2.1 and sharing a uniform 80mm length, 80mm front diameter, and a mass between 690 and 710 grams. That consistency lets gimbal operators swap lenses on a DJI Ronin 4D or RS5 without re-balancing, a practical advantage on fast-paced narrative shoots and single-operator music-video productions.
The optical formula packs 15 elements in 13 groups (32mm/45mm) or 11 groups (75mm), combining three ED ultra-low dispersion elements, four high-refractive elements, and four cylindrical elements. A front-mounted cylindrical group — a construction more common in high-end cine glass — holds a constant 1.5x squeeze ratio from the closest focusing distance to infinity, reducing the facial distortion known as "anamorphic mumps." Close focus reaches 0.48 m on the 32mm, 0.53 m on the 45mm, and 0.78 m on the 75mm, giving room for tight detail shots during interviews or product work.
Where the Arcana set truly stands apart is its 14-blade elliptical aperture, which replicates the oval, waterfall-style bokeh associated with 2x anamorphic optics. Horizontal colour-shifting flares change tone with the colour temperature of the light source, thanks to a neutral coating inherited from DZOFilm's PAVO line. The full-frame 43.3 mm image circle covers the entire 36 × 24 mm sensor area without cropping.
The kit uses ARRI PL mount with a four-keyway flange supporting 90° rotation for vertical anamorphic compositions. Standard 0.8 MOD gears, a 270° focus throw, and a 77mm filter thread ensure seamless integration with wireless follow-focus units and screw-in NDs. The DZOFilm Octopus Adapter extends compatibility to Canon RF, Sony E, Leica L, and Nikon Z bodies — making the Arcana trio a practical foundation for rental houses and owner-operators building a full-frame anamorphic package.
We ship across the EU for €20, free over €1,000.
B2B sales only, prices excl. VAT.
Official EU distribution and warranty.
Secure online payments via Stripe.
Send your enquiry via the form or email avgear@avgear.shop
The DZOFILM Arcana 32/45/75mm T2.1 Full-frame 1.5X Hybrid Anamorphic Prime 3-Lens Set (PL mount) from DZOFILM is a premium anamorphic prime lens set crafted for professional cinematography, virtual production, and high-end filmmaking. The set includes three focal lengths—32mm, 45mm, and 75mm—each engineered with a consistent T2.1 aperture and full-frame coverage with a 43.3mm image circle, ensuring compatibility with a wide range of cinema cameras.
Key Features
Featuring a 1.5× anamorphic squeeze factor, these lenses produce a distinctive cinematic aesthetic, including oval-shaped bokeh and characteristic horizontal lens flares that respond naturally to light sources thanks to the specialized coating design. This makes them ideal for achieving a classic anamorphic look without the extreme squeeze of 2× systems, while maintaining practical usability in modern production workflows.
Mechanically, all lenses in the series share a unified compact form factor with identical dimensions, 80mm front diameter, M77 filter thread, and similar weight (~690–710g). This consistency allows for efficient rigging, gimbal use, and lens swaps without the need for rebalancing. The robust construction includes a titanium finish for durability and a refined professional appearance.
Each lens offers manual focus with a 270° focus throw for precise control, manual iris operation, and close focusing distances suited for a variety of shooting scenarios. The PL mount ensures compatibility with professional cinema cameras, making this lens set a versatile tool for narrative films, commercials, music videos, and high-end content production.
| Focal Length | 32mm | 45mm | 75mm |
|---|---|---|---|
| Colour | Titanium | Titanium | Titanium |
| Mount | PL | PL | PL |
| Aperture | T2.1-16 | T2.1-16 | T2.1-16 |
| Image Circle | ø43.3mm (Full-Frame) | ø43.3mm (Full-Frame) | ø43.3mm (Full-Frame) |
| Construction of Optics | 15 Elements in 13 Groups | 15 Elements in 13 Groups | 15 Elements in 11 Groups |
| Angle of View (horizontal, vertical) | 97.0°(H) × 41.4°(V) | 70.0°(H) × 30.2°(V) | 42.6°(H) × 18.8°(V) |
| Close Focus (from sensor plane) | 0.48m / 1ft 7in | 0.53m / 1ft 9in | 0.78m / 2ft 7in |
| Max. Mag. Ratio | 0.092 | 0.111 | 0.116 |
| Squeeze Factor | 1.5X | 1.5X | 1.5X |
| Iris Control | Manual (52.26°) | Manual (51.96°) | Manual (59.53°) |
| Focus Control | Manual 270° | Manual 270° | Manual 270° |
| Front Dia. | ø80 | ø80 | ø80 |
| Length (from lens front to flange plane) | 80mm | 80mm | 80mm |
| Iris Blade | 14 | 14 | 14 |
| Filter Size | M77 | M77 | M77 |
| Gear Pitch | 0.8mod | 0.8mod | 0.8mod |
| Material | Aluminum Alloy | Aluminum Alloy | Aluminum Alloy |
| Weight (Product) | 709g | 695g | 709g |
