RGBlink vue 4K NDI PTZ Camera 12x Zoom

Name: RGBlink vue 4K NDI PTZ Camera 12x Zoom
Brand: RGBlink
SKU: RGB12X-UNAI-OL
Price: 3490.00 EUR
Availability: InStock

MPN: RGB12X-UNAI-OL

Price: €3,490.00

No tax

We offer EU-wide sales, invoicing for VAT-free intra-community delivery.

In stock (Shipping 3-14 working days.)

Incorporating a 1/2.5-inch CMOS sensor with 8.51 million effective pixels, the RGBlink vue 4K NDI PTZ Camera offers exceptional 4K resolution at up to 60 frames per second. The 12x optical zoom lens, with a focal length ranging from 3.47mm to 41.65mm and an aperture of F1.84 to F3.72, ensures precise and clear imaging across various shooting scenarios.

This camera supports multiple output interfaces, including 12G-SDI, HDMI 2.0, USB Type-C, IP and NDI|HX2, allowing seamless integration into diverse production workflows. Advanced image processing capabilities, such as wide dynamic range and 3D noise reduction, enhance performance in challenging lighting conditions. The pan and tilt mechanism offers a movement range of -170° to +170° horizontally and -90° to +210° vertically, providing comprehensive coverage with adjustable speed controls.

Equipped with built-in dual microphones and supporting H.265/H.264 dual stream encoding, the camera adapts efficiently to varying network environments, ensuring reliable streaming. The distinctive 360° TALLY indicator light and customizable identification board enhance on-air visibility, facilitating effective communication during live productions.

The inclusion of PoE+ (Power over Ethernet) simplifies installation by reducing the need for separate power supplies. Additional features like low-power sleep mode and stable AI tracking expand its versatility, making it suitable for applications such as broadcast stage design, professional studios, corporate live events, remote conferencing, and more.

UE Shipping

We ship all over the European Union for €20, free shipping on orders over €1,000.

B2B Shop

Our offer is aimed only to B to B Customers, all prices are exclusive of tax.

Secure checkout

Secure online payments via Stripe.

Individual quotation

Send your enquiry via the form or email avgear@avgear.shop

RGBlink 4K vue PTZ camera is designed for professional broadcasting. The 1600TVL resolution lens is equipped with an advanced ISP image processor and 8.51 million pixel sensor (1), providing ultra-clear 4K image quality. Supports 12X/20X optical zoom and a range of outputs from HDMI, 12G-SDI to H.264, H.265, and NDI. It can support a maximum pitch angle of -30°~+210°, truly achieving panoramic vision coverage. Ultra-wide dynamic range provides powerful color performance. vue 4K has a unique TALLY indicator light and identification board, which can be seen from a 360° full viewing angle without fear of device switching. RGBlink 4K vue PTZ camera is suitable for any scene, including radio and television stage design, professional studios, corporate live broadcasts, character interviews, remote conferences, wedding hotels, outdoor live broadcasts, education and training, e-sports live broadcasts, church live broadcasts, etc.

Key Features
- Stable AI Tracking
- Resolution up to 3840x2160@60
- High performance in low light scenarios with Wide Dynamic Range
- H.265/H.264 Dual Stream Output Adapted to Different Network Environments
- 12G-SDI | HDMI2.0 | USB Type-C Multiple Output
- Pan and Tilt Control
- Built-in Dual Microphones
- NDI|HX2 output
- Support TALLY
- Support PoE+
- Low-power Sleep Function
- Wide Application

Specification

Connectors

Video Output
SDI: 1xBNC
HDMI: 1xHDMI 2.0
USB: 1xUSB Type-C
NDI" 1xRJ45
LAN(PoE+): 1xRJ45

Audio
IN: 1x3.5mm TRS Stereo Jack
Built-in: Dual Microphones

Communication
RS232 In/Out: 1×DIN-8
RS422/485: 1×4-Pin Phoenix Connector (RS485-2PIN | RS422-4PIN)
LAN: 1×1000M LAN Port

Performance

Camera
Optical Zoom: 12X
Focal Length: f = 3.47mm ~ 41.65mm
Aperture: F1.84 ~ F3.72
Horizontal View Angle: 81° ~ 7.5°
Vertical View Angle: 50° ~ 4.3°
CMOS Sensor: 1/2.5 inch
Effective Pixels: 8.51m
Digital Zoom: 16X
Minimum Illumination: 0.5 Lux（@F1.8, AGC ON）
DNR: 3D DNR
White Balance: Auto / Manual/ One Push/ Indoors/ Outdoors/VAR
Focus/Iris/Shutter: Auto / Manual
BLC: ON/OFF
Dynamic Range: OFF/ Dynamic Level Adjustment
Video Adjustment: Brightness/Hue/Saturation/Contrast/Sharpness/B/W Mode/Gamma Curve
Image Flip: Auto / Manual
Image Freeze: Supported
SNR: ≥55dB
Lens Resolution: 1600TVL+ (Central Area)

Pan-and-Tilt Parameter
Pan/Tilt Movement: -170°～+170°/-90°～+210°
Pan/Tilt Control Speed: 1.8～100°/s；1.5～60°/s
Preset Speed/Quantity: Pan:100°/s(max), Tilt:60°/s(max); Up to 255 preset positions (10 remote control)
360° TALLY: Full 360° view of TALLY
TALLY Signboard: (No.1~255)

Output Resolutions
HDMI & SDI
3840x2160p60/59.94/50/30/29.97/25
1080p60/59.94/50/30/29.97/25
1080i60/59.94/50
720p60/59.94/50
Network
(H.265 / H.264 / MJPEG) 3840x2160, 1920x1080, 1280x720 etc.
(First Stream: 32kbps~51200kbps Second Stream: 32kbps~20480kbps)

Power
Input Voltage: DC 12V/1.5A
Max Power: 18W

Environment
Temperature: 0℃～40℃
Humidity: 20%～80%

Physical
Weight: 2.27kg
Dimension: 212mm x 176mm x 232mm

Reference RGB12X-UNAI-OL

In stock (Shipping 3-14 working days.) 1 Item

Data sheet

Video Output: HDMI
NDI
RJ-45 (IP)
SDI
USB
Audio Input: Built-in microphone
Mini Jack 3.5mm
Audio Output: HDMI Embedded
NDI Embedded
RJ-45
SDI Embedded
USB
Max Output Resolution: 4K UltraHD (3840 x 2160) 50/60 fps
Control protocol for PTZ cameras: NDI
ONVIF
PELCO-D
PELCO-P
RS-232
RS-422
RS-485
UVC
VISCA
VISCA IP
Network Connection: Ethernet
Sensor Size: 1/2.5"
Optical Zoom: 12x
PoE Technology: Yes
Auto-Tracking: Yes
Tally Light: Yes
