Telycam Explore WH is a PTZ camera built around a 9 MP 1-inch CMOS sensor, delivering UHD 4K60 over 12G-SDI, HDMI 2.0, NDI®|HX3 and SFP+. Its 20× optical zoom (f=9.79–186.5 mm, F2.8–F4.5) spans 71°–4.05° horizontal, 39.6°–2.2° vertical and 78.5°–4.6° diagonal angles. PDAF secures fast, stable focus, while minimum illumination reaches 0.5 lx (50 IRE, 1/30, F1.8). Working distance is 15 cm at wide and 1.5 m at tele for confident tight shots.
Motion control is precise: pan −176° to +176° and tilt −90° to +90° at 0.1–80°/s and 0.1–60°/s, with 0.1° preset accuracy and up to 256 presets. A built-in variable ND filter (1.6%, 6.3%, 25%, 100%) stabilizes exposure under changing key light. Genlock maintains frame-accurate sync for multi-camera workflows in OB vans, XR volumes or virtual sets. The head supports VISCA over IP, VISCA, PELCO-P/D, ONVIF and FreeD for tracked graphics, with tally and native AI auto-tracking for presenter workflows.
I/O is comprehensive: PoE++ for single-cable power and data, gigabit Ethernet, Mini-XLR with phantom power and 3.5 mm line-in, dual microSD slots (one for firmware, one for local recording), plus USB-C with UVC/UAC. Encoders support H.264/H.265 with CBR/VBR up to 122.8 Mbps. Network delivery includes SRT, RTSP, RTMP, HTTP and WebRTC, with multicast RTP available. Matching 2160p60 4K, 1080p and 720p formats are exposed in parallel across SDI/HDMI/SFP+/IP for program, clean and confidence feeds.
Image controls cover 2D/3D NR, gamma, extensive WB modes (Auto/Manual/ATW/Push/Indoor/Outdoor/Color-Temp), backlight compensation and anti-flicker at 50/60 Hz. S/N is ≥50 dB. Operating from −10 °C to 50 °C, Telycam Explore WH measures 232.5 × 264 × 269 mm and weighs 4.6 kg (10.15 lb). For studios, live events and broadcast flypacks, it unites cinematic optics, very solid sync and multi-protocol IP in a compact head.
Telycam Explore WH PTZ Camera
Explore WH
Price: €5,390.00
No tax
We offer EU-wide sales, invoicing for VAT-free intra-community delivery.
Available from supplier (Delivery time to be confirmed.)
Telycam Explore WH is a PTZ camera built around a 9 MP 1-inch CMOS sensor, delivering UHD 4K60 over 12G-SDI, HDMI 2.0, NDI®|HX3 and SFP+. Its 20× optical zoom (f=9.79–186.5 mm, F2.8–F4.5) spans 71°–4.05° horizontal, 39.6°–2.2° vertical and 78.5°–4.6° diagonal angles. PDAF secures fast, stable focus, while minimum illumination reaches 0.5 lx (50 IRE, 1/30, F1.8). Working distance is 15 cm at wide and 1.5 m at tele for confident tight shots.
Motion control is precise: pan −176° to +176° and tilt −90° to +90° at 0.1–80°/s and 0.1–60°/s, with 0.1° preset accuracy and up to 256 presets. A built-in variable ND filter (1.6%, 6.3%, 25%, 100%) stabilizes exposure under changing key light. Genlock maintains frame-accurate sync for multi-camera workflows in OB vans, XR volumes or virtual sets. The head supports VISCA over IP, VISCA, PELCO-P/D, ONVIF and FreeD for tracked graphics, with tally and native AI auto-tracking for presenter workflows.
I/O is comprehensive: PoE++ for single-cable power and data, gigabit Ethernet, Mini-XLR with phantom power and 3.5 mm line-in, dual microSD slots (one for firmware, one for local recording), plus USB-C with UVC/UAC. Encoders support H.264/H.265 with CBR/VBR up to 122.8 Mbps. Network delivery includes SRT, RTSP, RTMP, HTTP and WebRTC, with multicast RTP available. Matching 2160p60 4K, 1080p and 720p formats are exposed in parallel across SDI/HDMI/SFP+/IP for program, clean and confidence feeds.
Image controls cover 2D/3D NR, gamma, extensive WB modes (Auto/Manual/ATW/Push/Indoor/Outdoor/Color-Temp), backlight compensation and anti-flicker at 50/60 Hz. S/N is ≥50 dB. Operating from −10 °C to 50 °C, Telycam Explore WH measures 232.5 × 264 × 269 mm and weighs 4.6 kg (10.15 lb). For studios, live events and broadcast flypacks, it unites cinematic optics, very solid sync and multi-protocol IP in a compact head.
UE Shipping
We ship all over the European Union for €20, free shipping on orders over €1,000.
B2B Shop
Our offer is aimed only to B to B Customers, all prices are exclusive of tax.
Secure checkout
Secure online payments via Stripe.
Individual quotation
Send your enquiry via the form or email avgear@avgear.shop
High-Performance Sensor and Image Processor
Explore's Sony 1-inch CMOS sensor delivers broadcast-grade imaging. Engineered for low-light excellence, it captures vivid detail with minimal noise while achieving cinematic depth of field. Enhanced light sensitivity ensures razor-sharp subject focus with artful background blur - the ultimate choice for professional production.
PDAF (Phase Detection Auto Focus)
Experience seamless and precise focusing with our PTZ camera's advanced AI Auto Focus. Whether for live events or VR production, Telycam’s PDAF auto-focus empowers you with fast and accurate focus for premium-quality footage.
Versatile Output Options with Robust Audio Capabilities
The Explore offers diverse output options including 4K60p through NDI®, NDI®HX3, 12G-SDI, HDMI, and SFP+, along with 3.5mm line-in and Mini XLR with Phantom power for compatibility with various microphones and audio equipment, ensuring great flexibility and compatibility for Telycam users.
Genlock Functionality
The Explore features Genlock for better synchronization. This allows it to function as the main camera, ensuring precise video synchronization with sub-cameras in broadcasting and live streaming setups.
Built-in ND Filters for Light Management
Explore features a built-in variable ND filter adjustable to 1.6%, 6.3%, 25%, and 100%, with the option to attach custom ND filters for precise lighting control.
Native AI-Based Auto-Tracking
The Explore features AI-based auto-tracking, automatically following subjects to enhance ease of use and capture the moments flawlessly.
FreeD Technology Integration
The Explore integrates FreeD technology for versatile shooting angles, ideal for both real-world and virtual applications.
MicroSD Card Slots
The Explore features two MicroSD card slots – one for firmware upgrades and the other for local recording. Record directly onto the camera for instant backup during network issues or quick access, ideal for prompt event review.
Specifications
Camera
Part NO. TLC-900-IP-20-4K(NDI)-AB
1 inch, 9MP UHD CMOS sensor
20X optical zoom
Lens: f=9.79~186.5mm, F2.8~F4.5
Horizontal View Angle: 71°(Wide)~4.05°(Tele)
Vertical Viewing Angle: 39.6°~2.2°
Diagonal Viewing Angle: 78.5°~4.6°
Minimum Working Distance: Wide: 15cm; Tele: 150cm
S/N Ratio: ≥50dB
Image Parameters
Noise Reduction: 2D&3D
Minimum lux: 0.5Lux(50 IRE Max AGC, 1/30, F1.8)
White Balance: Auto/Manual/ATW/Push/Indoor/Outdoor/Color Temperature
Exposure: Auto/Manual/Shutter Priority/Iris Priority/Brightness Priority
Anti-Flicker: OFF, 50Hz, 60Hz
Image Flip/Mirroring: Supported
Focus/Iris/Electronic-shutter: Auto/Manual
Gamma: Supported
Backlight Compensation: Supported
Video Format
12G-SDI: 3840*2160P60/50/30/25/59.94/29.97/24/23.98;
1920*1080P60/50/30/25/59.94/29.97/24/23.98;
1920*1080I60/50/59.94; 1280*720P60/50/30/25/59.94/29.97
3G-SDI(Crop Only): 1920*1080P60/59.94/50/30/29.97/25/24/23.98;
1920*1080I60/59.94/50; 1280*720P60/59.94/50/30/29.97/25
HDMI2.0: 3840*2160P60/50/30/25/59.94/29.97/24/23.98;
1920*1080P60/50/30/25/59.94/29.97/24/23.98;
1920*1080I60/50/59.94; 1280*720P60/50/30/25/59.94/29.97
NDI® / NDI®HX3: Main Stream: 3840*2160P15~60; 1920*1080P15~60; 1280*720P15~60; 1024*576P15~60;
Sub Stream: 640*360P15~30
SFP+: 3840*2160P60/50/30/25/59.94/29.97/24/23.98;
1920*1080P60/50/30/25/59.94/29.97/24/23.98;
1920*1080I60/50/59.94; 1280*720P60/50/30/25/59.94/29.97
USB Type-C: NV12: 1920*1080P5; 1280*720P15; 1024*576P25; 800*448P30
YUYV: 1920*1080P5; 1280*720P15; 1024*576P25; 800*448P30
MJPG: 3840*2160P30; 1920*1080P60; 1280*720P60; 1024*576P60; 800*448P60
H264/H265: 3840*2160P30; 1920*1080P60; 1280*720P60; 1024*576P60; 800*448P60
IP Streaming
Video Encoding: H.264/H.265
Bitrate Control: Variable bitrate(VBR), Constant bitrate(CBR)
Bitrate Range: 1024Kbps~122800Kbps
Network Port Speed: 1000M
Protocol: NDI®,NDI®HX3, SRT, HTTP, RTSP, RTMP, ONVIF, VISCA over IP(TCP&UDP), VISCA, PELCO P/D, SSDP, FreeD, NTP, RTP Multicast, WebRTC
Pan/Tilt Movement
Preset: Remote controller: 10; Serial port: 256; Accuracy：0.1°
Pan Rotation Angle: -176°~+176°
Tilt Rotation Angle: -90°~+90°
Pan Rotation Speed: 0.1°~80°/s
Tilt Rotation Speed: 0.1°~60°/s
I/O Interface
Control Port: RS232, RS485, RS422, RJ45, USB, NDI®HX3
Video Port: NDI®, NDI®HX3, HDMI 2.0, 12G-SDI, 3G-SDI, SFP+, USB Type-C
Audio Port: Mini XLR(with phantom power), stereo 3.5mm line in
Tally: Supported
POE++: Supported
Daisy Chain: Supported
General
Input Voltage: DC12V, POE++(IEEE802.3bt)
Operating Temperature: -10℃~50℃
Operating Humidity: ≤80%
Dimension(L×W×H): 232.5 mm×264mm×269mm
Net Weight: 4.6kg(10.15LBS)
Color: Black/White
Explore WH
Data sheet
- Video Output
- HDMI
NDI
RJ-45 (IP)
SDI
SFP+
USB - Audio Input
- Mini Jack 3.5mm
Mini XLR - Audio Output
- HDMI Embedded
NDI Embedded
RJ-45
SDI Embedded
USB - Max Output Resolution
- 4K UltraHD (3840 x 2160) 50/60 fps
- Control protocol for PTZ cameras
- NDI
ONVIF
PELCO-D
PELCO-P
RS-232
RS-422
RS-485
VISCA
VISCA IP - Network Connection
- Ethernet
- Sensor Size
- 1"
- Optical Zoom
- 20x
- PoE Technology
- Yes
- Auto-Tracking
- Yes
- Tally Light
- Yes
Specific References
- ean13
- 768486168576
- mpn
- TLC-900-IP-20-4K(NDI)-AB-WHITE
