Telycam Vision+ 4KN 30x WH PTZ Camera

Name: Telycam Vision+ 4KN 30x WH PTZ Camera
Brand: Telycam
SKU: Vision+ 4KN 30X WH
Price: 1899.00 EUR
Availability: InStock

MPN: Vision+ 4KN 30X WH

Price: €1,899.00

No tax

We offer EU-wide sales, invoicing for VAT-free intra-community delivery.

External stock. (Shipping 3-14 working days.)

Telycam Vision+ 4KN 30x WH targets broadcast, live production and AV integrations where precision and protocol breadth matter. Built around a 1/1.8-inch 9MP CMOS and a 30x optical block (6.91–214.64 mm), it outputs UHD 3840×2160 at 60 fps via HDMI 2.0 and NDI|HX, with 3G-SDI up to 1080p60 and USB-C up to 4K30. The lens covers 63°–2.1° horizontal FOV, opens to f/1.35–4.6, focuses from 1.5 m, and maintains 2160 TVL detail with 50 dB SNR and 0.5 lux minimum illumination. pan range is −170° to +170° (0.1–80°/s); tilt −30° to +90° (0.1–60°/s). PoE+ 802.3at supports single-cable installs; tally, 3.5 mm line-in and 1/4-20 plus 3/8-16 mounts cover studio or truss use.

IP workflows are native. NDI|HX3/NDI|HX carry 4K60 over RJ-45; SRT, RTMP and RTSP feed CDNs or private links, while ONVIF eases control. FreeD streams real-time PTZF metadata for AR/VR sets in engines like Unreal and Vizrt. Built-in AI auto-tracking locks on a subject via WebUI, IR remote or VISCA keyboard; switch targets, set zones and adjust box size without external servers. Up to 128 RS-232 presets plus 10 IR presets handle multi-scene moves; image flip/mirror and broadcast rates fit mixed infrastructures.

Colorimetry and clarity hold under stage light thanks to temporal/spatial NR and responsive AF during fast zooms. Multi-interface output enables parallel program, ISO and confidence paths: HDMI for switchers, SDI for legacy chains, NDI for IP production and USB-UVC for conferencing. Daisy-chain control, web API tools shorten commissioning, while the white housing suits worship halls, auditoriums and medical spaces.

For search: 4K60 PTZ, 30x optical zoom, NDI HX3, SRT streaming, FreeD, PoE+, HDMI 2.0, 3G-SDI, USB-C, 1/1.8-inch sensor, 63–2.1° FOV, 1.5 m MFD, 2160 TVL. Telycam Vision+ 4KN 30x WH fits studio, event and streaming pipelines that need precise control, stable color and low-latency transport.

UE Shipping

We ship across the EU for €20, free over €1,000.

B2B Shop

B2B sales only, prices excl. VAT.

Safe Shopping

Official EU distribution and warranty.

Secure checkout

Secure online payments via Stripe.

Individual quotation

Send your enquiry via the form or email avgear@avgear.shop

4K UHD Resolution
Equipped with cutting-edge image processor, Vision+ 4KN outputs 4Kp60/59.94 video for clear, sharp, lifelike images even in low-light environments.

Built-in Auto Tracking function
With its built-in auto-tracking function, users can track targets, switch targets, set target areas, or adjust target size effortlessly without any third party softwareor device.

FreeD
The Vision+ 4KN integrates FreeD technology for versatile shooting angles, ideal for both real-world and virtual applications.

NDI®HX3 /3G-SDI/HDMI2.0/USB2.0 Available
The device supports NDI®HX3 and HDMI2.0 outputs at 4Kp60/59.94 simultaneously, 3G-SDI(Level A and B) outputs 1080p60/59.94, and USB-C output up to 4K30.

Specifications

Vision+ 4KN 30x
Part NO. TLC-700-IP-30-4K(NDI)-AB
1/1.8 inch, 9MP UHD CMOS sensor
30X optical zoom
Lens: f= 6.91~214.64mm, F1.35~F4.6
Horizontal View Angle: 63°(Wide)~2.1°(Tele)
Vertical Viewing Angle: 34.14°~1.12°
Diagonal Viewing Angle: 67.08°~2.27°
Minimum Working Distance: 1.5m
S/N Ratio: ≥50dB

Video Format
HDMI2.0: 3840*2160P 60/59.94/50/30/29.97/25；1920*1080P 60/59.94/50/30/29.97/25/24/23.98; 1920*1080I 60/59.94/50; 1280*720P 60/59.94/50/30/29.97/25
NDI®HX3: Main Stream: 3840*2160P15~60; 1920*1080P15~60; 1280*720P15~60; 1024*576P15~60;
Sub Stream: 640*360P15~30
3G-SDI: 1920*1080P60/59.94/50/30/29.97/25/24/23.98; 1920*1080I60/59.94/50; 1280*720P60/59.94/50/30/29.97/25
USB Type-C: NV12: 1920*1080P5;1280*720P15; 1024*576P25; 800*448P30;
YUYV: 1920*1080P5;1280*720P15;1024*576P25; 800*448P30;
MJPG: 3840*2160P30;1920*1080P60; 1280*720P60;1024*576P60;800*448P60;
H264/H265:3840*2160P30;1920*1080P60; 1280*720P60;1024*576P60;800*448P60

Image Parameters
Noise Reduction: 2D&3D
Minimum lux: 0.5Lux (50 IRE Max AGC, 1/30, F1.8)
White Balance: Auto/Manual/ATW/Push/Indoor/Outdoor/Color Temperature
Exposure: Auto/Manual/Shutter Priority/Iris Priority/Brightness Priority
Anti-Flicker: OFF, 50Hz, 60Hz
Image Flip: Supported
Mirroring: Supported
Focus: Auto/Manual
Iris: Auto/Manual
Electronic-shutter: Auto/Manual

IP Streaming
Video Encoding: H.264/H.265
Bitrate Control: Variable bitrate(VBR), Constant bitrate(CBR)
Bitrate Range: 1024Kbps~122800Kbps
Network Port Speed: 1000M
Protocol: NDI®HX3, SRT, HTTP, RTSP, RTMP, ONVIF, VISCA over IP(TCP&UDP), VISCA, PELCO P/D, SSDP, FreeD, NTP, RTP Multicast, WebRTC

Pan/Tilt Movement
Preset: Remote controller: 10; Serial port: 256; Accuracy: 0.1°
Pan Rotation Angle: -176° ~+176°
Tilt Rotation Angle: -30° ~+90°
Pan Rotation Speed: 12X: 0.1°~120°/s 20X: 0.1°~80°/s 30X: 0.1~80°/s
Tilt Rotation Speed: 12X: 0.1°~80°/s 20X: 0.1°~60°/s 30X: 0.1°~60°/s

I/O Interface
Control Port: RS232(RS485), NDI®HX3
Video Port: NDI®HX3, HDMI 2.0, 3G-SDl, USB Type-C
Audio Port: stereo 3.5mm linear inputs
Tally: Supported
POE+: Supported
Daisy Chain: Supported

General
Input Voltage: DC12V, POE+(IEEE802.3at)
Operating Temperature: -10℃~50℃
Operating Humidity: ≤80%
Dimension(L×W×H): 12X: 220mmx190mmx173mm 20X:220mm×190mm×193.5mm 30X: 220mm×190mm×193.5mm
Net Weight: 12X: 1.5kg(3.3LBS) 20X: 1.9kg(4.2LBS) 30X: 1.9kg(4.2LBS)
Color: Black/White

Reference Vision+ 4KN 30X WH

External stock. (Shipping 3-14 working days.) 2 Items

Data sheet

Video Output: HDMI
NDI
RJ-45 (IP)
SDI
USB
Audio Input: Mini Jack 3.5mm
Audio Output: HDMI Embedded
NDI Embedded
RJ-45
SDI Embedded
USB
Max Output Resolution: 4K UltraHD (3840 x 2160) 50/60 fps
Control protocol for PTZ cameras: NDI
ONVIF
PELCO-D
PELCO-P
RS-232
RS-485
VISCA
VISCA IP
Network Connection: Ethernet
Sensor Size: 1/1.8"
Optical Zoom: 30x
PoE Technology: Yes
Auto-Tracking: Yes
Tally Light: Yes
