Telycam Vision+ SE HDMI WH PTZ Camera

    Vision+ SE HDMI WH
    Price: €959.00
    No tax
    We offer EU-wide sales, invoicing for VAT-free intra-community delivery.

    Telycam Vision+ SE HDMI WH is a compact PTZ unit for live production pipelines that need stable 4K60 video, precise motion and IP interoperability. Its 1/2.8-type (≈6.5 mm diagonal) UHD CMOS sensor outputs 3840×2160/60 via HDMI and IP, with a 12× optical zoom (f=3.4–40.3 mm, F1.8–3.6), horizontal FOV 80.5°–7.6°, vertical 50.0°–4.4°. Minimum scene illumination reaches 0.5 lux (50 IRE, 1/30 s), and S/N is ≥50 dB. HDMI provides 2160p15–60, 1080p15–60 and 720p15–60; IP main stream matches these formats for predictable routing. Bitrate control spans CBR/VBR from 1.0 to 122.8 Mbps max.

    Network I/O delivers NDI®HX3 at up to 2160p60 alongside H.264/H.265 streaming for SRT, RTSP, RTMP, ONVIF and WebRTC. USB-C offers MJPEG 2160p30 and 1080p60 for capture appliances, while the embedded 3.5 mm stereo line-in aligns external audio with program video. The camera publishes IP through SSDP for quick discovery, supports VISCA over IP (TCP/UDP), VISCA and PELCO-P/D on RS-232/RS-485, and integrates a bright tally light driven by NDI to mark Program/Preview states.

    Framing and movement remain consistent thanks to native AI auto-tracking with one-touch activation from the web UI, IR remote or Telycam keyboards. FreeD telemetry streams PTZF data to engines such as Vizrt, Brainstorm, Aximmetry and Unreal for AR/VR composites. Mechanics deliver ±170° pan and −30° to +90° tilt, with variable speeds from 0.1°/s to 120°/s (pan) and 0.1°/s to 80°/s (tilt), plus 256 serial presets with 0.1° repeatability.

    Integration is straightforward: PoE+ powers the head over Ethernet, daisy-chain mode simplifies multi-camera cabling, and the body measures 220 × 190 × 173 mm for unobtrusive placement. Operating range is −10 °C to 50 °C, ≤80 % RH. For workflows that mix switchers, recorders, and IP production tools, the Telycam Vision+ SE HDMI WH consolidates HDMI, NDI®HX3, USB-C and broadcast-style control into one dependable PTZ endpoint.

    Quantity
    Add to Wishlist
    Add to Compare
    Last items in stock

    UE Shipping

    We ship across the EU for €20, free over €1,000.

    B2B Shop

    B2B sales only, prices excl. VAT.

    Safe Shopping

    Official EU distribution and warranty.

    Secure checkout

    Secure online payments via Stripe.

    Individual quotation

    Send your enquiry via the form or email avgear@avgear.shop

    Unparalleled 4K UHD Brilliance
    Equipped with cutting-edge image processor, Vision+ SE outputs 4Kp60/59.94 video for clear, sharp, lifelike images even in low-light environments.

    One-Touch Auto-Tracking Precision
    The Vision+ SE offers AI-powered auto-tracking with no third-party tools required. The auto-tracking can be instantly activated with a simple click in the Web UI, remote control, or Telycam V-Joy+ keyboard. Tracking can be customized effortlessly for specific people, areas or sizes.

    Enhanced Reality with FreeD
    Bridging worlds with the embedded FreeD protocol. Easily sync PTZF data with your VR/AR systems, expanding your creative possibilities.

    Magnify with 12x Optical Mastery
    With a 4K 12X optical zoom and an expansive 80.5-degree FOV, coupled with a custom focusing algorithm, every zoom and pan translates to a journey through intricate details.

    Adaptable Streaming Elegance
    Our camera adapts seamlessly with NDI®HX3 output at 4Kp60/59.94, 3G-SDI(A/B levels), and USB-C up to 1080p60/59.94, enhancing streaming versatility.

    Integrated NDI® Ecosystem
    Integrated with Newtek's NDI® SDK, our camera is a cornerstone in the plug-and-play live streaming universe.

    Intuitive Tally Indication
    The camera's indicator doubles as a Tally light, synchronizing with NDI® device notifications and monitoring your live stream's status.

    Specifications

    TLC-300-IP-12-4K(NDI)-AB-SE-HDMI
    1/2.8 inch, 9MP UHD CMOS sensor
    12X optical zoom
    Lens: f=3.4mm~40.3 mm, F1.8~F3.6
    Horizontal View Angle: 80.5°(Wide)~7.6°(Tele)
    Minimum Working Distance: Wide: 1m Tele: 1.5m
    Vertical Viewing Angle: 50.0°~4.4°
    Diagonal Viewing Angle: 88.9°~8.7°
    S/N Ratio: ≥50dB

    Image Parameters
    Noise Reduction: 2D&3D
    Minimum lux: 0.5Lux(50 IRE Max AGC, 1/30, F1.8)
    White Balance: Auto/Manual/ATW/Push/Indoor/Outdoor/Color Temperature
    Exposure: Auto/Manual/Shutter Priority/Iris Priority/Brightness Priority
    Anti-Flicker: OFF, 50Hz, 60Hz
    Image Flip: Supported
    Mirroring: Supported
    Focus: Auto/Manual
    Iris: Auto/Manual
    Electronic-shutter: Auto/Manual
    Gamma: Supported
    Backlight Compensation: Supported

    Video Format
    NDI®HX3: Main Stream: 3840*2160P15~60; 1920*1080P15~60; 1280*720P15~60; 1024*576P15~60; Sub Stream: 640*360P15~30
    HDMI: 3840*2160P15~60; 1920*1080P15~60; 1280*720P15~60; 1024*576P15~60;
    USB Type-C: NV12: 1920*1080P5;1280*720P15; 1024*576P25;800*448P30; YUYV: 1920*1080P5;1280*720P15; 1024*576P25;800*448P30; MJPG: 3840*2160P30;1920*1080P60; 1280*720P60;1024*576P60; 800*448P60; H264/H265:3840*2160P30; 1920*1080P60; 1280*720P60;1024*576P60; 800*448P60

    IP Streaming
    Video Encoding: H.264/H.265
    Bitrate Control: Variable bitrate(VBR), Constant bitrate(CBR)
    Bitrate Range: 1024Kbps~122800Kbps
    Network Port Speed: 1000M
    Protocol: NDI®HX3, SRT, HTTP, RTSP, RTMP, ONVIF, VISCA over IP(TCP&UDP), VISCA, PELCO P/D, SSDP, FreeD, NTP, RTP Multicast, WebRTC

    Pan/Tilt Movement
    Preset: Remote controller: 10; Serial port: 256; Accuracy: 0.1°
    Pan Rotation Angle: -170°~+170°
    Tilt Rotation Angle: -30°~+90°
    Pan Rotation Speed: 0.1°~120°/s
    Tilt Rotation Speed: 0.1°~80°/s

    I/O Interface
    Control Port: RS232(RS485), NDI®HX
    Video Port: NDI®HX3, HDMI, USB Type-C
    Audio Port: stereo 3.5mm linear inputs
    Tally: Supported
    POE+: Supported
    Daisy Chain: Supported

    General
    Input Voltage: DC12V, POE+(IEEE802.3at)
    Operating Temperature: -10℃~50℃
    Operating Humidity: ≤80%
    Dimension(L×W×H): 220mmx190mmx173mm
    Color: Black/White

    Vision+ SE HDMI WH
    1 Item

    Data sheet

    Video Output
    HDMI
    NDI
    RJ-45 (IP)
    USB
    Audio Input
    Mini Jack 3.5mm
    Audio Output
    HDMI Embedded
    NDI Embedded
    RJ-45
    USB
    Max Output Resolution
    4K UltraHD (3840 x 2160) 50/60 fps
    Control protocol for PTZ cameras
    NDI
    PELCO-D
    PELCO-P
    RS-232
    RS-485
    VISCA
    VISCA IP
    Sensor Size
    1/2.8"
    Optical Zoom
    12x
    PoE Technology
    Yes
    Auto-Tracking
    Yes
    Tally Light
    Yes

    Specific References

    ean13
    768486167654
    mpn
    TLC-300-IP-12-4K(NDI)-AB-SE-HDMI-WHITE
