Magewell Pro Convert HDMI Plus Modator Module

Magewell Pro Convert HDMI Plus Modator Module

Name: Magewell Pro Convert HDMI Plus Modator Module
Brand: Magewell
SKU: B40210000
Price: 549.00 EUR
Availability: InStock

MPN: B40210000

Price: €549.00

No tax

We offer EU-wide sales, invoicing for VAT-free intra-community delivery.

External stock. (Shipping 3-14 working days.)

The Magewell Pro Convert HDMI Plus module converts any HDMI source into a broadcast-grade NDI 6.2 stream, packaged as a hot-swappable card for the Modator 2U chassis. Ten modules fit in one 2 RU rack frame, so a multi-camera studio can run all its HDMI-to-NDI encoding from a single, centrally managed unit. Input resolution reaches 4096×2160 at 60 fps (4:2:0) or 30 fps (4:4:4), while an HDMI 1.4 loop-through mirrors the signal to a confidence monitor without extra distribution hardware — a welcome simplification on set or inside an OB truck.

Encoding tops out at 2048×2160 / 120 fps in 4:2:2 8-bit with a measured latency around 57 ms. Eight channels of HDMI-embedded audio carry over to the NDI output intact. Onboard processing covers deinterlacing, up/down-scaling, colour-space conversion across RGB and YUV (BT.601, BT.709), and aspect-ratio correction via anamorphic, crop, or letterbox modes. A configurable EDID lets the module request the exact format it needs from the source, avoiding handshake failures that surface during live shows.

Each card has its own Gigabit Ethernet port, allowing NDI traffic to be segmented onto dedicated switches — a tangible benefit when production and corporate networks must stay separate. An RS-232 serial connection handles PTZ camera control and tally relay, fitting naturally into robotic-camera rigs found in houses of worship, lecture halls, and TV studios. Setup runs through the Modator touchscreen, a browser GUI, or Magewell Control Hub for fleet-wide oversight; Crestron SIMPL+ modules plug the encoder into existing AV-over-IP control systems.

Power draw sits at just 6.2 W per card, and the Modator chassis supports redundant power supplies, keeping the system on air through a single-supply failure. Streams produced by the module work natively with OBS, vMix, Wirecast, and every other NDI-compatible application, giving crews a direct path from camera to switcher or cloud distribution — no proprietary lock-in.

UE Shipping

We ship across the EU for €20, free over €1,000.

B2B Shop

B2B sales only, prices excl. VAT.

Safe Shopping

Official EU distribution and warranty.

Secure checkout

Secure online payments via Stripe.

Individual quotation

Send your enquiry via the form or email avgear@avgear.shop

The Pro Convert HDMI Plus Module is a hot-swappable module designed to be installed in the Magewell Modator chassis, allowing you to convert HD HDMI input signals into high-bandwidth NDI streams with support for loop-through. It supports a variety of HDMI input resolutions, including up to 4096x2160 at 60fps (4:2:0) or 30fps (4:4:4), providing flexibility for different types of video sources. The module is centrally manageable via the Modator chassis and Magewell Control Hub, offering ease of integration into your production environment. A standalone version of this module is also available for those who prefer a separate solution.

The Pro Convert HDMI Plus Module delivers high-quality NDI encoding with very low latency, making it suitable for real-time video streaming and live production applications. It supports up to 2048x2160 at 120fps 4:2:2 8-bit NDI encoding and includes the ability to encode 8-channel NDI-embedded audio. It also fully supports NDI 5.x for compatibility with the latest NDI standards. With its intuitive control options, including the Modator chassis touchscreen, Web GUI, or Magewell Control Hub, users can easily configure and manage the module, while HTTP-based APIs enable custom integrations to suit specific workflows.

Features & Advantages:
Very low latency ensures real-time conversion and minimal delay, essential for live production and broadcast applications.
Configuration is simplified through the touch screen of the Modator chassis, Web GUI, or Magewell Control Hub, offering intuitive and user-friendly management options.
HTTP-based APIs provide flexibility for custom integrations, enabling tailored control and monitoring for specific production workflows.

Pro Convert HDMI Plus Module Specifications

Interfaces
1* RJ45 1000Mbps Ethernet port
1* USB Type-C port for configuration
1* HDMI 1.4 input port
1* HDMI 1.4 output port
1* Modator interface for connecting to Modator 2U (hot-swappable)

Input & Loop Through Features
Max. input & loop through signal:
4096x2160 30fps 4:4:4/4:2:2
4096x2160 60fps 4:2:0
Input videos at any format by customizing the EDID of input port
Supports RGB and YUV BT.601/709 signals
Supports 8-channel HDMI-embedded audio

NDI® Encoding Features
Encode and output real-time streams of NDI High Bandwidth® at up to 2048x2160 120fps 4:2:2 8-bit
Output the same resolution as input or any custom resolution. Typical outputs include:
2048x1080p/1920x1080p 23.98/24/25/29.97/30/50/59.94/60
1280x720p 23.98/24/25/29.97/30/50/59.94/60/100/119.88/120
1920x1080i 25/29.97/30/50/59.94/60
720x480p/720x480i 59.94/60/119.88/120
720x576p/720x576i 50/100
Output frame rate same as the original, 1/2, 1/3 or 1/4 of input frame rate
Encode 8-channel NDI-embedded audio
Supports NDI® 6.2

Web UI
Register with Magewell Control Hub for remote centralized management
Supports configuring and managing via Web UI
Provides comprehensive information regarding the device and signals in real-time
Allow to configure how a signal is encoded and output, including deinterlacing, EDID settings, up/down scale, frame rate, aspect ratio, as well as the network connection
Supports updating firmware
Supports USB RNDIS/ECM
Supports IE/Edge/Firefox/Chrome/Safari/Opera web browsers
Provides HTTP APIs

LED Indicators
Input signal:
On: locked
Off: unlocked
Loop through signal:
On: device connected and signal detected
Off: undetected

Physical Specifications
Form factor: 184.4mm (L) x 30.0mm (W) x 81.5mm (H)
Weight: ≈295g

Power Consumption
Max power consumption: 6.2W

Working Environment
Operating temperature: 0 to 50 deg C
Storage temperature: –20 to 70 deg C
Relative humidity: 5% to 90% non-condensing
