A New Standard for PTZ Cameras
The Move 4K is the latest PTZ camera from PTZOptics, featuring auto-tracking for a more intelligent video production workflow. The Move 4K is capable of 4K at 60fps (1080p at 60fps over SDI), future-proofing your technology investment while still accommodating HD and Full HD video resolutions equipment. The Move 4K offers high performance in low-light scenarios, PoE+ capabilities, and a built-in tally light.

Designed with the Future in Mind
Every Move 4K camera features SDI, HDMI, USB, and IP output, and comes native with NDI®|HX for unparalleled performance and versatility. The Move 4K offers built-in auto-tracking capabilities — no need to run software on another computer — freeing teams of the need for a camera operator.

Pan, Tilt, Zoom, Track.
Control your production from behind the scenes – or right in front of them. The Move 4K’s auto-tracking can lock into a specific person, even while other people are in frame. Users can switch between on-stage presenters with the click of a button. The Move 4K can track subjects up to 300 feet away.In addition to the Move 4K’s auto-tracking features, users will also have access to our latest Web UI — updated to provide everything you need in one simple menu. Almost every feature in the Web UI has a tutorial function, perfect for novice producers navigating the settings for the first time.

Discreet Mounting Options
Mount your PTZOptics Move 4K camera above, below or beside the action to capture the ideal view every time. The new automatic video inversion feature senses the camera’s orientation and saves time on installation and setup.

PTZOptics Move 4K series has the following mounts:
Wall Mounts
Ceiling Mounts
Pole Mounts
Outdoor Enclosures

Take Control Your Way
Users can control Move 4K cameras using video production software such as OBS, Livestream Studio, Wirecast, vMix, mimoLive or Tricaster — or check out one of our hardware joystick controllers such as our IP joystick, serial joystick, or the SuperJoy. The options for camera control are endless, allowing you to take charge of your camera in a way that fits your workflow.

Move 4K cameras can be controlled remotely from anywhere in the world using a variety of tools, including NDI® and cloud-based software such as Zoom. Users can also live stream directly to content delivery networks such as Facebook and Youtube.

Free Software for PTZOptics Camera Users
Invigorate your meetings and presentations with NewBlueFX Titler Live 5 Present, now free for any PTZOptics customer. Create stunning graphics and data visualizations in minutes with this easy-to-use software, or use it to control your PTZOptics camera from anywhere on the network. To apply for your free 6-month license or for more information on Titler Live 5 Present, visit ptzoptics.com/newbluefx.

Unrivaled Warranties
With robust warranties included standard on every product, you can trust PTZOptics solutions to deliver high performance from day one, and for many years to follow. The Move 4K comes with a 5-year limited parts and labor warranty. PTZOptics stands by our promise to protect your investment by providing repairs or replacement products for the duration of your warranty.

Key Features:
• UltraHD 4K (3840x2160p) video resolutions up to 60 FPS
• Built-in auto-tracking capabilities
• 20X optical zoom lens with a 60.7° horizontal field of view
• High performance in low light scenarios with Wide Dynamic Range
• 3D noise reduction with our latest “low noise CMOS sensor”
• Serial (RS232 & RS485) & IP control (LAN/WAN)
• H.264, H.265, & MJPEG video compression when IP streaming
• USB 2.0, HDMI 2.0 / 3G-SDI, NDI®|HX 3 / IP streaming (SRT, RTSP, RTMP)
• PoE (Power over Ethernet) or 12VDC power supply
• Built in tally light
• Photobooth capable
• 5-year warranty

What’s in the Box:
• Camera
• AC Power Supply
• USB A-A Cable
• RS232 Cable
• Quick Start Guide
• IR Remote
• 2 AA Batteries

PTZOptics Move 4K PT20X-4K-GY-G3 specifications :
Video Sensor: 1/1.8 inch, CMOS, Effective pixels: 8.42M
Lens: f = 6.25mm ~ 125mm, F1.58 ~ F3.95
Lens (35mm Equivalencies): 31mm ~ 589mm, F1.58 ~ F3.95
Resolution and Frame Rate HDMI: 3840x2160p-60/59.94/50/30/29.97/25, 1920x1080p60/59.94/50/30/29.97/25, 1920x1080i-60/59.94/50, 1280x720p-60/59.94
SDI: 1920x1080p-60/59.94/50/30/29.97/25,1920x1080i-60/59.94/50, 1280x720p-60/59.94
Digital Zoom Off (3840x2160), 2X (1920x1080), 3X (1280x720), 4X (960x540), 8X (480x270), 16X (256x144)
Field of View: Horizontal: 3.5° (tele) ~ 60.7° (wide), Vertical: 1.9° (tele) ~ 34.1° (wide)
Min. Lux 0.5 Lux @ (F1.8, AGC ON)
Shutter 1/30s ~ 1/10000s
Pan Speed 1.7° ~ 100°/s
Tilt Movement +90° to -30
Tilt Speed 1.7° ~ 69.9°
Presets 255 Presets
Video Tracking Supported
Image Flip, Mirror and Freeze Supported
Power Supply DC 12V / PoE+ (802.3at)
Input Power 18W (Max)
Material Aluminum, Plastic
Color White
Dimensions (W x D x H) : 5.57 x 5.94 x 7.91 in., 168.4 x 141.5 x 164.5 mm
Weight : 3.25 lbs (1.47 kg)
Working Environment Indoor
Operating Temperature 14°F ~ 104°F (-10°C to 40°C)
Storage Temperature -40°F ~ 140°F (-40°C to 60°C)
HD Video Output 1x RJ45: 10/100/1000M Adaptive Ethernet Port424M standard
1x HDMI: version 2.0
1x USB 2.0: type A
1x 3G-SDI: BNC type, 800mVP-p, 75Ω, Along to SMPTE 424M standard
Audio Interface 1x 3.5mm Line level Input
Communication Interface 1x 8 pin Mini-din RS232 input, Max distance: 98.5ft / 30m, protocol: VISCA / Pelco-D / Pelco-P
1x 8 pin Mini-din RS232 output, Max distance 98.5ft / 30m, protocol: VISCA / Pelco-D / Pelco-P
1x 2 pin Phoenix port, RS485 input / output, Max distance 3,937ft / 1200m, protocol: VISCA / Pelco-D / Pelco-P
Network Interface RJ45: 10/100/1000M Adaptive Ethernet Port, supports PoE
Power Jack JEITA type (DC IN 12V)

PTZOptics SUPERJOY PT-SUPERJOY-G1

Introducing the new SuperJoy Joystick Controller supporting Network and Serial Camera Control. Experience the full capabilities by pairing it with PTZOptics or HuddleCamHD cameras.

Create a Powerful, Precise and Versatile Production Experience
Introducing the PTZOptics SuperJoy, a PTZ camera joystick controller designed for smooth, efficient production workflows. The SuperJoy takes remote pan, tilt, and zoom camera operations to the next level in a simplified user interface with advanced controls for power users. The SuperJoy offers an intuitive, tactile interface, simplifying and streamlining even the most complex production setups.

SuperJoy’s HDMI video output provides a 1080p video preview for any camera connected to the SuperJoy that has an RTSP video feed available for use. This HDMI video output is ideal for viewing cameras over a local area network. In this way, a SuperJoy controller can be set up anywhere on a network to gain PTZ camera controls with a low-latency, live video preview.

Ergonomic, rubberized controls and pressure-sensitive dials for precise, on-the-fly-tuning, with no OSD adjustments required

Status-responsive backlit buttons and knobs indicate available camera modes, while optional tablet/computer control can allow for remote monitoring

Custom Control Across a Variety of Cameras and Devices
The PTZOptics SuperJoy Joystick Controller is a comprehensive solution supporting mix-and-match serial and network-based control for PTZ cameras of any generation.

Simultaneous pan, tilt and zoom control across IP, NDI® and serial cameras from multiple brands including PTZOptics, HuddleCamHD, Sony, BirdDog, and NewTek

If it’s IP-controlled, chances are the SuperJoy can control it – cameras, lights, projector screens and more – using four customizable buttons

Powerful Super-Preset buttons are programmable to trigger synchronized multi-preset commands across up to five unique camera groups with up to eight cameras each

Main Features
● Durable metal housing
● PTZOptics VISCA over IP & Serial control
● Limited NDI & Sony control
● PTZOptics Camera On Screen Display control
● Full Pan / Tilt / Zoom camera control
● PTZ, Focus, and Preset Speed Adjustment on the fly
● 5 Camera Control Groups
○ Groups 1-4 limited to 7 cameras
● 255 camera presets, 9 Quick presets
● 4 Customizable buttons (TCP, UDP, & HTTP)
● Fine tune zoom & focus control dials
● Buttons glow / flash when available
● RTSP Decoder via HDMI
● PTZOptics Focus Lock & Unlock
● Large LCD screen with controller status
● Import / Export settings via network & USB
● 2-Year warranty

What’s in the box?
● PT-SUPERJOY-G1 Joystick Controller
● 12V 2A DC International Power Supply
● RS-232C | DB9 to 8-pin mini-din cable
● PT-SUPERJOY-G1 Quick Start Guide
● Grounding Pin

Technical Specifications
Connections RS-232, RS-485, RS-422, RJ-45
Control Protocols VISCA, VISCA over IP, PELCO-D, PELCO-P, Sony, & NDI
Max Cameras 253 cameras total (Cam Groups 1-4: 7 channels Cam Group 5: 225 channels)
Recommended Max Distance RS-232 / RS-422: 50 ft | 15m, RS-485: 3,937 ft | 1200m, Ethernet: 328 ft | 100m
Baud rate 1200 ~ 19200 bps
Operation Specifications
Power 6W | 12VDC / PoE (802.3af) (Only use one (1) power source at a time.)
Working Temp 14° F ~ 122° F | -10° C ~ +50° C
Working Humidity 10% ~ 90% (non-condensation)
Weight 3.75 lbs | 1.70 kg
Dimensions (mm.) 370 W x 180 D x 101 H

Netgear M4250-10G2XF-PoE+ (GSM4212PX-100EUS) AV Line Managed Switch

Designed with input from industry professionals, this switch is engineered for 1G AV over IP. Enjoy rear-facing ports that ensure a clean integration in AV racks, and pre-configuration for out-of-the-box functionality.

Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.

Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design
Less fan noise, and mounting ears included for under-table or wall mounting.

Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4250 (and M4300) switches.

Fast, Easy, Configuration for AV Pros
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.

Focus on The Event Not Fan Noise
Most models have quiet mode which greatly reduces fan noise, and some models are even fanless.

Designed for AV Over IP right out of the box
With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.

Refined Design Provides Mounting Flexibility
Clean lines and port activity status is featured in the front of the switch, while cabling is neatly in the back. Universal mounting options allow VESA mounting or in standard racks.

Primary Port Speed : 1 Gigabit
Number of Ports : 12 (10x 1G, 2x SFP+)
PoE Ports / Budget : 8 PoE+ (30W/port), 240W Budget
IGMP Support : Enhanced (NETGEAR IGMP Plus™)
Jumbo Frame Support : Yes, up to 12kb
Acoustics : Fanless or 39.22dB@25ºC
Power Consumption : With PoE: 306.4W/1046.050Btu/hr; Without PoE: 25W/85.35Btu/hr; Standby without any port connection: 12.96W/44.245Btu/hr
AVB Support : Yes. Electronic license required, activation key sent via email (AVB4212PX-10000S)
Third party support : Domotz
Dimensions (WxDxH) : 440 x 200 x 43.2mm
Weight : 2.9Kg (6.39lb)

What's in the Box :
M4250-10G2XF-PoE+ (GSM4212PX)
Power cord(s)
Console USB Type-C and RJ45-DB9 cables
Rack-mounting standard brackets
Longer brackets for recessed mounting
Rubber footpads for tabletop installation
Installation guide
