RGBlink vue 4K PTZ Camera 20x Zoom

Name: RGBlink vue 4K PTZ Camera 20x Zoom
Brand: RGBlink
SKU: RGB20X-UPAI-OL
Price: 3090.00 EUR
Availability: InStock

MPN: RGB20X-UPAI-OL

Price: €3,090.00

No tax

We offer EU-wide sales, invoicing for VAT-free intra-community delivery.

Out of stock (Delivery time to be confirmed.)

The RGBlink vue 4K PTZ Camera with 20x optical zoom is tailored for professional broadcasting and live production environments. It features an 8.42-megapixel sensor and a 1600TVL resolution lens, delivering ultra-clear 4K image quality at resolutions up to 3840×2160 at 60fps.

This camera supports multiple output formats, including 12G-SDI, HDMI 2.0, USB Type-C, and H.264/H.265 dual stream output, providing flexibility for various production environments. Its 20x optical zoom lens enables detailed close-ups without compromising image quality.

Equipped with advanced ISP image processing and a wide dynamic range, the camera ensures high performance even in low-light scenarios. The pan and tilt control allows for a maximum pitch angle of -30° to +210°, achieving comprehensive panoramic coverage.

The built-in dual microphones and support for H.265/H.264 dual stream output adapt to different network environments, ensuring efficient and reliable streaming. The unique TALLY indicator light and identification board provide 360° visibility, enhancing communication during live productions.

With support for PoE+ (Power over Ethernet), the camera simplifies installation by reducing the need for additional power cables. Its low-power sleep function and stable AI tracking further enhance its functionality, making it suitable for various applications, including broadcast stage design, professional studios, corporate live broadcasts, remote conferences, and more.

UE Shipping

We ship all over the European Union

B2B Shop

Our offer is aimed only to B to B Customers, all prices are exclusive of tax.

Secure checkout

Secure online payments

Individual quotation

Send your enquiry via the form or email avgear@avgear.shop

RGBlink 4K vue PTZ camera is designed for professional broadcasting. The 1600TVL resolution lens is equipped with an advanced ISP image processor and 8.51 million pixel sensor (1), providing ultra-clear 4K image quality. Supports 12X/20X optical zoom and a range of outputs from HDMI, 12G-SDI to H.264 and H.265. It can support a maximum pitch angle of -30°~+210°, truly achieving panoramic vision coverage. Ultra-wide dynamic range provides powerful color performance. vue 4K has a unique TALLY indicator light and identification board, which can be seen from a 360° full viewing angle without fear of device switching. RGBlink 4K vue PTZ camera is suitable for any scene, including radio and television stage design, professional studios, corporate live broadcasts, character interviews, remote conferences, wedding hotels, outdoor live broadcasts, education and training, e-sports live broadcasts, church live broadcasts, etc.

Key Features
- Stable AI Tracking
- Resolution up to 3840x2160@60
- High performance in low light scenarios with Wide Dynamic Range
- H.265/H.264 Dual Stream Output Adapted to Different Network Environments
- 12G-SDI | HDMI2.0 | USB Type-C Multiple Output
- Pan and Tilt Control
- Built-in Dual Microphones
- Support TALLY
- Support PoE+
- Low-power Sleep Function
- Wide Application

Specification

Connectors

Video Output
SDI: 1xBNC
HDMI: 1xHDMI 2.0
USB: 1xUSB Type-C
LAN(PoE+): 1xRJ45

Audio
IN: 1x3.5mm TRS Stereo Jack
Built-in: Dual Microphones

Communication
RS232 In/Out: 1×DIN-8
RS422/485: 1×4-Pin Phoenix Connector (RS485-2PIN | RS422-4PIN)
LAN: 1×1000M LAN Port

Performance

Camera
Optical Zoom: 20X
Focal Length: f = 6.25mm ~ 125mm
Aperture: F1.58 ~ F3.95
Horizontal View Angle: 60° ~ 3.5°
Vertical View Angle: 36° ~ 2.0°
CMOS Sensor: 1/1.8 inch
Effective Pixels: 8.42m
Digital Zoom: 16X
Minimum Illumination: 0.5 Lux（@F1.8, AGC ON）
DNR: 3D DNR
White Balance: Auto / Manual/ One Push/ Indoors/ Outdoors/VAR
Focus/Iris/Shutter: Auto / Manual
BLC: ON/OFF
Dynamic Range: OFF/ Dynamic Level Adjustment
Video Adjustment: Brightness/Hue/Saturation/Contrast/Sharpness/B/W Mode/Gamma Curve
Image Flip: Auto / Manual
Image Freeze: Supported
SNR: ≥55dB
Lens Resolution: 1600TVL+ (Central Area)

Pan-and-Tilt Parameter
Pan/Tilt Movement: -170°～+170°/-90°～+210°
Pan/Tilt Control Speed: 1.8～100°/s；1.5～60°/s
Preset Speed/Quantity: Pan:100°/s(max), Tilt:60°/s(max); Up to 255 preset positions (10 remote control)
360° TALLY: Full 360° view of TALLY
TALLY Signboard: (No.1~255)

Output Resolutions
HDMI & SDI
3840x2160p60/59.94/50/30/29.97/25
1080p60/59.94/50/30/29.97/25
1080i60/59.94/50
720p60/59.94/50
Network
(H.265 / H.264 / MJPEG) 3840x2160, 1920x1080, 1280x720 etc.
(First Stream: 32kbps~51200kbps Second Stream: 32kbps~20480kbps)

Power
Input Voltage: DC 12V/1.5A
Max Power: 18W

Environment
Temperature: 0℃～40℃
Humidity: 20%～80%

Physical
Weight: 2.14kg
Dimension: 212mm x 176mm x 232mm

Reference RGB20X-UPAI-OL

Data sheet

Video Output: HDMI
RJ-45 (IP)
SDI
USB
Audio Input: Built-in microphone
Mini Jack 3.5mm
Audio Output: HDMI Embedded
RJ-45
SDI Embedded
USB
Max Output Resolution: 4K UltraHD (3840 x 2160) 50/60 fps
Control protocol for PTZ cameras: ONVIF
PELCO-D
PELCO-P
RS-232
RS-422
RS-485
UVC
VISCA
VISCA IP
Network Connection: Ethernet
Sensor Size: 1/1.8"
Optical Zoom: 20x
PoE Technology: Yes
Auto-Tracking: Yes
Tally Light: Yes
